Technical specifications for 330130-080-01-CN
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330130-080-01-CN
-
Estimated shipping dimensions:30.5x32.5x4.5cm
-
Weight:0.98 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Minimum Bend Radius:25.4 mm
-
Pull Strength (Cable to Probe Junction):330 N
-
Insulation/Dielectric Standard:75 Ω triaxial cable with FEP insulation
-
Output Resistance:50 Ω
-
Cable Length Option:8.0 meters (26.2 feet)
-
Connector Protector and Cable Option:Armored cable
Information
Overview
Manuals
Common Applications
Product Precautions
The 330130-080-01-CN is a standard extension cable for the 3300 XL series 8 mm eddy current transducer system. Serving as the primary signal transmission medium, this cable establishes a high-frequency path between the field probe tip and the Proximitor sensor to ensure accurate measurement of displacement and vibration.
- One 3300 XL 8 mm probe
- One 3300 XL extension cable
- One 3300 XL Proximitor Sensor
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable4 with other non XL 3300 series 5 mm and 8 mm transducer system components5. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330130-080-01-CN Standard Extension Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Nuclear Power
It is installed on main steam turbines, main feedwater pumps, and condensate pumps outside the nuclear island to continuously monitor rotor bearing conditions, ensuring long-term stable operation under stringent safety standards.
Hydroelectric Power
It measures the swing of large hydro-turbine generator units and the axial displacement of thrust bearings, preventing structural damage caused by hydraulic imbalance or severe load fluctuations.
Oil & Gas
It is deployed on large crude oil transfer pumps and high-pressure water injection pumps on offshore drilling platforms and onshore gathering stations, providing real-time shaft alignment monitoring to prevent sudden equipment downtime in harsh environments.
Petroleum Refining & Refineries
It monitors the journal bearing vibration of fluid catalytic cracking units and various high-temperature, high-pressure hydrocarbon pumps, eliminating flammable and explosive leakage risks caused by abnormal machinery vibration.
Iron & Steel Metallurgy
It is utilized in blast furnace blowers, Top Gas Recovery Turbine power generation units, and large converter oxygen compressors, ensuring that these critical air and power supply systems do not trip due to excessive vibration.
The impedance and capacitance of this 8-meter cable are strictly calibrated. Field cutting, splicing, or terminating with non-standard connectors is prohibited, as it causes impedance mismatch, leading to uncorrectable thermal drift and measurement errors. Due to internal core wire manufacturing constraints, the static bend radius within the armor must not be less than 25.4 mm (1 inch) to prevent internal capacitance changes or coaxial shield damage.
Alternative Names
330130 080 01 CN
330130-080-01-BR
330130-080-01-RU
330130-080-O1-CN
330130-08O-01-CN
330130-O80-01-CN
330130-0B0-01-CN
33013O-080-01-CN
330I30-080-01-CN
33O130-080-01-CN
33O13O-O8O-O1-CN
330I30-080-0I-CN
33OI3O-O8O-OI-CN
33O13O-OBO-O1-CN
330I30-0B0-0I-CN
33OI3O-OBO-OI-CN
Technical notes
It features a 75-ohm triaxial cable structure with fluorinated ethylene propylene insulation. Equipped with integrated ClickLoc coaxial connectors and a CableLoc design, the assembly provides connector tensile strength up to 330 Newtons.
FAQ View All FAQ
-
Do you offer global delivery services?Yes. We ship globally, and we are able to quickly deliver parts globally to any corner of the world. Unless otherwise specified, we will ship your order via (DHL). We can also ship through FedEx, UPS, and TNT. We can also use your account.
-
How many parts do you have in stock?We have an extensive stock base consisting of ten thousands of new and discontinued automation parts including those from leading manufacturers such as:Control Systems (DCS, PLC, CNC) ,Panel Controllers,HMI and Display Panels,Drives,Encoders and Resolvers,Power Supplies.
-
What is 330130-080-01-CN?It is an eddy current Proximitor Sensor (signal amplifier).
-
How is 330130-080-01-CN used?It is installed on a DIN rail inside a field instrument box near the machinery. The input connects to the probe via an extension cable, and the output sends voltage signals to a monitor (like the Bently 3500) or PLC/DCS via a 3-wire cable.
-
What probe and cable must be paired with 330130-080-01-CN?It must be paired with a 3300 XL 8mm series probe with an integral 1.0m cable, and an 8.0m extension cable, ensuring the total cable length of the eddy current system is strictly 9.0 meters.
