      MAI32MAD

      32-Channel Analog Input Module
      In Stock
      Ships by Tuesday, September 22
      Fast Shipping Available

      Product Describe：

      Rockwell Automation ICS Triplex MAI32MAD is a thirty-two-channel Trusted analog input module for 0-10 VDC field signals. Its triple modular redundant architecture presents voted measurement data to the Trusted system.

      Ask our team:

      Get a quick price for： MAI32MAD
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Alternative names Technical notes FAQ

      Technical specifications for MAI32MAD

      Technical specifications for MAI32MAD

      • Manufacturer:
        ICS Triplex
      • Product Category:
        DCS System
      • Spare Part Number:
        MAI32MAD
      • Estimated shipping dimensions:
        39.8x39.8x2.8cm
      • Weight:
        1.52 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Sweden
      • Input channels:
        32
      • Architecture:
        Triple modular redundant
      • Input range:
        0-10 VDC
      • Input overrange:
        +/-40 VDC
      • Resolution:
        12 bit
      • Accuracy at 25 C:
        +/-0.04% full signal range
      • Stability:
        +/-20 ppm/C
      • ADC type:
        Successive approximation, monotonic
      • Nominal sample rate:
        40 ms
      • Input impedance:
        >20 MOhm
      • Power-off impedance:
        >12 kOhm
      • Common-mode range:
        +/-11 VDC
      • System-to-channel isolation:
        1 kVDC
      • Channel-to-channel isolation:
        +/-15 VDC
      • Power consumption:
        7.5 W
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Rockwell Automation / ICS Triplex MAI32MAD provides the 32-Channel Analog Input Module function within ICS Triplex Trusted installations.
      • Acquires thirty-two voltage measurements
      • Uses triplicated input processing for fault tolerance
      • Performs monitored analog conversion
      • Transfers validated channel data to the Trusted controller

      MAI32MAD operates with Trusted module carrier, field termination assembly, Trusted controller, engineered 0-10 VDC transmitters.
      Typical engineered duties include Safety-related process measurements, Turbine auxiliary analog monitoring, Burner management analog inputs, Critical package-unit instrumentation.

      Important Notice: MAI32MAD must be installed only in the carrier, termination and Trusted configuration assigned to its 0-10 VDC TMR input function.

      Apter Power MAI32MAD Manuals and Guides

      Important Notice: The first document is an Apter Power MAI32MAD model-specific technical reference. The second is a directly related Rockwell Automation / ICS Triplex document for installation, configuration or system engineering.

      MAI32MAD Safety-related process measurements
      Acquires thirty-two voltage measurements
      MAI32MAD Turbine auxiliary analog monitoring
      Uses triplicated input processing for fault tolerance
      MAI32MAD Burner management analog inputs
      Performs monitored analog conversion
      MAI32MAD Critical package-unit instrumentation
      Transfers validated channel data to the Trusted controller
      Read the applicable Rockwell Automation / ICS Triplex installation instructions before work. Verify MAI32MAD and the installed-system configuration.
      1
      Place the Trusted application in its engineered maintenance state.
      2
      Confirm MAI32MAD and the assigned Trusted carrier position.
      3
      Verify the configured 0-10 VDC range for every active channel.
      4
      Match the field termination assembly wiring and channel references.
      5
      Inspect carrier contacts and termination connectors before inserting MAI32MAD.
      6
      Start the Trusted system and review triplicated-channel diagnostics.
      7
      Inject representative voltages and verify scaling across the configured range.
      8
      Record channel, diagnostic and fault-response results before release.

      Alternative Names

      Alternative Names

      MAI32xAD

      Technical notes

      Technical notes

      MAI32MAD commissioning should verify the Trusted I/O slot, field termination arrangement and channel mapping for all configured analog inputs. Review module diagnostics and validate representative measurements before service.

      FAQS

      • What input range is assigned to MAI32MAD?
        MAI32MAD is the 0-10 VDC variant in the Trusted analogue-input family.
      • How many channels does MAI32MAD process?
        It processes thirty-two analog input channels.
      • Why does MAI32MAD use TMR architecture?
        The triplicated paths support fault detection and voted measurement processing in the Trusted system.
      • What isolation check applies to MAI32MAD?
        Confirm the system-to-channel and channel-to-channel limits against the installed field circuit.
      • How should MAI32MAD be wired?
        Use the specified Trusted carrier and field termination assembly with each 0-10 VDC channel correctly referenced.
      • What commissioning test is appropriate for MAI32MAD?
        Inject representative voltages, confirm scaling and observe channel diagnostics across the configured range.
      • Can MAI32MAD replace a current-input module?
        No. Replacement requires the same voltage-input variant, channel mapping and termination design.
      • What maintenance data should be trended for MAI32MAD?
        Trend diagnostic state, channel deviation, calibration result and any repeated fault indication.
