140ACI04000C

Name: 140ACI04000C
Brand: Schneider Electric
SKU: 140ACI04000C

Analog Input Module

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

Schneider Electric 140ACI04000C is a sixteen-channel differential Modicon Quantum analogue input module for 0–20 mA, 0–25 mA and 4–20 mA signals.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Immediate Dispatch
Available for dispatch immediately.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for 140ACI04000C

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 140ACI04000C

Manufacturer:

Schneider Electric
Product Category:

PLC Systems
Spare Part Number:

140ACI04000C
Estimated shipping dimensions:

4x10.5x24.8cm
Weight:

0.32 kg
Tariff Code:

8537101190
Counliy of origin:

France
Product range:

Modicon Quantum automation platform
Product type:

Analogue input module
Analogue inputs:

16 differential channels
Input ranges:

0–20 mA; 0–25 mA; 4–20 mA
Digital ranges:

0–16000; 0–20000; 0–25000; 0–4095 counts
Addressing:

17 input words
Input impedance:

250 ohms
Absolute maximum input:

30 mA
Update time:

15 ms
Channel-to-bus isolation:

1780 V AC for 60 s
Filter:

Single-pole low-pass, -3 dB at 34 Hz ±25%
Bus current:

360 mA
Power dissipation:

5 W
Operating temperature:

0–60 °C
Relative humidity:

95% non-condensing

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

Schneider Electric 140ACI04000C acquires sixteen differential current channels for the Quantum rack with selectable count ranges and a fifteen-millisecond update time.

16 differential current inputs
0–20, 0–25 and 4–20 mA ranges
17 input-word addressing
15 ms update time

Use Schneider Electric 140ACI04000C only with the documented rack, field interface and approved commissioning record for the installed application.

Important Notice: Confirm the complete 140ACI04000C identifier, companion hardware and wiring condition; do not substitute a nearby code without an engineering review.

Schneider Electric 140ACI04000C Manuals & Downloads

Schneider Electric 140ACI04000C Technical Reference (PDF)Schneider Electric 140ACI04000C Installation & Commissioning Guide (PDF)

The Technical Reference consolidates exact-model technical data and engineering boundaries; the Installation & Commissioning Guide organizes identity control, isolation, interface checks, functional testing and acceptance records.

High-density transmitter input

Acquires up to sixteen documented field-current channels.

Mixed current-range system

Uses per-project 0–20, 0–25 or 4–20 mA scaling.

Quantum rack renewal

Restores the seventeen-word input map and channel allocation.

Current-loop diagnostics

Uses the channel LEDs and broken-wire status for configured 4–20 mA loops.

Apply these controls specifically to Schneider Electric 140ACI04000C before isolation, replacement, reconnection and final release.

Record all sixteen channel assignments, current ranges and scaling before disconnection.

Do not exceed the specified 30 mA absolute input limit on any channel.

Preserve loop-power, common, shielding and terminal assignments for each field circuit.

Verify the selected digital count range matches the controller scaling.

Restore the complete seventeen-input-word mapping without shifting channels.

Review channel and external-fault indications before applying process signals.

Inject known current values at multiple points on every serviced channel.

Confirm normal readings and broken-wire response on configured 4–20 mA loops before release.
