OPERATOR INTERFACE
SIMATIC MP 270 MULTI PANEL
10.4 INCH TFT DISPLAY
COLOR TOUCHSCREEN
4 MB CONFIGURATION MEMORY
CONFIGURABLE WITH PROTOOL FROM VERSION V6.0
The 6AV6542-0AG10-0AX0 is a SIMATIC OP27 operator panel equipped with a 5.7" STN liquid crystal color display, offering a resolution of 640 x 480 pixels. The device is designed with a rugged front providing IP65 protection and features a compact housing with dimensions of 240 x 180 x 57 mm, suitable for space-critical industrial applications.
640x480 Color Display
Integrated Multi-Protocol Ports
Flash Project Memory
This module provides integrated connectivity through a 25-pin Sub-D socket (IF1A) supporting TTY/RS232/RS422/RS485, and a 15-pin Sub-D socket (IF2) for MPI/PPI or PROFIBUS-DP up to 1.5 Mbit/s. It includes 1024 KB of Flash memory for project data and an onboard keyboard with 24 softkeys and 22 system keys for efficient process control.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Siemens 6AV6542-0AG10-0AX0 OPERATOR INTERFACE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Machine Tooling
The operator panel provides precise process monitoring for CNC and PLC-controlled machinery. It utilizes 24 softkeys and 22 system keys for high-speed data entry and navigation in complex manufacturing cycles.
Food Processing
Features a rugged front panel with IP65 protection, making it resistant to wash-down environments and dust. The 640 x 480 color STN display ensures clear visualization of temperature and mixing parameters.
Automotive Assembly
Integrated MPI and PROFIBUS-DP interfaces allow for seamless communication with SIMATIC S7 controllers at rates up to 1.5 Mbit/s. It manages real-time status updates and event messages on the production line.
Chemical Plants
The device operates within a permissible ambient temperature of 0 °C to +50 °C for vertical installation in control cabinets. It monitors bit messages and process values across multi-protocol IF1A and IF2 connections.
Packaging Logistics
Equipped with 1024 KB of Flash memory for project data storage and recipe management. The compact dimensions allow for integration into small-scale conveyor and sorting control systems.
Water Treatment
Supports RS232, RS422, and RS485 communication for distributed I/O and pump station monitoring. The CCFL backlit display provides long-term reliability for continuous 24-hour operation in utility facilities.
The 6AV6542-0AG10-0AX0 operator panel is designed for vertical installation in control cabinets, requiring a mounting cutout of 229 mm x 169 mm to ensure proper fit and the IP65 degree of protection at the front. The unit operates on a +24 V DC power supply with a permissible range of 18 V to 30 V and a typical current consumption of 0.3 A, necessitating careful adherence to terminal assignments for the 24 V DC and 0 V DC connections.
During operation, the ambient temperature must be maintained between 0 °C and +50 °C, while the relative humidity must not exceed 85% to prevent condensation within the CCFL backlit STN color display assembly. For communication setup, the 25-pin IF1A and 15-pin IF2 Sub-D sockets require shielded cables to maintain signal integrity for TTY, RS232, or PROFIBUS-DP protocols at rates up to 1.5 Mbit/s.
What are the display specifications for the 6AV6542-0AG10-0AX0?
The unit features a 5.7" STN liquid crystal display (Color) with a resolution of 640 x 480 pixels .
What communication protocols are supported via the IF2 interface on the 6AV6542-0AG10-0AX0?
The IF2 interface uses a 15-pin Sub-D socket and supports MPI, PPI, and PROFIBUS-DP protocols at transmission rates up to 1.5 Mbit/s.
What are the integrated interfaces for IF1A on the 6AV6542-0AG10-0AX0?
The IF1A interface is a 25-pin Sub-D socket that provides integrated TTY, RS232, RS422, and RS485 communication options.
What is the power consumption of the 6AV6542-0AG10-0AX0 during operation?
The module requires a +24 V DC supply and typically consumes 0.3 A, with a maximum current consumption rating of 0.5 A.
ow many keys are available on the 6AV6542-0AG10-0AX0 for operator control?
The operator panel is equipped with 24 softkeys (18 of which have LEDs) and 22 system keys for data entry and navigation.
