The 330908-00-67-10-01-00 features a 3/8-24 UNF thread, a 6.7-inch overall case length, and a 1.0-meter integral cable equipped with a miniature coaxial connector. It is suitable for challenging process compressor environments, offering enhanced chemical resistance and narrow side-view tracking metrics that outperform legacy 190 models. Total mechanical reliability is reinforced through the high-strength TipLoc molded tip-to-body bond and the patented CableLoc structure providing 220 N of robust pull strength. Connector protectors are highly recommended to prevent liquid ingress and safeguard electrical signal stability.
Axial (thrust) position measurements
Phase reference (Keyphasor signals)
Tachometer and zero speed measurements
The 3300 XL NSv Transducer System design allows it to replace both the 3300 RAM Transducer Systems and the 3000-series or 7000-series 190 Transducer System. Upgrades from the 3300 RAM system to the 3300 XL NSv system may use the existing probe, extension cable, and monitoring system with 3300 XL NSv Proximitor Sensor. Upgrades from the 3000-series or 7000-series Transducer System must replace the probe, extension cable, and Proximitor Sensor with NSv components.
The 3300 XL NSv Transducer System has an Average Scale Factor of 7.87 V/mm (200 mV/mil), which is the most common output for eddy current transducers. Its enhanced side view and small target characteristics give it a shorter linear range than the Bently Nevada 3300 XL-series 5 and 8 mm Transducer System. The 1.5 mm (60 mils) of linear range exceeds the linear range of the 3000-series 190 Transducer System.
The 3300 XL NSv transducer system configuration allows this specific 330908-00-67-10-01-00 reverse-mount probe to replace legacy 3300 RAM setups as well as 3000-series or 7000-series 190 transducer systems. When upgrading from a 3300 RAM system, users can retain the existing monitoring framework by integrating the 3300 XL NSv Proximitor Sensor, while transitions from 3000 or 7000 series require a complete swap to NSv components.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330908-00-67-10-01-00 Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Refining & Petrochemical Industry
Applied to high-speed, small-diameter rotors of hydrocracking and high-pressure reciprocating compressors to eliminate lateral false vibration signals from metallic casings.
Thermal Power
Deeply embedded through ultra-thick metallic walls into turbine high-pressure boiler feed pumps and high-speed auxiliary bearing housings to monitor oil film clearances.
Nuclear Power
Monitors axial thrust and displacement of large-to-medium auxiliary turbomachinery and main feedwater pumps outside the nuclear island under severe temperature differentials during continuous operation.
Hydroelectric Power
Applied to high-speed gear auxiliary drive mechanisms of large vertical hydro-generator units, where the side-view suppression blocks signal interference from adjacent gear flanks.
Pharmaceutical & Fine Chemical Industry
Penetrates the thickened explosion-proof outer walls of fully enclosed specialized high-speed centrifuges and reactor agitators to directly measure shaft runout within narrow internal spaces.
Mining & Mineral Processing Industry
Monitors bushing wear by penetrating thick walls of heavy-duty SAG mill high-load gearboxes under severe vibration and dusty process environments.
During use, due to its extended 6.7-inch case, the mounting torque must be strictly controlled to prevent long-tube deformation, and the probe tip must maintain the specified lateral clearance from internal metallic shoulders to eliminate side-view effects.
Additionally, the 1.0-meter integral cable should be supported by proper routing brackets to prevent sagging, and the ClickLoc connector must be kept absolutely clean and dry during field connection to avoid signal degradation.
The 330908-00-67-10-01-00 probe features an extended 6.7-inch fully threaded stainless steel case to penetrate thick fluid-film bearing housings. Its reinforced internal coil suppresses tip oscillations from high-velocity fluid flow. The side-view suppression eliminates lateral false vibration signals caused by nearby metallic boundaries in confined bearing areas. The attached 1.0-meter shielded coaxial cable includes a miniature terminal for lossless high-frequency signal transmission, ensuring electrical stability across severe temperature differentials during continuous operations.
It is a 3300 NSv series reverse mount proximity probe from Bently Nevada.
Which transducer system does the 330908-00-67-10-01-00 belong to?
It belongs to the 3300 XL NSv proximity transducer system, typically used in confined spaces or applications requiring narrow side-view characteristics.
What is the primary application of 330908-00-67-10-01-00?
It is primarily used for shaft vibration and axial position measurements on fluid-film bearing machines, as well as speed and Keyphasor reference measurements.
What is the compatibility of 330908-00-67-10-01-00 when replacing legacy systems?
It serves as a replacement for legacy 3300 RAM transducer systems or 3000/7000-series 190 transducer systems.
What harsh environment capabilities does the 330908-00-67-10-01-00 possess?
It is suitable for challenging process compressor environments, offering enhanced chemical resistance compared to legacy RAM probes.
