Technical specifications for F8628X
-
Manufacturer:HIMA
-
Product Category:DCS Systems
-
Spare Part Number:F8628X
-
Estimated shipping dimensions:4x18.6x12.8cm
-
Weight:0.45 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product class:Communication module
-
Fieldbus:PROFIBUS-DP
-
System families:H41q / H51q
-
H51q option capacity:Up to 5 per central module
-
Installation:Central-rack communication option
-
Project control:Node and bus settings retained from installed system
Information
Overview
Manuals
Common Applications
Product Precautions
The F8628X adds the exact PROFIBUS-DP communication path represented in the HIMA H51q assembly options.
- Performs the documented PROFIBUS-DP communication role within the HIQuad H41q / H51q architecture.
- Supports controlled system integration without transferring assumptions from a nearby HIMA execution.
- Keeps installed configuration, diagnostics and maintenance evidence tied to the exact hardware function.
- Enables witnessed functional acceptance before the validated safety system returns to service.
Within the documented HIQuad H41q / H51q architecture, HIMA F8628X performs the PROFIBUS-DP communication role. Its installed rack position, configuration and connected circuits remain part of the validated safety-system record.
Important Notice: Treat HIMA F8628X as an exact execution. Confirm the full marking, installed HIQuad H41q / H51q context, controlled project and manufacturer evidence before replacement or commissioning.
HIMA F8628X Manuals & Downloads
HIMA F8628X Official Manufacturer Excerpt (PDF)HIMA F8628X Installation & Commissioning Guide (PDF)
The official excerpt preserves relevant original manufacturer pages for this product family. The installation guide provides a separate controlled workflow for preparation, replacement, commissioning and acceptance.
F8628X installed-role restoration
Restore the documented PROFIBUS-DP communication role without transferring assumptions from a nearby HIMA suffix.
F8628X controlled maintenance
Use the exact F8628X identity, installed position and approved HIQuad H41q / H51q records during service work.
F8628X configuration recovery
Retain the project, channel or communication assignments and diagnostic history that belong to this execution.
F8628X acceptance testing
Witness the model-specific function and archive the release evidence before the safety system returns to operation.
HIMA F8628X installation checks: preserve the exact model identity, documented system arrangement and controlled acceptance evidence.
1
Read the complete HIMA F8628X marking and compare it with the controlled equipment record.
2
Place the process served by F8628X in its approved maintenance state before hardware work.
3
Remove the applicable rack and field power before inserting, removing or rewiring F8628X.
4
Record the rack position, project assignment and every documented connection associated with F8628X.
5
Do not transfer ratings or compatibility claims from a nearby HIMA model to F8628X.
6
Use grounded ESD controls and inspect the connector, backplane and mechanical retention for F8628X.
7
Restore the validated HIQuad H41q / H51q configuration and review all relevant diagnostics for F8628X.
8
Prove the intended PROFIBUS-DP communication role and retain witnessed acceptance results before release.
Technical notes
Treat HIMA F8628X as an exact execution. Confirm the full marking, installed HIQuad H41q / H51q context, controlled project and manufacturer evidence before replacement or commissioning.
FAQ View All FAQ
-
Which fieldbus does HIMA F8628X support?The manufacturer identifies it as the PROFIBUS-DP communication module.
-
Where is HIMA F8628X used in the HIQuad architecture?It is listed as a communication option for H41q/H51q central racks.
-
How many HIMA F8628X options are shown per H51q central module?The HIMA assembly table shows up to five PROFIBUS-DP modules per central module.
-
Why must HIMA F8628X be distinguished from F8628?The catalogue lists both identities, so the complete marking and approved project must agree.
-
Which bus information must be retained for HIMA F8628X?Retain the PROFIBUS address, baud-rate design, topology, termination and mapped data exchange.
-
What should be inspected before seating HIMA F8628X?Inspect the assigned central-rack slot, connector, backplane contacts and mechanical retention under ESD control.
-
How is HIMA F8628X functionally accepted?Review module and bus diagnostics and witness the intended PROFIBUS-DP data exchange with every required peer.
