Technical specifications for 6AV3617-1JC20-0AX1
-
Manufacturer:Siemens
-
Product Category:HMI Panels
-
Spare Part Number:6AV3617-1JC20-0AX1
-
Estimated shipping dimensions:24x5.3x20.5cm
-
Weight:0.82 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Memory:256KB
-
Power Supply:24V DC
-
Current Rating:0.4 AMP
-
Power consumption:Typical 25 W
-
Other interfaces:1 x RS-232
-
Resolution:640 x 480 pixels
Information
Overview
Manuals
Common Applications
Product Precautions
The 6AV3617-1JC20-0AX1 Operator Panel is an industrial-grade human-machine interface device component within the SIMATIC HMI family.
- Features an 8-line, 40-character black-and-white LC display
- Includes a 24-key membrane keyboard (16 with LEDs)
- Includes a battery-backed hardware clock and Info/Error LEDs
The RAM area processes runtime variable updates and temporary inputs. The hardware contains no magnetic storage media with mechanical rotating shafts to prevent dust and vibration wear. The panel integrates low-level hardware status diagnostics. The front panel indicators (Info LED and Error LED) are directly controlled by the internal chip status; the Error indicator provides a status notification when the communication link is interrupted or a system stack error occurs.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Siemens 6AV3617-1JC20-0AX1 OPERATOR PANEL Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Machinery Manufacturing
Enters processing parameters for CNC machine tools and metal cutting equipment.
Automotive Manufacturing
Displays the operating status of conveyor chains in final assembly shops.
Plastics Processing
Monitors temperature control variables in the heating sections of injection molding machines.
Printing Industry
Inputs tension control and alignment values for multi-color offset printing presses.
Chemical Industry
Prompts interlock fault texts for agitation motors inside chemical reactors.
Pharmaceutical Engineering
Monitors operational sequences in Chinese medicine extraction and batching systems.
During installation, the 6AV3617-1JC20-0AX1 must remain vertical. Without external ventilation, the inclination angle must not deviate from the vertical plane. The device must be powered by a standard 24V DC bus, and the internal circuit lacks a serial UPS interface. When replacing the panel, ensure the internal 3.6V lithium battery has a valid voltage to prevent loss of clock data and retentive parameters.
