330101-00-28-10-02-CN

3300 XL 8 mm Proximity Probe
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

Bently Nevada 330101-00-28-10-02-CN is a 3300 XL 8 mm proximity probe with 3/8-24 UNF case thread and without armor. It is the probe segment of a matched noncontact shaft measurement chain.
  • Manufacturer part number
    330101-00-28-10-02-CN
  • Shipping
    Swift global dispatch
  • Condition
    New, original product
  • Shipping size (est.)
    1.5cm × 1.3cm × 121cm
  • Country of Origin
    USA
Get a quick price for 330101-00-28-10-02-CN
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 0

    Review your reference

    Send the complete 330101-00-28-10-02-CN marking and installed-system identifiers for technical review.

  • 1

    Confirm the offer

    Review the exact offered unit, included items, condition and quantity in the quotation.

  • 2

    Arrange dispatch

    Confirm the accepted quantity and destination so dispatch can be arranged.

  • Match the complete marking

    Compare every order group of 330101-00-28-10-02-CN with the installed item and the applicable Bently Nevada system documentation.

  • Check the offered item before ordering

    Request photos of the offered 330101-00-28-10-02-CN and included items. Have the maintenance team compare them with the installed equipment and applicable Bently Nevada documentation.

Technical specifications for 330101-00-28-10-02-CN

  • Manufacturer:
    Bently Nevada
  • Product Category:
    Machinery Monitoring Systems
  • Spare Part Number:
    330101-00-28-10-02-CN
  • Weight:
    0.05 kg
  • Tariff Code:
    8537101190
  • Probe system:
    3300 XL 8 mm
  • Probe tip family:
    8 mm
  • Case thread:
    3/8-24 UNF
  • Cable armor:
    without armor
  • Unthreaded length:
    0.0 in
  • Overall case length:
    2.8 in
  • Integral probe length:
    1.0 m
  • Cable construction:
    standard
  • Connector:
    Miniature coaxial ClickLoc, without connector protector
  • Approval option:
    CN country-specific option; confirm label
  • Matching sensor:
    3300 XL 8 mm Proximitor Sensor

Information

Overview Downloads Applications / Compatibility Product Precautions
  • The 3300 XL 8 mm probe senses shaft-to-tip gap as one part of a probe, extension cable and 3300 XL 8 mm Proximitor Sensor chain.
Mounting interface: 3/8-24 UNF case, without armor
Case geometry: 0.0 in unthreaded; 2.8 in overall case
Connection path: 1.0 m integral lead; ClickLoc without connector protector
The 330101 base number selects a 3300 XL 8 mm probe with 3/8-24 UNF mounting and without armor. The first two order groups set 0.0 in unthreaded length and 2.8 in overall case length. These dimensions are installation geometry: compare bracket depth, target clearance and the removed part before setting the probe gap.

The integral 1.0 m probe lead terminates in a miniature coaxial ClickLoc connector without connector protector. An extension cable completes the electrical run to the 3300 XL 8 mm Proximitor Sensor; select the probe and cable lengths for the matching sensor system length. A mechanically fitting connector alone does not establish an electrically matched chain.

The final option is CN country-specific option; confirm label. Inspect the actual marking and site classification before commissioning; retain the original monitor channel and target records. The probe must be checked in its installed chain under a controlled machine procedure rather than evaluated only as a loose component.
Controller platform reference: Bently Nevada 3300 XL 8 mm Proximity Transducer System. Match probe, extension cable and Proximitor Sensor markings.
The official Bently Nevada 3300 XL 8 mm datasheet excerpt covers the applicable system and ordering family. The Apter Power guide organizes complete-code checks, installation and handover for 330101-00-28-10-02-CN.
Use the applicable Bently Nevada system documentation and the site-approved installation procedure for 330101-00-28-10-02-CN.
Prepare Bently Nevada 330101-00-28-10-02-CN using the applicable installation instructions and site isolation procedure.
Read all code groups

Compare every group of 330101-00-28-10-02-CN with the removed part; a shared base number does not establish equal cable or case length.

Check mounting geometry

Confirm 3/8-24 UNF, 0.0 in unthreaded section and 2.8 in case against the bracket and target.

Match electrical length

Combine the 1.0 m probe lead with the extension cable and check the 3300 XL 8 mm Proximitor Sensor system-length marking.

Inspect ClickLoc

Keep the connector clean and verify the specified connector-protector arrangement before closing the joint.

Review site approval

Treat the order-code approval group as CN country-specific option; confirm label; compare the physical label with the site requirement.

Prove the channel

Record target condition, gap indication and a controlled dynamic or position response after fitting.

Alternative Names

Bently Nevada 330101 00 28 10 02 CN 330101 order configuration 00 / 28 / 10 / 02 / CN

Technical notes

Code map: The first two groups set case geometry; the next group sets probe lead length; the last two select cable/connector and CN country-specific approval.

System applicability: These option meanings apply to the offered 330101-00-28-10-02-CN; system performance requires a matched 3300 XL 8 mm probe, extension cable and 3300 XL 8 mm Proximitor Sensor.

Technical reference: Bently Nevada 3300 XL 8 mm Proximity Transducer System Datasheet, 141194 Rev. AN.

FAQ View All FAQ

  • How should the installed measurement chain be matched when replacing 330101-00-28-10-02-CN?
    Check the probe lead and extension cable lengths together against the 3300 XL 8 mm Proximitor Sensor marking, then compare the monitor channel configuration.
  • Why might 330101-00-28-10-02-CN fit a bracket but still produce the wrong gap reading?
    3/8-24 UNF fit does not verify electrical length, target material, sensor calibration or gap. Compare the full chain and measure the baseline output before return to service.
  • What should be checked before setting the gap on 330101-00-28-10-02-CN?
    Confirm the 2.8 in case reaches the intended target without collision, then use the site-approved static target position and monitor procedure.
  • How is the ClickLoc joint on 330101-00-28-10-02-CN checked after assembly?
    Inspect contact cleanliness and full engagement, provide strain relief, and confirm the specified connector-protector arrangement matches the order group.
  • Can a different approval suffix be assumed equivalent to 330101-00-28-10-02-CN?
    No. Compare the physical approval marking, installation drawing and site classification before selecting a suffix for a controlled area.
  • How should a noisy channel be isolated after installing 330101-00-28-10-02-CN?
    Inspect target condition, ClickLoc joint, routing and shielding, then compare the probe-extension-sensor chain and monitor input under the approved diagnostic procedure.
  • What evidence is useful when accepting 330101-00-28-10-02-CN as a replacement?
    Retain full component markings, installed geometry, target and baseline gap reading, plus a controlled response from the monitoring channel.
  • When should the extension cable be changed along with 330101-00-28-10-02-CN?
    Change or reselect it when the existing cable and offered probe do not provide the sensor-required electrical length, or when connector/cable condition fails inspection.
