Technical specifications for 330730-080-02-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330730-080-02-00
-
Estimated shipping dimensions:20.5x22.4x3.3cm
-
Weight:0.35 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Cable Length Option:8.0 meters (26.2 feet)
-
Connector and Cable Option:Standard cable with connector protector
-
Operating and Storage Temperature:-52°C to +177°C
-
Extension Cable Material:75 Ω triaxial
-
Extension Cable:45 g/m (0.5 oz/ft)
Information
Overview
Manuals
Common Applications
Product Precautions
The 330730-080-02-00 belongs to the 3300 XL 11 mm Proximity Transducer System, which delivers a 3.94 V/mm (100 mV/mil) output for non-contacting vibration and displacement measurements on fluid-film bearing machines. The large 11 mm tip enables this transducer system to achieve a longer linear range compared to the standard 3300 XL 8 mm Transducer System.
- Axial (thrust) position measurements
- Tachometer and zero speed measurements
- Rod position or rod drop measurements on reciprocating compressors
Additionally, the configuration of the hosting monitoring system must be updated. If utilizing a 3500 Monitoring System, an updated version of the configuration software that lists the 3300 XL 11 mm Transducer System as a compatible option is required. Existing legacy 3300 Monitoring Systems may require a hardware modification to match the system impedance.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330730-080-02-00 Extension Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Power Generation Industry
Transmitting differential expansion (DE) and axial thrust position signals from large steam turbines in thermal power plants.
Hydroelectric Power Industry
Relaying low-frequency radial vibration and shaft runout data from massive vertical water turbine-generator units.
Petrochemical Industry
Delivering continuous axial position data from large-scale ethylene compressors to protect against catastrophic thrust bearing wear.
Iron & Steel Metallurgy Industry
Routing vibration signals from blast furnace axial blowers where the stainless steel armor protects the cable from slag and mechanical impacts.
Air Separation Industry
Carrying critical displacement data from high-power main air compressors used in large oxygen generation plants.
Pulp & Paper Manufacturing Industry
Monitoring large differential expansions on high-speed steam-heated drying cylinders and vacuum exhaust blowers.
When using the 330730-080-03-05 extension cable, this 8-meter cable pairs with a 1.0-meter 11mm probe to complete a 9-meter total system length. During installation, maintain a bend radius greater than 25.4 mm, lock the ClickLoc connectors, and adhere to intrinsic safety wiring standards in hazardous areas.
Alternative Names
330730 080 02 00
330730-080-02-05
330730-080-02-CN
330730-080-02-BR
330730-080-02-RU
330730-080-02-0O
330730-080-02-O0
330730-080-O2-00
330730-08O-02-00
330730-O80-02-00
33073O-080-02-00
33O730-080-02-00
Technical notes
The 330730-080-02-00 features gold-plated brass ClickLoc™ quick connectors on both ends. These connectors are designed with a unique anti-loosening locking mechanism capable of enduring long-term, high-frequency heavy vibration generated by large industrial machinery, while the heavy gold plating ensures ultra-low contact resistance for radio frequency (RF) signal transmission.
FAQ View All FAQ
-
What is the cable length of Bently Nevada 330730-080-02-00?The cable length for this model is 8.0 meters (26.2 feet).
-
What is the cable type of Bently Nevada 330730-080-02-00?This model is a standard cable.
-
What are the joint protectors and cable options for Bently Nevada 330730-080-02-00?This model comes with a joint protector.
-
