      6ES5420-4UA14

      SIMATIC S5 Digital Input 420 Module

      Product Describe：

      Siemens 6ES5420-4UA14 is used for dense sensor, contact, and status acquisition where the original S5 design relies on common-referenced non-isolated inputs.

      Ask our team:

      Get a quick price for： 6ES5420-4UA14
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Alternative names Technical notes FAQ

      Technical specifications for 6ES5420-4UA14

      Technical specifications for 6ES5420-4UA14

      • Manufacturer:
        Siemens
      • Product Category:
        PLC Systems
      • Spare Part Number:
        6ES5420-4UA14
      • Estimated shipping dimensions:
        25.4x1.9x19.5cm
      • Weight:
        1.049 lbs (0.38 kg)
      • Tariff Code:
        8537101101
      • Counliy of origin:
        Germany
      • System:
        SIMATIC S5
      • Module:
        Digital Input 420
      • Input count:
        32
      • Input voltage:
        24 V DC
      • Isolation:
        Non-isolated
      • Construction:
        Compact
      • Net weight:
        Approx. 0.476 kg
      • Lifecycle:
        PM500 since 1 October 2022
      • Dimensions:
        Siemens SiePortal lists official packaging dimensions 26.3 × 21 × 3.5 cm (L × W × H). Exact device W × H × D is not stated; do not use packaging dimensions for mounting.
      • Weight:
        0.476 kg (1.049 lb) net weight — Siemens SiePortal for complete catalog number 6ES5420-4UA14.
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      The Siemens 6ES5420-4UA14 is a compact SIMATIC S5 Digital Input 420 module with thirty-two non-isolated 24 V DC inputs. It collects discrete field states for the legacy S5 controller through the configured rack and process wiring.
      • SIMATIC S5
      • Digital Input 420
      • 32
      • 24 V DC

      The module is used for dense sensor, contact, and status acquisition where the original S5 design relies on common-referenced non-isolated inputs.

      Important Notice: Use the complete 6ES5420-4UA14 code and verify the physical nameplate and current Siemens documentation before installation or replacement.

      Apter Power 6ES5420-4UA14 Manuals and Guides

      Important Notice: These are two separate Apter Power documents prepared from the manufacturer-published Siemens information named in each document. Confirm the physical nameplate, current Siemens documents, and host-system requirements before installation or replacement.

      Legacy machine inputs
      Acquire dense switch and sensor states.
      Process status collection
      Read non-isolated 24 V DC contacts.
      S5 spare strategy
      Maintain the exact module while preparing migration.
      Read and follow the exact Siemens documentation and host-equipment instructions before use. Verify 6ES5420-4UA14 from the physical nameplate.
      1
      Recognize that the inputs are non-isolated
      2
      Verify shared reference potential and grounding
      3
      Label the 32-channel connector before removal
      4
      Back up the STEP 5 program and address assignment
      5
      Do not substitute another 420 suffix without pinout review

      Alternative Names

      Alternative Names

      6ES5420-4UA14 6ES5420 4UA14 Siemens 6ES5420-4UA14

      Technical notes

      Technical notes

      Use the complete 6ES5420-4UA14 identifier. Siemens classifies 6ES5420-4UA14 as PM500 since 1 October 2022 and states deletion without replacement. Values not published in the cited Siemens source are intentionally not inferred.

      FAQS

      • What is Siemens 6ES5420-4UA14?
        The Siemens 6ES5420-4UA14 is a compact SIMATIC S5 Digital Input 420 module with thirty-two non-isolated 24 V DC inputs. It collects discrete field states for the legacy S5 controller through the configured rack and process wiring.
      • What is the specific function of 6ES5420-4UA14?
        The module is used for dense sensor, contact, and status acquisition where the original S5 design relies on common-referenced non-isolated inputs.
      • Which signals, power, or data does 6ES5420-4UA14 handle?
        System: SIMATIC S5. Module: Digital Input 420. Input count: 32. Input voltage: 24 V DC.
      • Which system uses 6ES5420-4UA14?
        6ES5420-4UA14 belongs to the SIMATIC S5 context described in the cited Siemens source.
      • Which components are compatible with 6ES5420-4UA14?
        SIMATIC S5 rack and addressing documented for the machine 24 V DC field circuits sharing the required reference potential Original front connector and wiring diagram for the 420 module
      • Where is 6ES5420-4UA14 applied?
        Legacy machine inputs: Acquire dense switch and sensor states. Process status collection: Read non-isolated 24 V DC contacts. S5 spare strategy: Maintain the exact module while preparing migration.
      • What is the lifecycle status of 6ES5420-4UA14?
        Siemens classifies 6ES5420-4UA14 as PM500 since 1 October 2022 and states deletion without replacement.
      • What must be checked before installing 6ES5420-4UA14?
        Recognize that the inputs are non-isolated Verify shared reference potential and grounding Label the 32-channel connector before removal Back up the STEP 5 program and address assignment Do not substitute another 420 suffix without pinout review
