The 330101-00-12-10-02-05 is a standard eddy current proximity probe within the Bently Nevada 3300 XL 8 mm transducer system. This specific configuration features a 3/8-24 UNF thread with zero unthreaded length and a 1.2 inch total case length. It includes a 1.0 metre integrated cable for a 5 metre system combination, a standard ClickLoc connector, and holds international hazardous area approvals including CSA, ATEX, and IECEx.
One 3300 XL 8 mm probe
One 3300 XL extension cable
One 3300 XL Proximitor* Senso
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-metre system also fully complies with the American Petroleum Institute’s (API) 670 Standard (4th Edition) for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward-compatible and interchangeable with other non-XL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330101-00-12-10-02-05 8 mm Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power Generation
Used for shaft vibration and axial displacement monitoring of large steam turbines, gas turbines, and generators to prevent rotor-to-stator rubbing during high-speed rotation.
Hydroelectric Power Generation
Monitors the radial runout (vibration) of hydro-turbine generator shafts and the displacement of thrust bearings to ensure stable vertical or horizontal shaft alignment.
Nuclear Power Generation
Used for shaft condition monitoring and overspeed protection (Keyphasor reference) of main feedwater pumps and high-pressure turbo-generators in nuclear and conventional islands.
Petroleum Refining
Used for bearing vibration monitoring of large rich-gas compressors and centrifugal compressors in catalytic cracking and hydrocracking units to prevent catastrophic failures.
Natural Gas Transmission
Installed on gas-turbine driven compressor trains at pipeline pressurization stations for continuous mechanical vibration monitoring and safety interlocking.
Iron & Steel Metallurgy
Used for rotor shaft vibration monitoring of blast furnace blowers and Blast furnace Gas Top-gas Recovery Turbines to guarantee continuous operation.
During installation, the initial gap must be strictly adjusted based on DC voltage and the locknut must be securely tightened to prevent loosening and shaft impact caused by vibration. During routing, sharp bends and heavy pulling must be strictly avoided for the 1.0-metre cable, and the plastic tip must never impact hard objects.
The ClickLoc connector must be kept clean and oil-free, and an insulating sleeve or conduit box must be installed for sealing to prevent water ingress. In hazardous areas, it must be connected to the Proximitor through matching safety barriers to ensure explosion-proof compliance.
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
Used to measure vibration, position, and speed of rotating machinery shafts.
How to correctly install 330101-00-12-10-02-05?
Screw it into the bearing housing mounting hole via its 3/8-24 UNF thread.
What is the total case length of 330101-00-12-10-02-05?
Its total case length is 1.2 inches.
Which system should 330101-00-12-10-02-05 be used with?
It must be used with a 5-metre total length 3300 XL transducer system.
What connector does 330101-00-12-10-02-05 use?
It is equipped with a standard ClickLoc coaxial connector.
Does 330101-00-12-10-02-05 have explosion-proof approvals?
Yes, it holds multi-national hazardous area approvals including CSA, ATEX, and IECEx.
