      6ES7513-1AL02-0AB0

      CPU UNIT
      In Stock
      Siemens 6ES7513-1AL02-0AB0
      Siemens 6ES7513-1AL02-0AB0
      Siemens 6ES7513-1AL02-0AB0
      Siemens 6ES7513-1AL02-0AB0
      Siemens 6ES7513-1AL02-0AB0
      Siemens 6ES7513-1AL02-0AB0
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      CPU UNIT
      1513-1 PN
      SIMATIC S7-1500
      1.9 AMP, 24 VDC
      300 KB, 1.5 MB
      PROFINET IRT W/ 2 PORT SWITCH
      40 NS BIT-PERFORMANCE
      -40 TO +70 DEGREES C
      IPV4

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 6ES7513-1AL02-0AB0
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 6ES7513-1AL02-0AB0

      • Manufacturer:
        Siemens
      • Product Category:
        PLC Systems
      • Spare Part Number:
        6ES7513-1AL02-0AB0
      • Estimated shipping dimensions:
        5.1x15.2x15.2cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Germany
      • Processor Architecture:
        64-bit
      • Processing Speed (MHz):
        400
      • Memory (Program):
        512 KB
      • Memory (Data):
        2 MB
      • Communication Interfaces:
        PROFINET,EtherCAT
      • Power Consumption:
        12 W
      • Operating Temperature Range:
        -25°C to +60°C
      • Cooling Method:
        Passive heatsink cooling
      Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      The 6ES7513-1AL02-0AB0 is a Siemens SIMATIC S7-1500 series PLC central processing unit. It is a compact controller for medium-scale automation, featuring a built-in PROFINET IO interface, and is suitable for production process control in factory automation where high responsiveness is required.
        • Features an integrated display
        • Integrated PROFINET interface with 2 ports
        • Providing high-speed logic execution for demanding tasks
      The 6ES7513-1AL02-0AB0 is a versatile CPU 1513-1 PN within the SIMATIC S7-1500 family, engineered for medium-performance automation tasks. Featuring a lightning-fast 40 ns bit performance, it delivers exceptional responsiveness for sophisticated logic execution. It is equipped with 300 KB of work memory for programs and 1.5 MB for data, providing a robust foundation for complex applications.Its integrated PROFINET IRT interface, featuring a 2-port switch, ensures seamless deterministic communication and high-precision synchronization for motion control. The module requires a SIMATIC Memory Card (SMC) for operation and includes a built-in display for rapid on-site diagnostics. This CPU is an essential spare part for optimizing productivity and ensuring long-term reliability in diverse industrial sectors like packaging, assembly, and process control.

      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
       Siemens 6ES7513-1AL02-0AB0 CPU UNIT Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Automotive Assembly
      Used for logic control in engine assembly lines, managing numerous sensors and actuators.

      Logistics & Warehousing
      Controlling stacker cranes and conveyor systems for automated cargo scheduling.

      Printing Industry
      Used for tension control and multi-color alignment monitoring in printing presses.

      Rubber & Plastics
      Controlling pressure, temperature, and mold processes in injection molding machines.

      Solar Industry
      Managing solar wafer cutting equipment or photovoltaic module assembly lines.

      Packaging Machinery
      Controlling high-speed case packers and sealers, utilizing 40ns bit performance for precise cutter synchronization.

       The CPU must be used with an original SIMATIC Memory Card (SMC) for operation; never insert or remove the card while the power is on to prevent data corruption. Ensure the 24V DC power supply has correct polarity and proper grounding to maintain the high-speed communication stability of the backplane bus. Additionally, regularly check and update the firmware via TIA Portal, utilize the integrated display for on-site diagnostics, and ensure adequate ventilation in confined spaces to prevent CPU overheating.

      FAQ View All FAQ

      • What are the Communication Interfaces of 6ES7513-1AL02-0AB0?
        The Communication Interfaces of 6ES7513-1AL02-0AB0 include PROFINET and EtherCAT.
      • What is the Processing Speed ​​(MHz) of the 6ES7513-1AL02-0AB0?
        The Processing Speed ​​of the 6ES7513-1AL02-0AB0 is 400MHz.
      • What is the Memory (Data) of the 6ES7513-1AL02-0AB0?
        The Memory of the 6ES7513-1AL02-0AB0 is 2 MB.
      • What is the purpose of the display on the 6ES7513-1AL02-0AB0?
        The display shows the IP address, operating status, diagnostic messages, and module serial numbers.
      • Does the 6ES7513-1AL02-0AB0 support OPC UA?
        Yes, it supports OPC UA as a server or client for standardized communication with upper-level systems.
