The 330105-02-12-10-02-00 is delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability.
Reverse Mount Versatility
High-Pressure Fluid Sealing
Extended Temperature Performance
All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330105-02-12-10-02-00 3300 XL 8 mm Reverse Mount Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Petrochemical Refineries
Used for monitoring centrifugal compressors and high-speed turbines. The probe tip and case are sealed against liquids and rated to 483 kPa (70 psi) for reliable performance in hydrocarbon environments.
Power Generation
Applied in steam turbine generator sets for vibration and thrust position measurements. It provides high-accuracy sensing within an extended operating temperature range from -52°C to +177°C.
Natural Gas
Utilized in gas transmission compressors and mechanical drive turbines. The reverse mount design allows for integration into 330400 or 330490 housing assemblies for external mounting on critical machinery.
Water Processing
Deployed in large-scale industrial pumps and cooling tower fans. The system provides superior mechanical robustness and resistance to moisture, ensuring stable shaft displacement monitoring in humid conditions.
Mining Operations
Implemented in heavy-duty gearboxes and crushing equipment. It tracks radial vibration and axial position under high-vibration conditions, maintaining a nominal Average Scale Factor of 7.87 V/mm (200 mV/mil).
Maritime Propulsion
Used for monitoring propulsion shafting and auxiliary machinery in marine vessels. The 3300 XL components are designed for high-density installations and offer improved RFI/EMI immunity for complex electronic environments.
An extended temperature range (ETR) probe and ETR extension cable are available for applications in which either the probe lead or extension cable may exceed the standard 177°C (350°F) temperature specification. The ETR probe has an extended temperature rating for up to 218°C (425°F). The ETR extension cable rating is up to 260°C (500°F). Both the ETR probe and cable are compatible with standard temperature probes and cables, for example, you can utilize an ETR probe with the 330130 extension cable. The ETR system uses the standard 3300 XL Proximitor Sensor. Note that when you use any ETR component as part of your system, the ETR component limits the system accuracy to the accuracy of the ETR system.
What are the specific configuration parameters for the 330105-02-12-10-02-00 reverse mount probe?
This model features a 3/8-24 UNF thread, a 12-inch total length, a 1.0-meter total system length, and includes a miniature coaxial connector with no connector protector or armor.
What is the primary application for the reverse mount design of the 330105-02-12-10-02-00?
Reverse mount probes are designed to be used with the 3300 XL extension cable and are typically installed in 330400 or 330490 housing assemblies for external mounting.
What is the specified Average Scale Factor (ASF) for the 330105-02-12-10-02-00 system?
The system has a nominal Average Scale Factor of 7.87 V/mm (200 mV/mil) when measured over the 2.0 mm (80 mil) linear range using a 4140 steel target.
How does the 1.0-meter system length of 330105-02-12-10-02-00 affect its compatibility?
As a 1.0-meter system, the 330105-02-12-10-02-00 probe must be used with a 3300 XL Proximitor Sensor specifically configured for a 1.0-meter total system length.
What are the environmental sealing and pressure ratings for the 330105-02-12-10-02-00 probe tip?
The probe tip and case are sealed against liquids and designed to withstand pressures up to 483 kPa (70 psi) between the probe tip and case.
