Which synchronization inputs can Siemens E10433-E0308-H110 accept?

The SICLOCK TS provides TTY, RS422 and IRIG input paths, including the documented GPS1000 and DCF arrangements.

How many Ethernet destinations can Siemens E10433-E0308-H110 configure?

Up to twenty LAN channels can be assigned with destination, protocol and transmission-cycle settings.

Which output interfaces are available on Siemens E10433-E0308-H110?

The unit provides TTY, RS422 and IRIG outputs through the documented X2 and X8 connections.

How is Siemens E10433-E0308-H110 mounted?

It snaps onto a 35 mm DIN rail or a SIMATIC S5 standard profile rail in an accessible cabinet position.

What installation clearance does Siemens E10433-E0308-H110 require?

The manual requires 50 mm free space above the unit and at least 50 mm below for process connectors.

How does Siemens E10433-E0308-H110 report a fault?

Local alarms and warnings appear on the display, while an isolated change-over contact supports external monitoring.

Which Ethernet media can Siemens E10433-E0308-H110 use?

The documented interfaces support 10BASE5, 10BASE-T and ITP connections.

What completes commissioning of Siemens E10433-E0308-H110?

Verify the retained source status, every configured output path, LAN distribution, alarm relay and representative consumer time.

E10433-E0308-H110

Name: E10433-E0308-H110
Brand: Siemens
SKU: E10433-E0308-H110

SICLOCK TS Plant Master Clock

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

Siemens E10433-E0308-H110 is a SICLOCK TS plant master clock with configurable synchronization inputs, point-to-point time outputs and Ethernet time distribution. It mounts in a control cabinet and supervises its time sources through local status and alarm functions.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for E10433-E0308-H110

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for E10433-E0308-H110

Manufacturer:

Siemens
Product Category:

General Automation
Spare Part Number:

E10433-E0308-H110
Estimated shipping dimensions:

14.8x16.5x 20cm
Weight:

2.8 kg
Tariff Code:

8537101190
Counliy of origin:

Germany
Product family:

SICLOCK TS V2.0
Hardware type:

Plant master clock
Synchronization inputs:

TTY 20 mA / TTY 40 mA / RS422 / IRIG
Time outputs:

TTY / RS422 / IRIG
Ethernet:

10BASE5 / 10BASE-T / ITP
LAN channels:

Up to 20 configured destinations
Alarm relay:

Isolated change-over contact
PC interface:

RS232, 9-pin Sub-D
Auxiliary output:

24 V / 0.5 A isolated
Supply range:

24-110 V DC or 90-250 V DC or 90-230 V AC
Power frequency:

50 / 60 Hz for AC supply
Mounting:

35 mm DIN rail or SIMATIC S5 profile rail
Required clearance:

50 mm above and below
Protection:

IP20
Operating temperature:

0 to 50 C

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

Siemens E10433-E0308-H110 forms the central time-reference node for a plant, converting an approved external source into configured TTY, RS422, IRIG and Ethernet timing paths.

Synchronization inputs: TTY 20 mA / TTY 40 mA / RS422 / IRIG.
Time outputs: TTY / RS422 / IRIG.
Ethernet: 10BASE5 / 10BASE-T / ITP.
LAN channels: Up to 20 configured destinations.

The installed SICLOCK TS position links the hardware identity, interfaces and retained configuration to one controlled functional path.

Important Notice: Confirm E10433-E0308-H110, every connected interface and the recorded acceptance result before service release.

Siemens E10433-E0308-H110 Manuals & Downloads

Siemens E10433-E0308-H110 Official SICLOCK TS User Manual Excerpt (PDF)Siemens E10433-E0308-H110 Installation & Commissioning Guide (PDF)

The official excerpt preserves the applicable manufacturer pages; the field guide organizes separate model-specific readiness, connection, verification and handover checks.

Plant time distribution

Distributes a controlled time reference to automation and monitoring systems.

GPS or DCF synchronization

Accepts the retained external clock source through the documented input path.

IRIG integration

Receives and transmits configured IRIG-A or IRIG-B timing formats.

Ethernet synchronization

Serves configured LAN destinations while preserving source, protocol and cycle settings.

Apply these checks to the exact Siemens E10433-E0308-H110 installation before isolation, replacement or release.

Confirm E10433-E0308-H110 and the SICLOCK TS V2.0 identity before work.

Record the active synchronization source and every A1, A2, A3, IRIG and LAN assignment.

Place dependent controllers and time consumers in the approved maintenance state.

Isolate the supply at the external 10 A protective device and verify protective earth continuity.

Maintain 50 mm clearance above and below the unit and lock the rail fastening.

Restore X1, X2, X3 and network connections without changing polarity, shielding or pin assignments.

After energization, verify U1-U3 indications, the display, source status and alarm relay state.

Compare distributed time at representative consumers before returning E10433-E0308-H110 to service.

Technical notes

Match E10433-E0308-H110 to the recorded SICLOCK TS position and every connected interface. Preserve the installed configuration and release only after controlled verification of plant-wide time synchronization and distribution.

FAQ View All FAQ

Which synchronization inputs can Siemens E10433-E0308-H110 accept?

The SICLOCK TS provides TTY, RS422 and IRIG input paths, including the documented GPS1000 and DCF arrangements.
How many Ethernet destinations can Siemens E10433-E0308-H110 configure?

Up to twenty LAN channels can be assigned with destination, protocol and transmission-cycle settings.
Which output interfaces are available on Siemens E10433-E0308-H110?

The unit provides TTY, RS422 and IRIG outputs through the documented X2 and X8 connections.
How is Siemens E10433-E0308-H110 mounted?

It snaps onto a 35 mm DIN rail or a SIMATIC S5 standard profile rail in an accessible cabinet position.

What installation clearance does Siemens E10433-E0308-H110 require?

The manual requires 50 mm free space above the unit and at least 50 mm below for process connectors.
How does Siemens E10433-E0308-H110 report a fault?

Local alarms and warnings appear on the display, while an isolated change-over contact supports external monitoring.
Which Ethernet media can Siemens E10433-E0308-H110 use?

The documented interfaces support 10BASE5, 10BASE-T and ITP connections.
What completes commissioning of Siemens E10433-E0308-H110?

Verify the retained source status, every configured output path, LAN distribution, alarm relay and representative consumer time.
