Technical specifications for MU-PDIX02 51304485-100
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:51304485-100
-
Estimated shipping dimensions:3×31.8×28cm
-
Weight:0.64 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
IOP function:Digital input
-
Part number:51304485-100
-
Channels:32
-
Compliance execution:CE compliant
-
Conformal coating:Not coated
-
24 VDC current usage:90 mA
-
Supported FTA classes:24 VDC, 120 VAC and 240 VAC digital input
-
Card-file role:Input/Output Processor
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell MU-PDIX02 51304485-100 converts a thirty-two-point digital-input field group into Process Manager status data while the selected FTA establishes the actual field voltage and terminal arrangement.
- 32 input channels
- Digital-input IOP
- Multiple DI FTA classes
- 90 mA at 24 VDC
Use Honeywell MU-PDIX02 51304485-100 only with the documented system, field interface and approved commissioning record for the installed application.
Important Notice: Confirm the complete MU-PDIX02 51304485-100 identity, companion hardware and wiring condition; do not substitute a similar code without an engineering review.
Honeywell MU-PDIX02 51304485-100 Manuals & Downloads
Honeywell MU-PDIX02 51304485-100 Official Technical Reference Excerpt (PDF)Honeywell MU-PDIX02 51304485-100 Installation & Commissioning Guide (PDF)
The Official Technical Reference Excerpt consolidates the selected Honeywell manual pages and exact-model technical data; the Installation & Commissioning Guide organizes identity control, isolation, interface checks, functional testing and acceptance records.
Discrete state processing
Processes thirty-two field contact states for controller use.
Mixed-voltage cabinet families
Works with the installed 24 VDC, 120 VAC or 240 VAC DI FTA execution.
Alarm and permissive acquisition
Supplies digital status data used by process alarms and permissives.
Legacy IOP replacement
Restores an exact 51304485-100 digital-input processor position.
Apply these controls specifically to Honeywell MU-PDIX02 51304485-100 before isolation, replacement, reconnection and final release.
1
Match MU-PDIX02 and 51304485-100 before removing the processor card.
2
Record the installed DI FTA model and its field-voltage class.
3
Back up all thirty-two channel assignments and inversion or alarm settings.
4
Place the affected IOP in the approved maintenance state before isolation.
5
Use grounded ESD controls and handle the card only by its edges.
6
Inspect the card-file connector and IOP-to-FTA cable before insertion.
7
Do not apply FTA voltage-class assumptions to the processor card itself.
8
Verify all thirty-two input states and clear IOP diagnostics before handover.
Alternative Names
MU-PDIX02 51304485-100
Technical notes
Record the complete model identity, installed system position, companion hardware, field wiring and configuration before service. Use the exact-model limits and acceptance checks shown in the manuals for restoration.
FAQ View All FAQ
-
How many channels does Honeywell MU-PDIX02 51304485-100 process?It processes thirty-two digital-input channels.
-
What is the role of Honeywell MU-PDIX02 51304485-100?It is a digital-input I/O Processor for the Process Manager card file.
-
Which FTA voltage classes can be paired with Honeywell MU-PDIX02 51304485-100?The processor works with the documented 24 VDC, 120 VAC and 240 VAC digital-input FTA families.
-
Is Honeywell MU-PDIX02 51304485-100 the coated execution?No. MU-PDIX02 is the non-coated model; the MC prefix identifies the coated counterpart.
-
What 24 VDC current is assigned to Honeywell MU-PDIX02 51304485-100?The component power table assigns 90 mA.
-
What must be recorded before replacing Honeywell MU-PDIX02 51304485-100?Capture the card-file slot, FTA model, cable identity and all thirty-two channel configurations.
-
Does Honeywell MU-PDIX02 51304485-100 determine the field voltage by itself?No. The connected digital-input FTA establishes the field-voltage and terminal execution.
-
How should Honeywell MU-PDIX02 51304485-100 be commissioned?Verify card recognition, diagnostics and every mapped input state against controlled field conditions.
