The 9905-969 is distributed input acquisition hardware manufactured by Woodward and belongs to the LinkNet module series. This hardware functions as an analog input module specifically to receive and collect standard 4 to 20 mA direct current signals from field transmitters. It interfaces with the main control system to transmit physical transmitter signals to the central controller for digital control logic processing.
The module structure contains 6 independent analog input channels and directly includes a 24 Vdc internal loop power supply unit to provide excitation power for external transmitters. The hardware circuitry contains a physical electrical isolation architecture with 277 Vac isolation voltage from network to input channels and 500 V isolation voltage from power input to channels. For interface and configuration components, it contains hardware rotary switches for setting the LONWORKS bus network address and status indicator LEDs on the front panel.
The Woodward 9905-969 LinkNet Analog Input Module may still be available for purchase and support from Apter Power Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
WOODWARD 9905-969 LinkNet 6 Channel Analog Input Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power Generation
Collecting high-pressure/high-temperature pressure transmitter signals on main steam turbine pipelines to ensure precise steam flow control.
Petroleum Refining
Monitoring the lubricating oil supply pressure and auxiliary system temperature transmitter signals of core recycle hydrogen compressor trains in hydrocracking units.
Petrochemical
Transmitting temperature and pressure signals from interstage coolers of the core cracked gas compressor train to the main control system in ethylene plants.
Coal Chemical Industry
Collecting differential pressure transmitter data from the suction end filters of main air compressors and boosters in large air separation units.
Nuclear Power Generation
Used to collect analog process signals from turbine auxiliary feedwater systems and condensate pump control loops in conventional island distributed control systems.
Hydropower Generation
Collecting control oil pressure of hydraulic oil stations and 4–20 mA feedback signals from servomotor stroke transmitters in large hydro-turbine governing systems.
Power off before operating 9905-969 and hot-swapping is strictly prohibited. With built-in 24 Vdc loop power, clearly separate wiring for two-wire and four-wire transmitters to prevent active signal back-feeding from burning channels. Install terminal resistors on LON cables to prevent signal reflection, and precisely set the network node address via hardware switches during replacement.
