The 3500/01-01 is the dedicated Rack Configuration Software Package that serves as the architectural blueprint for the 3500 Series Machinery Protection System. Instead of localized, manual tuning, this software delivers a centralized platform to define, archive, and deploy comprehensive operational parameters and dynamic channel attributes across the entire monitoring network. By establishing a secure digital link with the transient data interface of the rack, it allows the seamless calibration and mapping of diverse sensor inputs, spanning axial displacement, case vibration, thermal status, and shaft rotational speed.
High-Security Dual Control Interlocks
Unified One-Stop Centralized Configuration
Strict Compliance with API 670 Industry Standards
The 3500/01-01 is engineered to streamline asset lifecycle management and solve the operational friction of managing isolated I/O configurations. It aggregates individual module parameters such as 3500/42M vibration monitors, 3500/45 position monitors, and 3500/50 tachometers into a single, intuitive user interface. From this comprehensive console, technicians can systematically lock in precise alert or danger thresholds, customize bandpass filter frequencies, and program complex voting logic such as two-out-of-three for safety relays. This effectively eliminates the risk of human error and configuration drift, thereby dramatically shortening commissioning timelines in mission-critical environments.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power
Configures vibration and displacement interlock trip protection parameters for large steam turbines, generators, and feedwater pumps in supercritical and ultra-supercritical power units.
Hydroelectric Power
Sets up runout, axial displacement, high-precision speed monitoring, and main shaft eccentricity protection logic for hydro-generator units.
Nuclear Power Industry
Defines channel parameters meeting international safety standards for main coolant pumps and turbine-generator units in high-security nuclear and conventional islands.
Petroleum Refining Industry
Centrally manages alarm setpoints for heavy centrifugal compressors and high-temperature, high-pressure pumps in core units like catalytic cracking and hydrocracking.
Petrochemical Industry
Formulates protection configurations for multi-channel composite indicators of ethylene charge gas compressors, propylene compressors, and large extruder-granulator trains.
Coal Chemical Industry
Implements high-reliability relay voting logic designs for critical rotating equipment such as air separation units, coal slurry pumps, and syngas compressors.
Before downloading any configuration changes the physical key on the hardware rack must be turned to the PROGRAM position. It is highly recommended to perform this operation while the machinery is shut down or trip interlocks are bypassed to prevent false tripping or accidental shutdowns.
Always backup the latest wcf configuration file and maintain a change log after every modification. Lastly ensure that the software version is fully compatible with the firmware versions of each hardware module within the rack to avoid communication errors or configuration drift.
Alternative Names
Alternative Names
3500 01 013500-01-0135OO/O1-O13500/0I-0I
Technical notes
Technical notes
The Bently Nevada 3500/01-01 is a 3500 series rack configuration software running on Windows English operating systems that includes a configuration manual and carries no physical rack hardware entity. This program establishes data links via RS232 serial ports or TCP/IP networks and serves for non-measurement function parameter definitions and system downloads, allowing technicians to configure transducer types, scale factors, alarm setpoints, and relay voting logic matrices within the 3500/05 rack to meet API 670 machinery protection standard benchmarks in conjunction with 3500 system hardware.
3500/01-01 is the part number for the Rack Configuration Software of the Bently Nevada 3500 system, used to set, modify, and manage the parameters of all hardware modules within the 3500 monitoring rack.
What are the consequences of an incorrect configuration in 3500/01-01?
Incorrect configuration can lead to a failure in asset protection (missed-trips) or cause false alarms that trigger unplanned factory shutdowns (false-trips).
Does 3500/01-01 comply with the API 670 industry standard?
Yes. The software provides all parameter configuration logic required to fully meet the American Petroleum Institute API 670 standard, such as alarm delays, logic voting, and transducer suppression.
Can 3500/01-01 manage multiple 3500 systems centrally?
It can save and open unlimited configuration files for independent racks, and can connect to different racks individually or one-by-one via industrial Ethernet for configuration.
Does the machinery need to be shut down when changing configurations using 3500/01-01?
Some parameter modifications support online downloading, but to ensure absolute safety, it is highly recommended to update configurations while the machinery is shut down or when trip interlocks are bypassed.
