      Bently Nevada 330105-02-12-05-02-00
      Bently Nevada 330105-02-12-05-02-00
      Bently Nevada 330105-02-12-05-02-00
      Bently Nevada 330105-02-12-05-02-00
      Bently Nevada 330105-02-12-05-02-00
      Bently Nevada 330105-02-12-05-02-00
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330105-02-12-05-02-00

      3300 XL 8 mm Reverse-Mount English Proximity Probe
      In Stock

      Product Describe：

      Bently Nevada 330105-02-12-05-02-00 is a reverse-mount 3/8-24 UNF 3300 XL 8 mm probe with the fixed 0.2 in unthreaded and 1.2 in case configuration, plus a 0.5 m total lead. It uses a standard ClickLoc connector without protector and has no agency approval.

      Ask our team:

      Get a quick price for： 330105-02-12-05-02-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330105-02-12-05-02-00

      Technical specifications for 330105-02-12-05-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330105-02-12-05-02-00
      • Estimated shipping dimensions:
        1.2x1x62cm
      • Weight:
        0.04 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Mounting style:
        Reverse mount
      • Probe thread:
        3/8-24 UNF
      • Unthreaded length:
        0.2 in
      • Overall case length:
        1.2 in
      • Total length:
        0.5 m
      • Connector option:
        Standard ClickLoc without protector
      • Agency approval:
        None
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330105-02-12-05-02-00 is a reverse-mount 3/8-24 UNF 3300 XL 8 mm probe with the fixed 0.2 in unthreaded and 1.2 in case configuration, plus a 0.5 m total lead. It uses a standard ClickLoc connector without protector and has no agency approval.
      • Reverse-mount English probe
      • Fixed 0.2 in by 1.2 in case geometry
      • 0.5 m integral lead
      • 2 mm calibrated linear-range family

      Install 330105-02-12-05-02-00 from the reverse side of the approved bracket and use the reverse-mount tightening limit. Pair its 0.5 m lead with the exact extension cable and Proximitor Sensor required for the documented 5 m or 9 m system.

      Important Notice: Confirm quotation scope, physical marking, included accessories and installed-system compatibility before work.

      Apter Power 330105-02-12-05-02-00 Manuals and Guides
      Apter Power 330105-02-12-05-02-00 Product Technical ReferenceBently Nevada 3300 XL 8 mm Proximity Transducer System Datasheet 141194 Rev. AM

      Important Notice: The first document is an Apter Power model-specific technical reference; the second link is the unmodified official manufacturer publication.

      Reverse-side bearing bracket
      Fits a documented bracket accessed from the rear mounting side.
      Radial shaft vibration
      Measures dynamic shaft motion through a matched 8 mm transducer loop.
      Static shaft position
      Reports non-contact position inside the calibrated linear range.
      Controlled installed-base replacement
      Restores the exact short reverse-mount probe identity.
      Read the applicable Bently Nevada documentation before work. Verify 330105-02-12-05-02-00 from the physical marking and the installed system record.
      1
      Verify the complete 330105-02-12-05-02-00 marking and retain existing product records.
      2
      Confirm the 0.2 in unthreaded and 1.2 in case dimensions fit the reverse-mount bracket.
      3
      Keep 3/8-24 thread engagement within 0.563 in.
      4
      Use the 7.5 N m reverse-mount torque limit rather than the forward-mount value.
      5
      Protect the option-02 connector because no connector protector is supplied.
      6
      Use the correct extension cable to complete the 0.5 m lead to the selected system length.
      7
      Verify 15.2 mm target size, shaft diameter and probe separation.
      8
      Record static gap, dynamic response, diagnostics and final protection-channel proof.

      Technical notes

      Technical notes

      Install 330105-02-12-05-02-00 from the reverse side of the approved bracket and use the reverse-mount tightening limit. Pair its 0.5 m lead with the exact extension cable and Proximitor Sensor required for the documented 5 m or 9 m system.

      FAQS

      • Why is the mounting torque for 330105-02-12-05-02-00 lower than a forward probe?
        It is a reverse-mount design; the datasheet specifies a 7.5 N m case-torque limit for reverse mounting.
      • What fixed case geometry identifies 330105-02-12-05-02-00?
        The fixed reverse-mount code specifies 0.2 in unthreaded length and a 1.2 in overall case.
      • Which thread engagement is safe for 330105-02-12-05-02-00?
        For the 3/8-24 case, the published maximum engagement is 0.563 in.
      • How is the 0.5 m lead of 330105-02-12-05-02-00 used in a 5 m loop?
        Pair it with the matching 4.5 m extension cable and a 5 m Proximitor Sensor.
      • What extension cable completes 330105-02-12-05-02-00 for a 9 m system?
        Use the matching 8.5 m extension cable with the 0.5 m probe and 9 m sensor.
      • Where should 330105-02-12-05-02-00 be biased for radial-vibration service?
        Use the published approximately -9 V or 1.27 mm recommended gap, then confirm the installed linear range.
      • What probe spacing prevents cross-talk around 330105-02-12-05-02-00?
        Maintain at least 40 mm axial separation or 38 mm radial separation between probes.
      • May 330105-02-12-05-02-00 be represented as an approved-area probe?
        No. Its final 00 ordering option specifies no agency approval.
