      6AV6648-0CE11-3AX0

      Touch Operator Panel
      Ships by Friday, November 6
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      Siemens 6AV6648-0CE11-3AX0 is a Smart 1000 IE V3 touch panel with a 10.1-inch TFT display, Ethernet and RS-422/485 connectivity.
      • Manufacturer part number
        6AV6648-0CE11-3AX0
      • Shipping
        Swift global dispatch
      • Condition
        New, original product
      • Shipping size (est.)
        27.5cm × 21.6cm ×4.5cm
      • Country of Origin
        Germany

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 6AV6648-0CE11-3AX0
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 0

        Review your reference

        Send the full 6AV6648-0CE11-3AX0 marking and installed SIMATIC HMI Smart 1000 IE V3 configuration.
      • 1

        Confirm the offer

        Review the exact assembly, condition, included items and quoted dispatch date.
      • 2

        Arrange dispatch

        Confirm delivery details for 6AV6648-0CE11-3AX0; tracking follows when shipment is arranged.

      • Match the complete marking

        Include 6AV6648-0CE11-3AX0 and any revision or assembly number visible on the item. Keep the exact reference on your enquiry and quotation.

      • Check the offered item before ordering

        Request available label and connector photos. Have your maintenance team compare the offered 6AV6648-0CE11-3AX0 with the installed equipment and applicable Siemens documentation.

      Technical specifications for 6AV6648-0CE11-3AX0

      • Manufacturer:
        Siemens
      • Product Category:
        HMI Panels
      • Spare Part Number:
        6AV6648-0CE11-3AX0
      • Weight:
        1.18 kg
      • Tariff Code:
        8537101190
      • Product designation:
        Smart 1000 IE V3
      • Display:
        10.1-inch TFT touch screen
      • Resolution:
        1024 × 600 pixels
      • Colors:
        65,536
      • Supply:
        24 V DC; permissible 19.2–28.8 V DC
      • Current consumption:
        230 mA rated; 370 mA maximum
      • Processor:
        ARM, 600 MHz
      • Ethernet ports:
        1
      • Serial interface:
        1 shared RS-422/485; no RS-232
      • USB interface:
        1 host USB type A
      • Engineering software:
        WinCC flexible SMART V3
      • Protection:
        IP65 front; IP20 rear
      • Variable capacity:
        800 per device
      • Screen capacity:
        150 configurable screens
      View as PDF Ask for Quote

      Information

      Overview Downloads Applications / Compatibility Product Precautions
      • Siemens 6AV6648-0CE11-3AX0 provides local operator access to process values, alarms and recipes. The HMI project, communication driver and connected controller determine its machine-level behavior.
      Product type: Touch operator panel
      Display: 10.1-inch TFT, 1024 × 600 pixels
      Engineering: WinCC flexible SMART V3
      The 6AV6648-0CE11-3AX0 is the SIMATIC HMI Smart 1000 IE V3. Its TFT touch display has 1024 × 600 pixels and 65,536 colors, with onscreen numeric and alphanumeric entry. The panel includes a 600 MHz ARM processor, flash and RAM storage, and a retentive, synchronizable real-time clock for configured operator functions.

      The panel operates from 24 V DC within a permissible range of 19.2–28.8 V DC. Rated current consumption is 230 mA and maximum consumption is 370 mA. Communication connections comprise one Industrial Ethernet port, one shared RS-422/485 interface and one USB host interface; it has no RS-232 interface or SD card slot. Ethernet connectivity does not make it a PROFINET IO device.

      WinCC flexible SMART V3 supports configuration of process-value displays and entries, alarm handling and recipe management. Device limits include 800 variables, 150 configurable screens and ten recipes with up to 100 records per recipe. Front protection is IP65 and rear protection is IP20 under the installation conditions. Temperature limits depend on mounting orientation and inclination, so check the cabinet arrangement before replacement.
      Controller platform reference: SIMATIC HMI Smart 1000 IE V3. Match the installed configuration before replacement.
      Technical downloads for 6AV6648-0CE11-3AX0: an original Siemens reference excerpt and an Apter Power installation planning guide.
      Specifications apply to Smart 1000 IE V3; V4 and V5 hardware values and capabilities are not transferred to this model. The planning guide is prepared by Apter Power; apply the complete manufacturer instructions and the stated applicability boundaries.
      System and supply context: Specifications apply to Smart 1000 IE V3; V4 and V5 hardware values and capabilities are not transferred to this model. Accessories are included only when itemized in the quotation.

      Platform applications: The following applications describe SIMATIC HMI Smart 1000 IE V3 functions. Match the complete 6AV6648-0CE11-3AX0 identity to the installed system before selecting a replacement.
      Prepare 6AV6648-0CE11-3AX0 against the installed configuration and applicable Siemens instructions. Plan isolation and the resulting interruption of system operation before replacement.
      Isolate the panel

      Switch off and isolate the panel supply and place the connected machine in a safe state before removal.

      Preserve the project

      Back up the HMI project and communication settings before changing the installed panel.

      Check DC power

      Use the specified 19.2–28.8 V DC range and account for maximum current consumption of 370 mA.

      Match the interface

      Check Ethernet or RS-422/485 wiring and the selected communication driver; do not treat this panel as a PROFINET IO device.

      Check mounting conditions

      Maintain the front seal and rear cabinet protection. Confirm orientation-dependent temperature and inclination limits.

      Verify operator functions

      Test touch input, process values, alarms and recipe transfer under controlled conditions before returning the machine to service.

      Alternative Names

      6AV6648-0CE11-3AX0 Siemens 6AV6648-0CE11-3AX0

      Technical notes

      Installation relationship: The panel operates from 24 V DC within a permissible range of 19.2–28.8 V DC. Rated current consumption is 230 mA and maximum consumption is 370 mA. Communication connections comprise one Industrial Ethernet port, one shared RS-422/485 interface and one USB host interface; it has no RS-232 interface or SD card slot. Ethernet connectivity does not make it a PROFINET IO device.

      Configuration: Specifications apply to Smart 1000 IE V3; V4 and V5 hardware values and capabilities are not transferred to this model.

      Technical reference: Siemens 6AV6648-0CE11-3AX0 data sheet, 28 September 2026.

      FAQ View All FAQ

      • Which panel generation is 6AV6648-0CE11-3AX0?
        It is the Smart 1000 IE V3. V4 and V5 specifications must not be substituted for this order code.
      • What display does 6AV6648-0CE11-3AX0 use?
        It has a 10.1-inch TFT touch display with 1024 × 600 pixels and 65,536 colors.
      • What DC supply does 6AV6648-0CE11-3AX0 require?
        Nominal supply is 24 V DC, with a permissible range of 19.2–28.8 V DC.
      • Which communication ports are fitted to 6AV6648-0CE11-3AX0?
        It provides one Industrial Ethernet port, a shared RS-422/485 interface and one USB host port. RS-232 and an SD card slot are not fitted.
      • Which software configures 6AV6648-0CE11-3AX0?
        The specified engineering software is WinCC flexible SMART V3. Match the project and panel runtime before transfer.
      • Does 6AV6648-0CE11-3AX0 support PROFINET IO?
        No. Industrial Ethernet is present, but the data sheet does not specify PROFINET or PROFINET IO support.
      • What protection ratings apply to 6AV6648-0CE11-3AX0?
        The front is IP65 and the rear is IP20 when the installation meets the applicable mounting conditions.
      • What recipe and screen limits apply to 6AV6648-0CE11-3AX0?
        The device supports 150 configurable screens and ten recipes with up to 100 records per recipe; each record can contain 50 entries.
