How many DC outputs are provided by Schneider Electric 140DDO84300C?

Schneider Electric 140DDO84300C provides 16 DC outputs.

How are the 140DDO84300C output channels grouped?

The 140DDO84300C arranges its output channels into two groups of eight.

What output-voltage range applies to 140DDO84300C?

The 140DDO84300C operates across an output range of 10 to 60 V DC.

Which output logic does 140DDO84300C use?

The 140DDO84300C uses positive logic with source-output operation.

How much output addressing is required by 140DDO84300C?

The controller assigns one output word to the 140DDO84300C.

What load-current limits apply to 140DDO84300C?

The 140DDO84300C supports a maximum load of 12 A per module and 6 A per group.

Which point and group fuses are specified for 140DDO84300C?

The 140DDO84300C requires a 2 A fuse for each point and an 8 A fuse for each group.

What distinguishes the 140DDO84300C conformal-coated variant?

The 140DDO84300C incorporates Humiseal 1A33 conformal coating.

140DDO84300C

Name: 140DDO84300C
Brand: Schneider Electric
SKU: 140DDO84300C

DC Output Module

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

Schneider Electric 140DDO84300C is a conformal-coated Modicon Quantum DC output module with 16 positive-logic channels. The outputs operate from 10 to 60 V DC and are divided into two groups of eight.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for 140DDO84300C

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 140DDO84300C

Manufacturer:

Schneider Electric
Product Category:

PLC Systems
Spare Part Number:

140DDO84300C
Estimated shipping dimensions:

4.1x10.2x25cm
Weight:

0.44 kg
Tariff Code:

8537101190
Counliy of origin:

France
Output count:

16
Grouping:

2 groups of 8
Logic:

Positive logic (source)
Output range:

10 to 60 V DC; 72 V absolute maximum
Addressing:

1 output word
Load limits:

12 A module; 6 A per group
Response:

Up to 1 ms in either direction
Protective treatment:

Humiseal 1A33 conformal coating

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

The 140DDO84300C switches sixteen externally powered DC loads while providing group protection and front-panel status for each commanded output.

16 positive-logic source outputs
Two groups of eight channels
10 to 60 V DC output range
Humiseal 1A33 conformal coating

Divide the sixteen loads into the two approved eight-channel groups. Observe the 6 A group and 12 A module load-current boundaries. Use a 2 A fuse for each point and an 8 A fuse for each group as specified. Confirm external field power and source-output polarity before energization.

Important Notice: Confirm the complete Schneider Electric 140DDO84300C marking, installed hardware arrangement, circuit assignments and cabinet records before installation or replacement.

Schneider Electric 140DDO84300C Manuals & Downloads

Schneider Electric 140DDO84300C Technical Reference (PDF)Schneider Electric 140DDO84300C Installation & Commissioning Guide (PDF)

The first document presents model-specific technical information; the second provides a separate installation, verification and acceptance workflow.

DC load switching

Controls sixteen positive-logic field loads.

Grouped output control

Separates outputs into two groups of eight.

Protected cabinet outputs

Uses approved point and group fuse protection.

Coated hardware

Provides Humiseal 1A33 treatment for the exact C variant.

Read the applicable Schneider Electric instructions before work. Verify the complete 140DDO84300C identity, installed hardware arrangement and every connected circuit before isolation or replacement.

Record the complete 140DDO84300C marking.

Isolate both external field-power groups.

Confirm 10 to 60 V DC source-output circuits.

Verify the two groups of eight channels.

Check 2 A point and 8 A group fuses.

Keep loads inside group and module limits.

Review Active, external-fault and 16 status LEDs.

Document every commanded output before release.

Technical notes

The 140DDO84300C uses two externally powered groups of eight source outputs. Verify 10–60 V DC polarity, the specified point and group fusing and the 6 A group / 12 A module current limits before functional testing.

FAQ View All FAQ

How many DC outputs are provided by Schneider Electric 140DDO84300C?

Schneider Electric 140DDO84300C provides 16 DC outputs.
How are the 140DDO84300C output channels grouped?

The 140DDO84300C arranges its output channels into two groups of eight.
What output-voltage range applies to 140DDO84300C?

The 140DDO84300C operates across an output range of 10 to 60 V DC.
Which output logic does 140DDO84300C use?

The 140DDO84300C uses positive logic with source-output operation.

How much output addressing is required by 140DDO84300C?

The controller assigns one output word to the 140DDO84300C.
What load-current limits apply to 140DDO84300C?

The 140DDO84300C supports a maximum load of 12 A per module and 6 A per group.
Which point and group fuses are specified for 140DDO84300C?

The 140DDO84300C requires a 2 A fuse for each point and an 8 A fuse for each group.
What distinguishes the 140DDO84300C conformal-coated variant?

The 140DDO84300C incorporates Humiseal 1A33 conformal coating.
