Technical specifications for 330801-28-00-115-03-02
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330801-28-00-115-03-02
-
Estimated shipping dimensions:27.8x9.5x9.2cm
-
Weight:1.7 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Standoff Adapter:No standoff adapter
-
Probe Penetration:115 mm
-
Fittings Option:One M20 fitting, two plugs
-
Mounting Thread:3/4-14 NPT
-
Operating Temperature Range:-40°C to +85°C
-
Environmental Protection Rating:NEMA Type 4X and IP66
-
Nominal Linear Range:2.0 mm (80 mils)
-
Probe Tip Diameter:8 mm (0.315 in)
-
Frequency Response:0 Hz to 10 kHz
Information
Overview
Manuals
Common Applications
Product Precautions
The 330801-28-00-115-03-02 is a PROXPAC XL proximity transducer assembly. Unlike traditional separate probes, the PROXPAC XL integrates a 3300 XL 8 mm probe and a Proximitor sensor directly inside a rugged engineering plastic housing. This single-piece design removes the need for an extension cable between the probe and the sensor, allowing field wiring to connect directly from the monitoring instrument to the assembly.
- Glass/Carbon-Filled PPS Housing
- Integrated cable-free structure
- The assembly meets IP66 and Type 4X ratings for ingress protection
This design makes the PROXPAC XL Assembly a completely self-contained proximity probe system, and eliminates the need for an extension cable between the probe and its associated Proximitor sensor. It also eliminates the need for a separate Proximitor housing, as the field wiring connects directly between the monitors and PROXPAC XL Assemblies.
The PROXPAC XL housing is made of Polyphenylene Sulfide (PPS), which is an advanced, molded thermoplastic. This material replaces the steel and aluminum in previous housings offered in the Bently Nevada product line. It also incorporates glass and conductive fibers in the PPS to strengthen the housing and more effectively dissipate electrostatic charges. The PROXPAC XL housing is rated for Type 4X and for IP66 environments and provides extra protection in severe environments.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330801-28-00-115-03-02 PROXPAC Proximity Transducer Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas Pipeline Transportation
Used on compressors at outdoor midstream stations to monitor shaft radial vibration and prevent rotor-to-bearing rubs. (Equipment: Pipeline Gas Compressor).
Refining & Petrochemical Industry
Utilizes the corrosion-resistant PPS housing to protect internal electronics while tracking axial displacement in sour gas refining areas. (Equipment: Reforming Hydrogen Compressor).
Thermal Power Generation
Deployed in high-temperature, high-steam zones near boilers to provide speed logging and Keyphasor phase references. (Equipment: Boiler Feed Pump Turbine).
Hydropower Generation
Operates in damp underground dam galleries to measure radial shaft play caused by uneven hydraulic forces. (Equipment: Vertical Hydro-generator Set).
Air Separation & Industrial Gas
Provides non-contact clearance tracking on the drive end of expanders to prevent high-speed bearing failures. (Equipment: Cryogenic Turbo-expander).
Coal Chemical & Gasification Industry
Monitors oil film thickness and static shaft centerline plots on large blowers in outdoor environments heavy with coal dust. (Equipment: Gasification Air Blower) .
Set the initial gap at the linear midpoint using internal adjustment mechanisms during installation to establish the precise DC gap voltage, mitigating signal clipping from large axial shaft movement.
Alternative Names
330801 28 00 115 03 02
330801-28-00-115-03-O2
330801-28-00-115-O3-02
330801-28-00-1I5-03-02
330801-28-00-I15-03-02
330801-28-0O-115-03-02
330801-28-O0-115-03-02
3308O1-28-00-115-03-02
33080I-28-00-115-03-02
33O801-28-00-115-03-02
33O8O1-28-OO-115-O3-O2
33080I-28-00-II5-03-02
33O8OI-28-OO-II5-O3-O2
Technical notes
The system delivers IP66 protection, but field wiring requires proactive sealing measures to prevent ambient moisture migration through conduits into the PROXPAC housing.
FAQ View All FAQ
-
What device is 330801-28-00-115-03-02?It is a Bently Nevada PROXPAC XL proximity transducer assembly.
-
What is the primary use of 330801-28-00-115-03-02?It tracks shaft radial vibration, axial displacement, axial position, and rotational speed on rotating industrial machinery like compressors, pumps, and fans.
-
How do you install the 330801-28-00-115-03-02 probe?Thread the assembly directly into the machine bearing housing or mounting port, adjust the physical gap between the probe tip and the shaft, and lock it down with the jam nut.
-
