1C31125G02

FAQS

• Which electronics module is paired with Westinghouse 1C31125G02?
  The specified electronics partner is the sixteen-channel 1C31122G01 digital-output module.
• Where does Westinghouse 1C31125G02 obtain relay power?
  When used with relay modules, it routes local auxiliary power from the I/O backplane to the relay interface.
• How many output paths pass through Westinghouse 1C31125G02?
  The personality module carries sixteen digital-output paths.
• Can Westinghouse 1C31125G02 route outputs directly to field terminals?
  Yes. The documented arrangement allows the output paths to reach terminal blocks as an alternative to the locally powered relay interface.
• What dc subsystem range is associated with Westinghouse 1C31125G02?
  It belongs to the Ovation 0–60 V dc digital-output subsystem.
• Why should auxiliary-power continuity be checked on Westinghouse 1C31125G02?
  A missing local backplane supply would prevent the connected relay modules from operating even if the 1C31122G01 commands are present.
• What distinguishes the field role of Westinghouse 1C31125G02 from 1C31122G01?
  The 1C31125G02 provides the personality and field-routing interface, while 1C31122G01 contains the active digital-output electronics.
• How can the sixteen channels of Westinghouse 1C31125G02 be verified after rewiring?
  Trace each output from its 1C31122G01 channel through the assigned relay or terminal path and prove the destination one channel at a time.
