The 330905-00-18-05-02-00 is an 8 mm metric standard mount proximity probe belonging to the Bently Nevada 3300 XL NSv series. This specific configuration features an M10 by 1 thread, a 180 mm overall case length, and a 0.5 meter total cable length equipped with a miniature coaxial ClickLoc connector.
Axial (thrust) position measurements
Phase reference (Keyphasor signals)
Radial vibration and radial position measurements
The 3300 XL NSv Transducer System configuration allows it to replace both the 3300 RAM Transducer Systems and the 3000-series or 7000-series 190 Transducer System. Upgrades from the 3300 RAM system to the 3300 XL NSv system may use the existing probe, extension cable, and monitoring system with 3300 XL NSv Proximitor Sensor. Upgrades from the 3000-series or 7000-series Transducer System must replace the probe, extension cable, and Proximitor Sensor with NSv components. The 3300 XL NSv Transducer System developed around this probe has an Average Scale Factor of 7.87 V/mm, which is equivalent to 200 mV/mil, representing the most common output for eddy current transducers. Its enhanced side view and small target characteristics give it a shorter linear range than the Bently Nevada 3300 XL-series 5 and 8 mm Transducer System. The 1.5 mm of linear range, which equals 60 mils, exceeds the linear range of the 3000-series 190 Transducer System.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330905-00-18-05-02-00 Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Power Generation
Measuring the radial vibration of small steam turbines and feedwater pump shafts to prevent rotor-to-bearing rub.
Oil and Gas
Monitoring the axial displacement of natural gas pipeline compressor shafts to prevent impeller collision caused by thrust bearing wear.
Petrochemical
Performing shaft vibration measurement on high-speed centrifugal compressors or expanders to ensure the safe transport of hazardous process gases.
Chemical Industry
Monitoring the piston rod drop of reciprocating compressors to evaluate the wear state of rider rings.
Metallurgy and Iron & Steel
Measuring the relative vibration at the bearings of blast furnace blowers and large exhaust fans to avoid mechanical failures under heavy loads.
Hydroelectric Power
Serving as a keyphasor sensor in small hydro-generator sets to provide a once-per-turn pulse signal for speed and phase analysis.
When using the 330905-00-18-05-02-00 probe, it is essential to ensure the mounting hole is precisely tapped with a metric M10 by 1 right hand thread to avoid forcing and damaging the casing. Since this probe is unarmored, the cable must be routed away from sharp mechanical edges and hot moving components for protection. During installation, the proper initial gap must be set by monitoring the Proximitor output voltage to prevent the probe tip from colliding with the rotating shaft. Additionally, the gold ClickLoc connector must be kept clean, dry, and securely locked to prevent high frequency interference in signal transmission.
The 330905-00-18-05-02-00 is a 3300 NSv compact proximity transducer probe designed for tight spaces. It features an M10 by 1 standard right hand fully threaded metric casing with a length of 180 millimeters. Thanks to its unique magnetic field focusing design, it effectively eliminates side metal interference, making it specifically suitable for high precision non contact vibration or displacement measurement on equipment with small shaft diameters under 51 millimeters and narrow targets. Constructed from high strength polyphenylene sulfide and 304 stainless steel, the probe is highly resistant to corrosion and harsh environments. It comes equipped with a 0.5 meter unarmored cable and a highly reliable ClickLoc gold miniature connector, ensuring perfect interchangeability and calibration free stable operation within the 3300 XL NSv Proximitor sensor system.
It is a 3300 NSv proximity transducer probe manufactured by Bently Nevada.
What is the primary purpose of 330905-00-18-05-02-00?
It is used for non-contact measurement of radial vibration, axial displacement, or keyphasor of rotating machinery shafts (e.g., turbines, compressors).
How to properly install and use 330905-00-18-05-02-00?
Screw it forward into the mounting hole of the machine casing via the standard M10×1 thread, fix it with a locknut after adjusting the initial gap (voltage value) to the shaft surface.
What is the thread specification of 330905-00-18-05-02-00, and is it a reverse thread?
The thread specification is metric M10×1. It is a standard right-hand (forward) thread, tightened clockwise, not a reverse thread.
What is the attached cable length of 330905-00-18-05-02-00?
According to the
