      330104-00-07-50-02-00

      Armored Metric Eddy-Current Proximity Probe
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      Bently Nevada 330104-00-07-50-02-00 is a armored metric eddy-current proximity probe. This metric probe combines a threaded sensing case with an armored five-metre integral cable.
      • Manufacturer part number
        330104-00-07-50-02-00
      • Shipping
        Swift global dispatch
      • Condition
        New, original product
      • Shipping size (est.)
        28cm x 28cm x 3cm
      • Country of Origin
        USA

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330104-00-07-50-02-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 0

        Review your reference

        Send the complete 330104-00-07-50-02-00 reference, label photographs and required quantity. Include the installed interface and hardware revision.

      • 1

        Confirm the offer

        Review the offered 330104-00-07-50-02-00 execution, New, original product condition and itemized accessories against the retained application.

      • 2

        Arrange dispatch

        Confirm quantity, dispatch date, lead-time start and delivery details in the quotation.

      • Match the complete marking

        Compare the full Bently Nevada 330104-00-07-50-02-00 marking, hardware execution and mating interfaces with the installed position before approving a replacement.

      • Check the offered item before ordering

        Request clear photographs of the offered 330104-00-07-50-02-00 marking and connections. Ask the maintenance team to compare them with the applicable Bently Nevada instructions and the installed circuit or system design.

      Technical specifications for 330104-00-07-50-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330104-00-07-50-02-00
      • Weight:
        0.54 kg
      • Tariff Code:
        8537101190
      • Probe tip:
        8 mm
      • Mounting thread:
        M10 x 1
      • Unthreaded length:
        0 mm
      • Case length:
        70 mm
      • Integral lead:
        5.0 m
      • Cable execution:
        Armored standard cable
      • Connector:
        Miniature coaxial ClickLoc
      • Matched-system scale factor:
        7.87 V/mm (200 mV/mil)
      View as PDF Ask for Quote

      Information

      Overview Downloads Applications / Compatibility Product Precautions
      • The long lead forms the electrical connection to the matching five-metre XL 8 mm Proximitor sensor, reducing the need for an intermediate extension junction in that arrangement.
      Connection arrangement: long integral lead to the matching conditioner
      Mechanical protection: armored cable at the machine interface
      Calibration boundary: target, gap and conditioner remain a matched system
      The five-metre probe execution is designed for the corresponding five-metre system. Adding an extension simply to change the route would alter the total electrical length and is not a valid substitute for selecting the correct transducer configuration.

      The measurement output belongs to the complete system and its calibrated target conditions. Armor protects the cable execution but does not establish fluid-blocking performance. Gap, target material and monitor scaling must be checked separately from the mechanical cable protection.

      Use the M10 mounting interface in a mechanically compatible measurement position. Use the armored execution within the approved route and support arrangement. No. The stated scale factor belongs to the matched probe and Proximitor system under its calibration conditions. The bare probe is part of that sensing circuit.
      Controller platform reference: 3300 XL 8 mm transducer system. Use the applicable installation instructions and approved system design.
      Original Bently Nevada technical pages applicable to 330104-00-07-50-02-00 and its stated system context. Installation topics include: verify the five-metre configuration; prepare the metric mounting; route the integral armored lead.
      Original manufacturer pages retain their technical context. Use the Apter Power guide with the applicable manufacturer instructions and approved installation design.
      System and supply context: The 330104-00-07-50-02-00 belongs to the 3300 XL 8 mm transducer system arrangement with its specified field interfaces.

      Application scope: Applications must satisfy the module or transducer boundary and the actual controller, receiver or target conditions.
      Prepare Bently Nevada 330104-00-07-50-02-00 for its configured installation using these checks.
      Verify the five-metre configuration

      Record the selected conditioner length and complete probe marking. Remove any assumption that the old extension remains required with the new integral lead.

      Prepare the metric mounting

      Inspect the M10 x 1 interface and target location. Preserve adequate adjustment while avoiding damage to the sensing tip.

      Route the integral armored lead

      Support the cable through the machine exit and enclosure route. Do not shorten, splice or sharply load the integral lead to fit the path.

      Check gap and proportional response

      Use the applicable target and controlled displacement reference. Compare static gap voltage and change in output before restoring monitor settings.

      Release the matched channel

      Verify the intended scale, polarity and machinery-monitoring response. Retain the final probe and conditioner identities with the maintenance record.

      Control the return to service

      Keep the affected process in its approved maintenance state until field indications and the intended control or monitoring response have both been checked.

      Alternative Names

      Bently Nevada 330104-00-07-50-02-00

      Technical notes

      Configuration scope: System ratings apply to the complete matched chain; mechanical and cable selections apply to 330104-00-07-50-02-00.

      Engineering acceptance: The intended armored metric eddy-current proximity probe function must be accepted with its actual mating interfaces and configured system. Support the cable through the machine exit and enclosure route. Do not shorten, splice or sharply load the integral lead to fit the path.

      FAQ View All FAQ

      • Why should 330104-00-07-50-02-00 not receive an extra extension merely to increase reach?
        Its five-metre lead is intended for a five-metre Proximitor system. An added extension changes total electrical length and invalidates that selected combination.
      • Does armor make 330104-00-07-50-02-00 a FluidLoc probe?
        No. Armor is mechanical protection; fluid-blocking cable construction is a separate execution. Do not infer an oil-leak barrier from the presence of armor.
      • How can 330104-00-07-50-02-00 lose calibration even when its mechanical gap is unchanged?
        A mismatched conditioner, changed electrical path or different target material can alter the output. Check the complete transducer chain before adjusting the probe.
      • Why should 330104-00-07-50-02-00 connector condition be inspected before changing alarm settings?
        A poor coaxial connection can create unstable gap or vibration indications. Correct the physical signal path before modifying protection thresholds.
      • What should be checked when routing the long integral lead of 330104-00-07-50-02-00?
        Protect the cable from crushing and abrasion while providing support that avoids pulling at the probe. Routing convenience must not lead to cutting or splicing the calibrated lead.
      • Can 330104-00-07-50-02-00 system sensitivity be applied to the bare probe output?
        No. The stated scale factor belongs to the matched probe and Proximitor system under its calibration conditions. The bare probe is part of that sensing circuit.
      • Why is a controlled displacement test useful after installing 330104-00-07-50-02-00?
        It checks the full chain’s output direction and scale rather than only one static gap voltage. This helps reveal component or target mismatches before machinery operation.
      • How should 330104-00-07-50-02-00 be accepted when replacing a shorter-lead probe arrangement?
        Reconcile the entire electrical-length configuration and conditioner selection. A probe with a longer integral lead is not equivalent to the old probe plus an arbitrary extension.
