The 1771-OB is a digital DC output module for the Allen-Bradley PLC-5 series, featuring 8 output channels. The module operates within a voltage range of 10 to 27 V DC, with a maximum power dissipation of 16.9 W and a maximum thermal dissipation of 57.6 BTU/hr.
1500V AC opto-isolation
8 channel LED indicators
Single-slot rack installation
The 1771-OB incorporates 1500V AC opto-isolation to isolate electromagnetic noise, such as inductive back-EMF from field loads, from the PLC-5 CPU backplane bus. Mechanically, the module includes a 1771-WA field wiring arm for front-access maintenance and features 8 independent green LED status indicators on the front panel to display the logical on/off state of each output channel. With a maximum power dissipation of 16.9W and a thermal dissipation rating of 57.6 BTU/hr, it operates continuously under full load across a temperature range of 0 to 60 °C and a non-condensing relative humidity range of 5% to 95%.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Allen Bradley 1771-OB DC Output Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in t330101-00-16-10-01-05n.
Automotive Manufacturing
Outputting 24V DC signals on assembly lines to drive pneumatic solenoid valves for controlling robotic gripper operations.
Water and Wastewater Treatment
Controlling DC contactors for small dosing pumps in chemical dosing rooms and discrete inputs of field instruments.
Food and Beverage Processing
Controlling solenoid pilot valves for small sorting cylinders on packaging and filling lines.
Oil and Gas
Driving 24V DC relays for safety auxiliary circuits in wellhead control panels.
Pharmaceutical Industry
Controlling small DC stoppers for vial positioning in interconnected filling machines.
Power and Energy
Outputting signals in low-voltage switchgears to trigger shunt trips of auxiliary DC circuit breakers.
When using 1771-OB, notice the output voltage range and single-channel current limits. The key involves ensuring external loads stay within 10 to 27 Volts DC and single-channel current does not exceed 2 Amps (total module current under 8 Amps). Also, configure the dedicated 1771-WD wiring arm and ensure flyback diodes are connected in parallel across inductive loads to prevent back-EMF channel damage.
It is a digital output module for the Allen-Bradley PLC-5 system.
What is the main use of the 1771-OB?
It is used to control DC load devices in industrial fields.
How to use the 1771-OB?
Insert it into a 1771 I/O chassis and connect external DC power and loads.
How many output channels does the 1771-OB have?
It provides 8 independent output channels.
