Rockwell Automation / ICS Triplex T7481A is an evidence-bounded Regent Plus monitored guarded output module in the ICS Triplex installed-base context. The official Regent Plus reference identifies T7481A as the 24 VDC monitored guarded output module and distinguishes its 5 mA minimum load from T7481.
- Regent Plus Monitored Guarded Output Module
- 24 Vdc monitored guarded outputs
- 5 mA minimum load identified in the official reference
- Verify exact Regent Plus chassis and termination
Outputs: 16 guarded outputs, two groups of 8
Operating voltage: 18 to 36 VDC
Load current: 2 A at 0 to 40 C; derate to 1.5 A at 60 C
Minimum load: 5 mA for T7481A
Important Notice: Use the complete T7481A code and verify the physical nameplate, current ICS Triplex / Rockwell Automation documentation, field wiring, project, and compatible system hardware before installation or replacement.
Apter Power T3401 Manuals and Guides
Important Notice: These are two separate Apter Power documents prepared from the official ICS Triplex source named in each document. Confirm the physical nameplate, current Rockwell Automation documentation, and applicable installation instructions before installation or replacement.
Emergency shutdown contacts
Uses the T3401 regent 24 vdc digital input module in a model-appropriate Regent control or protection function.
Fire and gas switches
Handles system status and diagnostics under the official engineering limits.
Motor trip status
Uses the T3401 regent 24 vdc digital input module in a model-appropriate Regent control or protection function.
Valve limit switches
Handles system status and diagnostics under the official engineering limits.
Read Rockwell Automation ICSTT-RM006-EN-P (PD-6011) and the applicable system installation instructions before use. Verify the physical nameplate, revision, slot and matched termination hardware.
1
Verify the exact model, hardware revision, firmware and nameplate before substitution.
2
Install only with Regent I/O chassis, field terminal blocks, processor modules and WINTERPRET configuration; do not mix unmatched termination or base hardware.
3
De-energize or follow the approved live-insertion procedure and site safety plan before removal.
4
Preserve module keying, slot assignment, wiring polarity, shields, grounding and field power limits.
5
Complete application download, diagnostics, proof testing and functional acceptance before return to service.
