Technical specifications for IS200VCRCH1BBC
-
Manufacturer:General Electric
-
Product Category:General Automation
-
Spare Part Number:IS200VCRCH1BBC
-
Estimated shipping dimensions:2x18.6x26.1cm
-
Weight:0.32 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Board family:IS200VCRCH1B
-
Bus format:Single-width VME I/O board
-
Contact-input capacity:48 points with two TBCI terminal boards
-
Relay-output capacity:24 points with two TRLY terminal boards
-
Event time stamp:1 ms for VCRC contact inputs
-
I/O arrangement:TMR or simplex
Information
Overview
Manuals
Common Applications
Product Precautions
GE IS200VCRCH1BBC belongs to the IS200VCRCH1B hardware family documented for Mark VI discrete I/O. It scans field contacts, time-stamps their transitions, controls relay-output data and reports board, firmware and attached-terminal identities through the rack communications interface.
- Complete BBC revision retained for configuration control
- 48 contact inputs through two TBCI boards
- 24 relay outputs through two TRLY boards
- 1 ms sequence-of-events time stamping
The operating chain runs from Plant contact and relay circuits → TBCI / TRLY termination → IS200VCRCH1BBC VCRC processor → Mark VI rack and controller database; document each boundary and prove the intended final response before release.
Important Notice: Do not shorten the BBC revision when selecting the spare or recording the completed Mark VI maintenance activity.
GE IS200VCRCH1BBC Manuals & Downloads
GE IS200VCRCH1BBC Official Technical Reference Excerpt (PDF)GE IS200VCRCH1BBC Installation & Commissioning Guide (PDF)
The Official Technical Reference Excerpt provides the VCRC family architecture and documented IS200VCRCH1B hardware listing applicable to the BBC revision. The separate guide covers exact-identity control, replacement and functional acceptance.
Revision-controlled spares
Maintains the exact BBC suffix in Mark VI maintenance records.
Contact event capture
Provides millisecond SOE timing for alarms, trips and permissives.
Relay output control
Routes commanded outputs to the paired TRLY terminal boards.
Distributed Mark VI I/O
Serves simplex or TMR discrete-I/O sections in the cabinet architecture.
Apply these controls specifically to GE IS200VCRCH1BBC before isolation, replacement, reconnection, energization and final release.
1
Do not replace GE IS200VCRCH1BBC with a suffix variant without an approved compatibility review.
2
Isolate rack power and all contact-wetting and relay-load sources before cable work.
3
Handle the board using grounded ESD protection and approved packaging.
4
Record the two TBCI and two TRLY cable assignments before removal.
5
Inspect the VME connector and all 37-pin cable connectors for bent or recessed contacts.
6
Load only the controlled Mark VI configuration assigned to this rack position.
7
Use an approved test permit before forcing inputs or relay outputs.
8
Verify BBC identity, terminal-board IDs, SOE timing, point logic and relay response before handover.
Technical notes
Preserve BBC as part of the installed revision identity and verify terminal-board pairing before exchange. Prove contact scanning, 1 ms SOE recording, relay commands, terminal identification and diagnostic status before release.
FAQ View All FAQ
-
Why must the full GE IS200VCRCH1BBC code be retained?BBC is part of the complete revision identity used for spare control and installed-equipment matching.
-
Which terminal boards connect to GE IS200VCRCH1BBC?The documented VCRC arrangement uses two TBCI contact-input boards and two TRLY relay-output boards.
-
What contact-input capacity applies to GE IS200VCRCH1BBC?Two TBCI boards provide 48 contact-input points.
-
What relay-output capacity applies to GE IS200VCRCH1BBC?Two TRLY boards provide 24 relay-output points.
-
Does GE IS200VCRCH1BBC provide event timing?Yes. VCRC contact inputs are time-stamped to 1 ms.
-
Can GE IS200VCRCH1BBC operate in a simplex channel?Yes. The VCRC architecture supports simplex as well as TMR arrangements.
-
What should be backed up before changing GE IS200VCRCH1BBC?Archive the Toolbox configuration, point map, terminal-board identities, cable schedule, alarm logic and relay assignments.
-
How should GE IS200VCRCH1BBC be accepted after replacement?Confirm the exact suffix and rack slot, then test terminal IDs, input mapping, SOE timing, relay outputs and diagnostics.
