Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for 1C31238H01
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 1C31238H01
-
Manufacturer:Emerson
-
Product Category:DCS Systems
-
Spare Part Number:1C31238H01
-
Estimated shipping dimensions:12.1x3.6x3cm
-
Weight:0.04 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Component:Compact I/O cavity insert
-
Position:Personality-module position
-
Channel context:16-channel compact input configurations
-
Supported functions:Compact digital input, sequence-of-events input or contact input
-
Active circuitry:Normally no personality module circuitry is required
Information
Overview
Manuals
Common Applications
Product Precautions
Westinghouse 1C31238H01 occupies the personality-module position in compatible compact Ovation input assemblies and provides the wiring-schematic identification for sixteen-channel configurations.
- Provides sixteen-channel compact input context for the documented compact i/o cavity insert function.
- Handles digital, events or contact-input wiring identification through the specified Ovation I/O subsystem.
- Works with compatible compact input electronics module selected by the project.
- The insert provides the field-wiring schematic label while the compact electronics module performs the active I/O function.
The compact i/o cavity insert belongs in the controlled Ovation I/O subsystem and works with compatible compact input electronics module selected by the project. Its field connection, companion hardware and project configuration must be reviewed together before the channel is returned to service.
Important Notice: Use 1C31238H01 only with compatible compact input electronics module selected by the project; verify the field interface and controlled configuration before energizing the subsystem.
Westinghouse 1C31238H01 Manuals & Downloads
Westinghouse 1C31238H01 Official Technical Reference Excerpt (PDF)Westinghouse 1C31238H01 Installation & Commissioning Guide (PDF)
The first document covers the product function, system role and technical selection. The installation guide covers identification, connection checks, commissioning and the acceptance record.
Installed-base maintenance
Restores the documented compact i/o cavity insert position without changing the approved system architecture.
Loop or channel service
Supports verification of digital, events or contact-input wiring identification at the assigned control-system channel.
Planned replacement
Provides an exact-identity replacement path when compatible compact input electronics module selected by the project and the field interface have been confirmed.
Commissioning support
Allows the responsible engineer to prove wiring, configuration, status and response for sixteen-channel compact input context.
Before installing Westinghouse 1C31238H01, confirm the documented system, interfaces and controlled configuration.
1
Match the complete 1C31238H01 marking to the work order and installed position before removal.
2
Confirm compatible compact input electronics module selected by the project before making or breaking any field connection.
3
Keep the assigned digital, events or contact-input wiring identification within the documented subsystem and range.
4
Record terminal designations, polarity, common and shield treatment before disconnecting conductors.
5
Inspect module seating, connector keying, terminal condition and strain relief before power is restored.
6
Restore the controlled channel configuration, range selection and alarm or timeout behavior after installation.
7
Check local indicators and controller diagnostics for internal, communication or channel faults during commissioning.
8
Prove the intended response across sixteen-channel compact input context and record the acceptance result before release.
Technical notes
Use 1C31238H01 only with compatible compact input electronics module selected by the project; verify the field interface and controlled configuration before energizing the subsystem.
FAQ View All FAQ
-
What physical role does Westinghouse 1C31238H01 serve in compact Ovation I/O?It is a cavity insert that occupies the personality-module position and carries the wiring-schematic identification.
-
Which compact input functions can use Westinghouse 1C31238H01?The insert is documented for compatible compact digital-input, sequence-of-events and contact-input configurations.
-
How many channels are represented by Westinghouse 1C31238H01?Its wiring context covers sixteen-channel compact input assemblies.
-
Does Westinghouse 1C31238H01 contain the active input circuitry?Normally no personality-module circuitry is required; the compatible compact electronics module performs the active I/O function.
-
Why must the selected electronics module be checked before fitting Westinghouse 1C31238H01?Digital input, sequence-of-events and contact-input executions use different active electronics, while the insert identifies the correct field-wiring arrangement.
-
What information should the label on Westinghouse 1C31238H01 convey?The label should show the wiring schematic appropriate to the installed sixteen-channel compact input configuration.
-
Can Westinghouse 1C31238H01 be commissioned as an independent I/O module?No. It is an insert for the personality-module cavity and only has meaning with the matching compact electronics assembly.
-
What inspection confirms Westinghouse 1C31238H01 is installed correctly?Verify the insert is seated in the personality position, its schematic matches the active module and all sixteen field circuits follow that displayed connection plan.
