The 51198685-100 SPS5710-2-LF is a Series C industrial power supply that delivers a regulated 24 VDC output at 20 A. It is widely used in industrial automation and distributed control systems (DCS).
Supports global voltage standards for flexible deployment
Built-in safeguards extend equipment life and system reliability
Simplifies installation, integration, and maintenance
This power supply module integrates redundancy diagnostics and Advanced Thermal Distribution Innovation (ATDI), supporting live hot-swappability. It features status monitoring outputs to feed real-time diagnostics, including over-temperature, output derating, and overload warnings, back to the control layer. The printed circuit board is designed with conformal coating for resistance against chemical corrosion, moisture, and dust, making it suitable for remote I/O enclosures and distributed fiber links.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Honeywell 51198685-100 SPS5710-2-LF Power Supply Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Petrochemical Refining
Provides uninterrupted power to C300 controllers and Safety Instrumented Systems (SIS) in crude distillation and catalytic cracking units.
Thermal Power Generation
Powers Series C I/O modules in Boiler Control Systems (BCS) and turbine auxiliary control cabinets.
Coal Chemical Industryn
Supplies power to field distributed control hardware and fieldbus instruments in coal gasifiers and methanol synthesis sections.
Nuclear Power Generation
Supplies power to DCS hardware in conventional island auxiliary systems and water treatment control units of nuclear power plants.
Iron & Steel Smelting
Energizes blast furnace air supply, converter thermal parameter acquisition racks, and plant-wide network switch enclosures.
Non-Ferrous Metallurgy
Delivers continuous industrial-grade power to multi-channel analog acquisition baseplates in aluminum potlines and copper flash smelters.
Install on a ventilated Series C power baseplate. Derate power when ambient temperature exceeds 60°C. Verify redundancy module status in redundant configurations. Follow safety regulations for live hot-swapping in hazardous areas. Monitor overload and overvoltage warnings via the control layer to maintain output within 24-26 VDC.
Technical notes
Technical notes
Provides high-stability, high-capacity 24V DC (20A) industrial-grade power to C300 controllers and IO HIVE components, ensuring the uninterrupted operation of large-scale process automation systems.
What is the core use of 51198685-100 SPS5710-2-LF?
Provides stable 24V DC power to C300 controllers and I/O modules.
How to install 51198685-100 SPS5710-2-LF?
Slot it directly and vertically into the dedicated Series C power base.
What is the input voltage of 51198685-100 SPS5710-2-LF?
It supports a wide range of AC input from 100 to 240 VAC.
What is the rated output current of 51198685-100 SPS5710-2-LF?
Its rated output current is 20 Amps.
Does 51198685-100 SPS5710-2-LF support hot-swapping?
Yes, it can be replaced directly during system operation under power.
How does 51198685-100 SPS5710-2-LF achieve redundancy?
Achieved by installing two modules on the same redundant baseplate.
