      330130-045-00-00

      3300 XL 8 mm Standard Extension Cable
      In Stock
      Ships by Wednesday, September 23
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330130-045-00-00 is a 4.5 m standard extension cable for a 3300 XL 8 mm proximity transducer system. It connects the probe lead to the matched Proximitor Sensor while preserving the engineered system length.

      Ask our team:

      Get a quick price for： 330130-045-00-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330130-045-00-00

      Technical specifications for 330130-045-00-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330130-045-00-00
      • Estimated shipping dimensions:
        20x20x1.5cm
      • Weight:
        0.16 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Cable series:
        330130
      • Cable length:
        4.5 m (14.8 ft)
      • Cable length tolerance:
        +20%, -0%
      • Cable type:
        Standard extension cable
      • Cable construction:
        75 Ohm triaxial
      • Insulation:
        Fluoroethylene propylene (FEP)
      • Armor option:
        None
      • FluidLoc option:
        None
      • Connector protector:
        None
      • Agency approval option:
        Not required
      • Nominal core resistance:
        0.99 +/- 0.15 Ohm
      • Nominal jacket resistance:
        0.30 +/- 0.06 Ohm
      • Extension-cable capacitance:
        69.9 pF/m typical
      • Minimum bend radius:
        25.4 mm (1.0 in)
      • Operating and storage temperature:
        -52 to +177 degC
      • Cable outside diameter:
        3.7 mm maximum
      • Connector configuration:
        Miniature male and female coaxial
      • Connector material:
        Gold-plated brass or beryllium copper
      • Maximum connector torque:
        0.565 N m
      • Cable mass:
        34 g/m
      • Matched total system lengths:
        5 m or 9 m
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330130-045-00-00 is a 4.5 m standard extension cable for a 3300 XL 8 mm proximity transducer system. It connects the probe lead to the matched Proximitor Sensor while preserving the engineered system length.
      • Extends the probe connection between the machine and the Proximitor Sensor
      • Carries the triaxial proximity signal through a matched 3300 XL loop
      • Supports routing from the bearing housing to an accessible monitoring enclosure
      • Maintains the electrical length required by the selected 5 m or 9 m transducer system

      330130-045-00-00 installs with 3300 XL 8 mm proximity probe, 3300 XL 8 mm Proximitor Sensor, ClickLoc mating connectors, compatible machinery-protection monitor channel in an engineered 3300 XL 8 mm Proximity Transducer System configuration.

      The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this 3300 xl 8 mm standard extension cable.

      Important Notice: Confirm the complete 330130-045-00-00 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.

      Apter Power 330130-045-00-00 Manuals and Guides
      Apter Power 330130-045-00-00 Product Technical Reference PDFBently Nevada 330130-045-00-00 Official Manual PDF
      The first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
      Bearing-housing cable extensionExtends the probe connection between the machine and the Proximitor Sensor
      Remote Proximitor Sensor mountingCarries the triaxial proximity signal through a matched 3300 XL loop
      Radial vibration transducer routingSupports routing from the bearing housing to an accessible monitoring enclosure
      Axial-position probe connectionMaintains the electrical length required by the selected 5 m or 9 m transducer system
      Read the applicable Bently Nevada installation instructions before work. Verify 330130-045-00-00 and the installed 3300 XL 8 mm Proximity Transducer System configuration.
      1Verify the complete 330130-045-00-00 marking and cable length before installation.
      2Isolate the connected protection channel before separating either coaxial connector.
      3Keep connector interfaces clean and dry; do not use an unapproved solvent on the FEP cable.
      4Maintain the published bend radius throughout trays, glands and enclosure entries.
      5Do not substitute an armored, FluidLoc or connector-protector execution for this standard cable without engineering review.
      6Match the probe and extension-cable lengths to the 5 m or 9 m Proximitor Sensor calibration.
      7Secure the cable so machine vibration cannot load the miniature coaxial connectors.
      8Verify bias voltage, static gap, polarity and dynamic response before restoring alarm service.

      Technical notes

      Technical notes

      Route 330130-045-00-00 without violating the minimum bend radius, then finger-tighten the two 3300 XL click connectors and secure them against vibration. Confirm that probe length plus extension-cable length equals the Proximitor Sensor system length before gap and channel testing.

      FAQS

      • What length does 330130-045-00-00 provide?
        Ordering option 045 specifies a 4.5 m standard extension cable.
      • Does 330130-045-00-00 include armor or FluidLoc construction?
        No. Option 00 specifies standard cable without armor, FluidLoc construction or a connector protector.
      • Which system lengths can use 330130-045-00-00?
        Choose the probe and Proximitor Sensor so the combined probe-plus-extension length matches the engineered 5 m or 9 m system.
      • How tightly should the connectors on 330130-045-00-00 be assembled?
        Two 3300 XL gold click-type connectors are assembled finger tight; do not apply the maximum connector torque as a routine tightening target.
      • What bend control is required for 330130-045-00-00?
        Maintain at least the published 25.4 mm bend radius at trays, cabinet entries and service loops.
      • Can 330130-045-00-00 replace an armored extension cable?
        Only after engineering confirms that the standard unarmored option is acceptable for the installed mechanical protection and routing conditions.
      • What resistance checks can be made on 330130-045-00-00?
        Compare core and jacket continuity with the official nominal values for the 4.5 m cable, using test equipment that will not damage the proximity circuit.
      • What commissioning checks follow installation of 330130-045-00-00?
        Verify connector seating, total system length, bias voltage, static gap, polarity and dynamic channel response.
