      330104-13-20-10-02-00

      Armored Proximity Probe
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      A 1.0 m 3300 XL 8 mm M10 x 1 proximity probe with 130 mm unthreaded length, 200 mm case length, miniature coaxial clickloc without protector and the 00, not required selection.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330104-13-20-10-02-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330104-13-20-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330104-13-20-10-02-00
      • Estimated shipping dimensions:
        20.5x22.4x3.3cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        330104
      • Probe case thread:
        M10 x 1
      • Unthreaded length:
        130 mm
      • Case length:
        200 mm
      • Total probe length:
        1.0 m
      • Cable construction:
        75 ohm triaxial FEP with stainless-steel armor
      • Connector selection:
        Miniature coaxial ClickLoc without protector
      • Approval selection:
        00, not required
      • Linear range:
        2.0 mm (80 mils)
      • Recommended gap:
        About 1.27 mm at -9 Vdc
      • Scale factor:
        7.87 V/mm (200 mV/mil)
      • Frequency response:
        0 to 10 kHz
      • Probe tip:
        8.0 mm PPS
      • Minimum bend radius:
        25.4 mm
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330104-13-20-10-02-00 is a 3300 XL 8 mm M10 x 1 armored probe with 200 mm case length and 1.0 m total probe length.
      • M10 x 1 case thread
      • 130 mm unthreaded length
      • 200 mm case length
      • Miniature coaxial ClickLoc without protector

      This armored probe is the sensing end of a matched 3300 XL 8 mm transducer chain. Pair its probe-plus-extension length with the selected Proximitor Sensor, preserve the documented connector arrangement and verify the target material before calibration.

      Important Notice: Verify the complete 330104-13-20-10-02-00 marking, matched electrical length, connector selection and 00, not required record before installation; do not borrow another suffix.

      Bently Nevada 330104-13-20-10-02-00 Manuals & Downloads
      Bently Nevada 330104-13-20-10-02-00 Manufacturer Datasheet Excerpt (PDF)Bently Nevada 330104-13-20-10-02-00 Installation & Commissioning Guide (PDF)

      The manufacturer excerpt preserves selected original datasheet pages and is not the complete publication. The installation guide is an Apter Power field workflow for controlled restoration and commissioning.

      Radial vibration
      Measures shaft motion in a correctly engineered 3300 XL 8 mm channel.
      Axial position
      Supports static position measurement within the documented linear range.
      Phase reference
      Can form the probe end of a compatible phase-reference channel.
      Exact suffix renewal
      Restores the 330104-13-20-10-02-00 execution without borrowing another probe geometry.
      Bently Nevada 330104-13-20-10-02-00 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Read the full 330104-13-20-10-02-00 marking before removing the installed probe.
      2
      Record probe gap, target material, runout and monitor configuration before service.
      3
      Confirm M10 x 1, 130 mm unthreaded length and 200 mm case length.
      4
      Keep the cable route within the 25.4 mm minimum bend radius and protect the clickloc connector.
      5
      Join clean mating connectors finger tight; 0.565 N m is a maximum limit, not a tightening target.
      6
      Match probe-plus-extension length to the Proximitor Sensor electrical-length selection.
      7
      Restore the documented gap voltage and verify static and dynamic response before release.
      8
      Confirm the ordered 00, not required marking instead of assigning approval from the family name.

      Technical notes

      For 330104-13-20-10-02-00, retain the exact ordered suffix, installed measurement-chain record and witnessed acceptance result. Return the channel to service only after the model-specific electrical and mechanical checks pass.

      FAQ View All FAQ

      • What extended-reach geometry is ordered in Bently Nevada 330104-13-20-10-02-00?
        The model specifies a 130 mm unthreaded reach and a 200 mm M10 x 1 case.
      • How should the long unthreaded section of Bently Nevada 330104-13-20-10-02-00 be supported?
        The installation should provide adequate clearance and avoid side loading the 130 mm unthreaded portion while securing the threaded case.
      • Why can a 230 mm or 130 mm case not replace Bently Nevada 330104-13-20-10-02-00 by family number alone?
        Its exact 20 case code calls for 200 mm; using another 330104 case length would change probe reach and bracket position.
      • What protection does the probe cable of Bently Nevada 330104-13-20-10-02-00 provide?
        The 330104 construction uses 75 ohm triaxial FEP cable with stainless-steel armor and a 1.0 m total probe length.
      • Which connector detail must be checked before mating Bently Nevada 330104-13-20-10-02-00?
        Verify the miniature coaxial ClickLoc option without connector protector and use the corresponding clean mating connection.
      • What target setup supports the documented linear performance of Bently Nevada 330104-13-20-10-02-00?
        Set the static gap near 1.27 mm at about -9 Vdc, then verify response through the documented 2.0 mm system linear range.
      • Which sensitivity is expected from the matched system containing Bently Nevada 330104-13-20-10-02-00?
        The nominal scale factor is 7.87 V/mm, equivalent to 200 mV/mil, for the complete correctly matched system.
      • How is the final 00 on Bently Nevada 330104-13-20-10-02-00 documented?
        It is the not-required approval selection; record that exact option instead of applying a multiple-approval designation.
