Get a quick price for 6GF1710-3AA
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 6GF1710-3AA
-
Manufacturer:Siemens
-
Product Category:General Automation
-
Spare Part Number:6GF1710-3AA
-
Estimated shipping dimensions:15x8x10cm
-
Weight:0.76 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product family:SIMATIC VS710
-
Software execution:ProVision runtime
-
Image format:Up to 768 x 512 pixels
-
Processor:100 MHz 80486
-
Main memory:16 MB DRAM
-
Storage:16 MB IDE flash disk
-
Image buffer:2 MB
-
Power supply:24 V DC, 20.4 to 28.8 V
-
Current consumption:480 mA typical / 600 mA maximum
-
Digital inputs:2 optically isolated, 24 V DC
-
Digital outputs:4 optically isolated, 24 V DC / 0.5 A
-
PROFIBUS DP:Up to 12 Mbit/s
-
RS232:Up to 115 kbit/s
-
Lens interface:C-mount
-
Mounting:M4 threads / 1/4-20 UNC / mounting bracket
-
Operating temperature:0 to 50 C
Information
Overview
Manuals
Common Applications
Product Precautions
Siemens 6GF1710-3AA processes captured images inside one compact unit and exchanges inspection triggers, results and engineering data through its configured digital and serial interfaces.
- Image format: Up to 768 x 512 pixels.
- Processor: 100 MHz 80486.
- Main memory: 16 MB DRAM.
- Storage: 16 MB IDE flash disk.
The installed SIMATIC VS710 position links the hardware identity, interfaces and retained configuration to one controlled functional path.
Important Notice: Confirm 6GF1710-3AA, every connected interface and the recorded acceptance result before service release.
Siemens 6GF1710-3AA Manuals & Downloads
Siemens 6GF1710-3AA Official SIMATIC VS710 Quick Reference Excerpt (PDF)Siemens 6GF1710-3AA Installation & Commissioning Guide (PDF)
The official excerpt preserves the applicable manufacturer pages; the field guide organizes separate model-specific readiness, connection, verification and handover checks.
Quality inspection
Runs configured image checks for presence, position or assembly verification.
Parts identification
Processes the retained ProVision program and returns its configured result.
PROFIBUS integration
Exchanges trigger and result data with the installed automation system.
Local engineering
Uses VGA and RS232 connections for controlled setup and diagnostic access.
Apply these checks to the exact Siemens 6GF1710-3AA installation before isolation, replacement or release.
1
Confirm 6GF1710-3AA and the SIMATIC VS710 ProVision execution before work.
2
Archive the inspection program, camera settings, I/O map and PROFIBUS address.
3
Place the machine and inspection result path in the approved maintenance state.
4
Isolate the 24 V supply and protect the lens and CCD opening from contamination.
5
Restore the C-mount lens, mechanical position, grounding and connector orientation.
6
Verify the 20.4-28.8 V DC supply before reconnecting digital I/O and PROFIBUS.
7
Load the retained ProVision program and compare live images, triggers and output states.
8
Run known good and known reject samples before releasing 6GF1710-3AA.
Technical notes
Match 6GF1710-3AA to the recorded SIMATIC VS710 position and every connected interface. Preserve the installed configuration and release only after controlled verification of stand-alone industrial image inspection and parts verification.
FAQ View All FAQ
-
What is integrated in Siemens 6GF1710-3AA?The VS710 combines the camera, processor, image memory, flash storage and external interfaces in one stand-alone unit.
-
Which image size can Siemens 6GF1710-3AA process?The documented ProVision execution supports image formats up to 768 by 512 pixels.
-
Which supply range applies to Siemens 6GF1710-3AA?Use a 24 V DC SELV supply within the documented 20.4 to 28.8 V range.
-
How many digital I/O points does Siemens 6GF1710-3AA provide?It provides two optically isolated digital inputs and four optically isolated 24 V DC outputs.
-
Which PROFIBUS rate does Siemens 6GF1710-3AA support?The floating DP interface supports transmission rates up to 12 Mbit/s.
-
How can Siemens 6GF1710-3AA be mounted?Use the M4 threads, the 1/4-20 UNC support socket or the supplied mounting bracket.
-
Which local interfaces support Siemens 6GF1710-3AA engineering?The unit provides VGA and RS232 interfaces in addition to PROFIBUS DP and digital I/O.
-
What completes inspection acceptance for Siemens 6GF1710-3AA?Confirm focus and alignment, then run retained good and reject samples while checking triggers, results and communication.
