      IC697ALG230

      Analog Input
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      GE IC697ALG230 is an eight-channel high-level analog input base for the Series 90-70. It accepts individually configured voltage or current inputs and can support documented analog expander modules.

      Ask our team:

      Get a quick price for： IC697ALG230
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for IC697ALG230

      Technical specifications for IC697ALG230

      • Manufacturer:
        General Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        IC697ALG230
      • Estimated shipping dimensions:
        4x21.7x29.1cm
      • Weight:
        0.64 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product family:
        Series 90-70
      • Base channels:
        Eight differential analog inputs
      • Input ranges:
        Plus or minus 10 V or 4 to 20 mA, configured by channel
      • Expansion capacity:
        Up to seven expander modules; up to 120 inputs in the documented subsystem
      • Base update time:
        2.4 to 2.8 ms maximum for all eight base channels
      • Resolution:
        16-bit voltage; 14-bit current, no missing codes
      • Voltage increment:
        312.5 microvolts per LSB
      • Current increment:
        0.5 microampere per LSB
      • Current input element:
        Internal 250 ohm load selected by jumper
      • Isolation:
        Inputs isolated from the VME backplane; channels are not isolated from one another
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      GE IC697ALG230 is an eight-channel high-level analog input base for the Series 90-70. It accepts individually configured voltage or current inputs and can support documented analog expander modules.
      • Provides eight individually configured differential analog inputs
      • Supports plus or minus 10 V and 4 to 20 mA signal ranges
      • Expands through documented high-level analog expander modules
      • Transfers isolated field data to the Series 90-70 VME backplane

      Apply GE IC697ALG230 only in the documented Series 90-70 system position after checking its interfaces, companion hardware and configured values.

      Important Notice: Confirm the full IC697ALG230 marking, installed revision, compatible hardware and approved commissioning record before release.

      GE IC697ALG230 Manuals & Downloads
      GE IC697ALG230 Technical Reference (PDF)GE IC697ALG230 Installation & Commissioning Guide (PDF)

      The first document presents model-specific technical and system data. The second provides a separate installation, connection, commissioning and acceptance workflow.

      Process measurement
      Acquires approved voltage and current signals from field transmitters.
      Multi-channel expansion
      Builds a documented high-level analog subsystem with compatible expanders.
      Signal migration
      Preserves scaling, range and current-input jumper records during replacement.
      Commissioning tests
      Confirms channel values, update behavior and open-circuit diagnostics against the project record.
      Read the applicable GE instructions before work. Verify GE IC697ALG230 and the installed system configuration before commissioning.
      1
      Verify the complete GE IC697ALG230 marking and installed revision.
      2
      Confirm the documented Series 90-70 rack position and compatible companion hardware.
      3
      Back up the approved controller, network or channel configuration before removal.
      4
      De-energize the system and follow the current manufacturer service procedure before handling hardware.
      5
      Label every field, communication, common, shield and protective-ground connection.
      6
      Do not substitute a neighbouring catalog number without documented engineering approval.
      7
      Restore the exact configuration and verify normal module and system diagnostics.
      8
      Complete a controlled model-specific functional test before production release.

      Technical notes

      Technical notes

      Use only the complete GE IC697ALG230 identity and the current manufacturer publication. Verify the installed revision, companion hardware, wiring and saved configuration before replacement or release.

      FAQS

      • How many base channels does GE IC697ALG230 provide?
        It provides eight differential analog input channels on the base converter.
      • Which signal ranges does GE IC697ALG230 support?
        Each channel can be configured for plus or minus 10 V or 4 to 20 mA.
      • How is a current input selected on GE IC697ALG230?
        The documented jumper connects the internal 250 ohm load for current operation.
      • Can GE IC697ALG230 be expanded?
        Yes. The official system description supports up to seven compatible expanders and up to 120 inputs.
      • Are GE IC697ALG230 channels isolated from one another?
        No. The inputs are isolated from the VME backplane but not channel-to-channel.
      • What must be recorded before replacing GE IC697ALG230?
        Record the complete GE IC697ALG230 marking, installed revision, system position, connections and approved configuration before removal.
      • What confirms successful commissioning of GE IC697ALG230?
        The exact GE IC697ALG230 identity, restored configuration, normal diagnostics and a controlled model-specific functional test must all agree with the approved record.
