Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for FC-TSRO-0824 V1.1
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for FC-TSRO-0824 V1.1
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:FC-TSRO-0824 V1.1
-
Estimated shipping dimensions:30x7x6.2cm
-
Weight:0.5 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Output channels:8
-
Nominal coil voltage:24 Vdc
-
Maximum coil voltage:36 Vdc
-
Pickup voltage:19.2 Vdc
-
Typical coil current:40 mA
-
Contact rating:5 A fused
-
Switching voltage:250 Vac/Vdc maximum
-
Switching load:1250 VA; 150 W
-
Safety integrity:SIL 3
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell FC-TSRO-0824 V1.1 is an eight-channel Safe Relay Output FTA that provides isolated, fused contacts for Safety Manager field loads.
- Provides eight safety relay outputs
- Isolates safety logic from field loads
- Uses individually fused contacts
- Supports SIL 3 output circuits
FC-TSRO-0824 V1.1 operates with Safety Manager output module, 24 Vdc relay-coil supply, Fused field circuits, Safety shutdown loads.
Its engineered use includes Emergency trip solenoids, Burner shutdown circuits, Machine safety contactors, Fire and gas isolation outputs.
Important Notice: Confirm the complete FC-TSRO-0824 V1.1 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.
Apter Power FC-TSRO-0824 V1.1 Manuals and Guides
Apter Power FC-TSRO-0824 V1.1 Product Technical Reference PDFHoneywell FC-TSRO-0824 V1.1 Official Technical Manual PDF
The first document is an Apter Power model-specific technical reference. The second supports installation, configuration and engineering verification for FC-TSRO-0824 V1.1.
Emergency trip solenoidsProvides eight safety relay outputs
Burner shutdown circuitsIsolates safety logic from field loads
Machine safety contactorsUses individually fused contacts
Fire and gas isolation outputsSupports SIL 3 output circuits
Read the applicable Honeywell instructions before work. Verify FC-TSRO-0824 V1.1 and the installed Safety Manager configuration.
1Verify the complete FC-TSRO-0824 V1.1 marking and its assigned Safety Manager position before work.
2Isolate the applicable power and field energy before disconnecting FC-TSRO-0824 V1.1.
3Protect FC-TSRO-0824 V1.1 connectors and electronic assemblies with approved ESD controls.
4Record the installed wiring, channel assignment and configuration before replacement.
5Match Safety Manager output module and 24 Vdc relay-coil supply to the documented system arrangement.
6Commission FC-TSRO-0824 V1.1 with controlled status, signal and diagnostic checks.
7Retain the final emergency trip solenoids functional-test result in the maintenance record.
Technical notes
Confirm coil supply, contact voltage category and fuse rating for every channel, then prove de-energize-to-trip action under a controlled test.
FAQ View All FAQ
-
Does FC-TSRO-0824 V1.1 match Safety Manager output module in a Emergency trip solenoids installation?Verify the complete FC-TSRO-0824 V1.1 marking, the documented Safety Manager position and the installed Safety Manager output module before fitting the assembly.
-
How should FC-TSRO-0824 V1.1 be wired when it must provides eight safety relay outputs?Isolate the circuit, identify every terminal and reproduce the approved polarity, shield and channel assignment for FC-TSRO-0824 V1.1; then continuity-test the affected path.
-
Which Safety Manager records should be captured before removing FC-TSRO-0824 V1.1?Record the as-found wiring, installed position, active configuration and diagnostic state associated with FC-TSRO-0824 V1.1 before disconnection.
-
What controlled test confirms that FC-TSRO-0824 V1.1 can isolates safety logic from field loads?Apply the approved field or simulated stimulus, observe the Safety Manager indication and confirm the intended response without bypassing the normal interlocks.
-
Which 24 Vdc relay-coil supply condition should be checked when FC-TSRO-0824 V1.1 reports an abnormal state?Check the 24 Vdc relay-coil supply supply, seating and connection first, then compare channel diagnostics with the recorded FC-TSRO-0824 V1.1 baseline.
-
Can FC-TSRO-0824 V1.1 be moved directly into Burner shutdown circuits without validating Safety shutdown loads?No. Confirm the Safety shutdown loads, revision, connection scheme and Safety Manager configuration before transferring FC-TSRO-0824 V1.1 to that duty.
-
What maintenance evidence is required after FC-TSRO-0824 V1.1 is used for Machine safety contactors?Retain the nameplate record, corrective action, final diagnostics and a controlled machine safety contactors functional-test result for FC-TSRO-0824 V1.1.
-
How should FC-TSRO-0824 V1.1 be returned to service in Fire and gas isolation outputs?Restore power under control, verify uses individually fused contacts, exercise the intended signal path and release FC-TSRO-0824 V1.1 only after the Safety Manager remains in its approved operating state.
