The 6AV6648-0EC11-3AX0 is an industrial SMART Panel built with a 10" widescreen TFT display. It operates via direct touch control and displays up to 65,536 colors to provide visual clarity for machine-level status monitoring. The hardware configuration includes a built-in real-time clock (RTC) for timestamping alarms and system events, alongside a host USB Type A interface to support external equipment connections. Furthermore, the unit carries an official CE certificate, verifying its compliance with standard industrial regulations and safety requirements.
Operates on a low-power industrial 24 VDC architecture
Dedicated isolated RS422/485 port supporting point-to-multipoint links
Hardware-level real-time clock (RTC) with event timestamp recording
The physical hardware architecture provides industrial-grade data exchange and field connectivity, integrating a combined RS422/485 serial communication port alongside a standard Ethernet RJ45 network interface. To facilitate secondary automation loops and administrative plant controls, the unit incorporates a host USB Type A interface for peripheral linkages and embedded real-time clock support for event timestamping. Furthermore, the complete panel assembly carries an official CE certificate, verifying full compliance with safety regulations and electromagnetic standards.
Project engineering and custom graphic configurations run through the WinCC flexible SMART software environment, enabling database synchronization with downstream controllers. As part of its standard delivery framework, the factory package contains open-source software components provided free of charge, which are accessible via the enclosed CD. This panel layout establishes a solution for horizontal installation within standard industrial control cabinets.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas Downstream
Mounted within cabinets inside explosion-proof control rooms to collect and display static parameters and alarm info from multiple storage tanks via the Ethernet (RJ45) interface.
Automobile Manufacturing
Status switching and fault localization of conveyor roller tables on automotive stamping lines.
Pharmaceutical Packaging
Parameter regulation of automatic blister packaging machines and fully automatic capsule filling machines.
Food & Beverage Production
Parameter management of automatic labeling machines and CIP (Clean-in-Place) systems in bottling workshops.
Rubber & Plastics Processing
Temperature control of heating zones on fully automatic injection molding machines and plastic extruders.
Construction Material Machinery
Numerical calibration of automatic batching scales and cement packing machines in concrete batching plants.
When deploying the 6AV6648-0EC11-3AX0 HMI panel, operators must provide a stable 24V DC power supply and ensure reliable enclosure grounding to safeguard the 16-million-color TFT display from voltage fluctuations and electromagnetic interference. During wiring, technicians should carefully configure the dip switches or software parameters to match the chosen serial standard, whether RS-232, RS-422, or RS-485, to avoid permanent hardware damage to the communication ports.
Additionally, screen programming must be compiled using WinCC flexible SMART V5 or higher, and the resistive touchscreen must only be operated with fingers or approved plastic styluses, avoiding sharp or metallic tools that could pierce the front membrane.
The Siemens SIMATIC HMI SMART 1000 IE V3 is an industrial operator panel structured for machine-level visualization and control tasks. This hardware configuration is built around a 10-inch widescreen TFT display that supports up to 65,536 distinct colors, rendering process schematics, state animations, and system parameters via direct capacitive or resistive touch operation. For timing validation and historical tracking, the electronic assembly integrates a hardware-backed real-time clock (RTC) chip, which appends independent, unalterable time-stamps to incoming system alarms, process faults, and operator log actions.
What is the 6AV6648-0EC11-3AX0 SIMATIC HMI Smart 1000 IE V3?
It is a Siemens SMART Panel industrial human-machine interface operator panel used for machine-level automation status monitoring and data interaction.
What size display screen is equipped on the 6AV6648-0EC11-3AX0 SIMATIC HMI Smart 1000 IE V3?
This panel is configured with a 10-inch widescreen TFT liquid crystal display.
How many display colors are supported by the 6AV6648-0EC11-3AX0 SIMATIC HMI Smart 1000 IE V3?
This hardware screen supports the rendering of up to 65,536 colors for graphics and flowcharts.
How do field personnel operate the 6AV6648-0EC11-3AX0 SIMATIC HMI Smart 1000 IE V3?
Operators control screen switches, input values, or change operational modes directly via touch operation on the screen.
What serial communication physical interfaces are included on the 6AV6648-0EC11-3AX0 SIMATIC HMI Smart 1000 IE V3?
It integrates a combined RS422/RS485 serial communication interface on its base housing.
