Technical specifications for P0902BP
-
Manufacturer:Invensys
-
Product Category:DCS Systems
-
Spare Part Number:P0902BP
-
Estimated shipping dimensions:23x21x4.5cm
-
Weight:0.45 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Product type:Terminal cable assembly
-
Control platform:Foxboro I/A Series
-
Documented module association:FBM24B / FBM25B
-
Signal context:Input field wiring
-
Field interface:Screw-terminal arrangement
-
Lifecycle:Legacy / discontinued
-
Country of origin:USA
-
HS code:8537101190
Information
Overview
Manuals
Common Applications
Product Precautions
P0902BP provides the documented terminal-cable path between a legacy Foxboro I/A Series input-module position and its field-side screw-terminal arrangement.
- Identifies the legacy P0902BP cable assembly
- Associates the cable with documented FBM24B/FBM25B input positions
- Maintains the approved module-to-terminal wiring path
- Supports controlled point-to-point input verification
The assembly must remain matched to the installed FBM24B or FBM25B position and the site wiring drawing. The page intentionally avoids unsupported electrical ratings where no exact current public manufacturer data sheet is available.
Important Notice: Confirm P0902BP, the installed FBM24B/FBM25B position, both connector ends, cable orientation, field-terminal drawing, conductor map, shielding, grounding, diagnostics and controlled input-test evidence before commissioning.
Apter Power P0902BP Manuals and Guides
- Apter Power Foxboro P0902BP I/A Series Terminal Cable Technical Reference PDF
- Apter Power Foxboro P0902BP FBM Connection and Point-to-Point Workbook PDF
The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.
I/A Series cabinet wiring
Connects the documented input-module position to its field termination.
Legacy FBM maintenance
Preserves cable orientation and connector identity during planned service.
Termination-panel refurbishment
Maintains the approved screw-terminal and conductor map.
Input-loop recommissioning
Supports point-to-point status and channel-response testing after replacement.
Read the applicable Foxboro installation instructions before work. Verify P0902BP, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
1
Confirm P0902BP on the complete cable-assembly label and maintenance record.
2
Place the Foxboro controller, process and affected inputs in the approved maintenance state.
3
Isolate module and field energy before releasing either connector or terminal.
4
Record the FBM24B/FBM25B position, connector orientation and every field terminal.
5
Inspect cable condition, strain relief, connector locking and terminal cleanliness.
6
Restore the exact cable route, connector seating and documented conductor map.
7
Review FBM and system diagnostics after controlled energization.
8
Perform point-to-point input and alarm tests for every affected channel before release.
Alternative Names
Invensys Foxboro P0902BP; I/A Series terminal cable
Technical notes
Because P0902BP is legacy hardware, verify the complete label, both connector ends, cable orientation, FBM24B/FBM25B association and the approved field-terminal drawing before replacement. Record every conductor and terminal, keep the assembly de-energized during service and complete point-to-point input tests before release.
FAQ View All FAQ
-
How is the exact P0902BP execution identified?Match P0902BP on the cable label and both connector ends.
-
What documented role does P0902BP perform?It maintains a legacy I/A Series input-module-to-terminal wiring path.
-
Which installed host must be matched before fitting P0902BP?Match the documented FBM24B/FBM25B position and site field-terminal drawing.
-
Which physical interfaces must be recorded for P0902BP?Record connector orientation, cable route, strain relief and every field terminal.
-
What isolation or handling controls apply to P0902BP?Isolate module and field energy before disconnecting the cable assembly.
-
What must be restored after installing P0902BP?Restore the exact route, locking, conductor map, shields and grounds.
-
What evidence confirms P0902BP is ready for service?Retain FBM diagnostics plus point-to-point input and alarm tests.
-
Which manufacturer record supports the P0902BP page?Schneider Electric Foxboro DCS documentation supports the platform context; exact-model ratings must come from the supplied item or controlled site drawing.
