16710-12

Name: 16710-12
Brand: Bently Nevada
SKU: 16710-12

12 ft Armored Accelerometer Interconnect Cable

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

Bently Nevada 16710-12 is a 12 ft armored interconnect cable with three shielded 22 AWG conductors. It connects the compatible acceleration or seismic sensing device to terminal-based monitoring wiring while protecting the routed signal cable.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for 16710-12

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 16710-12

Manufacturer:

Bently Nevada
Product Category:

Machinery Monitoring Systems
Spare Part Number:

16710-12
Estimated shipping dimensions:

26x26x3cm
Weight:

0.42 kg
Tariff Code:

8537101190
Counliy of origin:

USA
Part number:

16710-12
Product type:

Standard armored interconnect cable
Cable length:

12 ft
Approximate length:

3.6 m
Conductor count:

3
Conductor size:

22 AWG (0.5 mm2)
Cable construction:

Shielded, armored
Sensor-end connection:

3-socket plug
Field-end connection:

Terminal lugs
Ordering increment:

1 ft (0.3 m)
Published minimum length:

3 ft (0.9 m)
Published maximum length:

99 ft (30 m)

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

16710-12 provides a mechanically protected signal connection between a compatible Bently Nevada acceleration or seismic sensing device and terminal-based monitoring wiring.

Carries the sensor connection to terminal-based field wiring
Protects the routed signal path with an external armored construction
Provides preterminated interfaces at the sensor and panel ends
Supports length-coded routing for an engineered machinery-monitoring installation

The cable is routed between the machine-mounted sensing device and the monitored-system terminal interface. Installation preserves the connector, terminal-lug identification, shield path and armor while keeping the approved sensor and channel configuration unchanged.

Important Notice: Confirm 16710-12, the compatible sensing device and monitor channel, twelve-foot routing requirement, three-socket connector, terminal-lug assignments, shield and armor condition, grounding plan, channel configuration and controlled continuity and response-test results before commissioning.

Apter Power 16710-12 Manuals and Guides

The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.

High-temperature acceleration-system wiring

Connects the compatible field sensing arrangement to remote terminal wiring in a documented 330450 installation.

Seismic transmitter interconnection

Provides the armored cable option identified in the 177230 transmitter ordering information.

Gearbox casing-vibration routing

Protects the signal cable between a compatible casing sensor and the monitoring termination.

Machinery-panel cable replacement

Restores a recorded twelve-foot connection without changing the approved sensor and monitoring-channel pairing.

Read the applicable Bently Nevada installation instructions before work. Verify 16710-12, the installed host system and all configured field interfaces before isolation, wiring or commissioning.

Confirm the complete 16710-12 marking and the twelve-foot cable-length code.

Place the associated machinery-monitoring channel in the approved maintenance state.

Isolate the connected circuit and use ESD-safe handling at the sensor and monitoring terminals.

Record the three-socket plug orientation, terminal-lug identifiers and shield termination before removal.

Inspect the armor, cable jacket, plug contacts and terminal lugs for mechanical damage or contamination.

Route the replacement without crushing, abrasion, sharp bends or tensile loading.

Restore the documented shield, grounding, polarity and monitoring-channel configuration.

Verify continuity, baseline condition, channel response and alarm action before returning the machine to service.

Alternative Names

1671012 16710 12 16710-AA

Technical notes

Match the 16710-12 three-socket plug to the documented Bently Nevada sensing device and land the terminal lugs exactly as shown in the applicable system drawing. Protect the armor and shield from crushing, abrasion and unintended ground paths, then verify continuity, polarity and vibration-channel response before service.
