Technical specifications for 6AV6640-0CA11-0AX1
-
Manufacturer:Siemens
-
Product Category:HMI Panels
-
Spare Part Number:TP177 Micro
-
Estimated shipping dimensions:21x15.5x5cm
-
Weight:0.7 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Rated Current Consumption:240 mA
-
Operation:Touch
-
Screen Size:5.7
-
Display Type:STN, 4 Blue Levels
-
Resolution:320 x 240 px
-
No. of function keys:Yes (onscreen)
-
Rated Voltage Supply:24 VDC
-
Intensidad nominal:0,24 A
-
Potencia:6 W
Information
Overview
Manuals
Common Applications
Product Precautions
The 6AV6640-0CA11-0AX1 is a 5.7-inch human-machine interface (HMI) operator panel for small-scale industrial control loops. Serving as the core window for local equipment operations, this product displays variable data and system status in real-time while transmitting control commands, making it a classic spare part within the Siemens micro-automation product line.
- Tight physical barrier for dust and water isolation
- Onboard 256 KB flash memory precisely mapped to the underlying system
- Its 5.7-inch screen integrates a high-transmittance analog resistive touch layer
Regarding data transmission and updates, its 9-pin interface converts directly into an RS485 differential signal via the physical layer, enabling serial connection with an upper-level PC using a PC/PPI adapter cable. Once the control screens, alarm logic, and variable mapping tables are compiled on the upper-level PC using WinCC flexible software, the panel must be manually switched to Transfer mode. At this stage, the project files are compiled and written into the panel's internal memory chip, allowing for long-term data retention during power-off states due to the built-in non-volatile storage characteristics.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
iemens 6AV6640-0CA11-0AX1 TP177 Micro Touch Panel Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Packaging Machinery
Used in compact cartoning, sealing, or labeling machines for operators to set packaging speeds, modify target counts, and view counter resets.
Food & Beverage Processing
Used in small mixers, batching equipment, or filling lines to monitor real-time temperatures and mixing times, and to fine-tune recipe parameters.
Plastics & Rubber Machinery
Displays heating zone temperatures and alarm statuses, and adjusts screw speeds in standalone plastic blow molding machines or small extruders.
Printing & Paper Converting
Enters paper cutting dimensions and records shift output on small paper cutters, slitting machines, or folding equipment.
Electronics Manufacturing & Semiconductor Equipment
Modifies baking profiles and monitors pneumatic pressure compressed-air alarms on small PCB conveyors, curing ovens, or standalone transfer robots.
Machine Tools & Metalworking
Used in small sawing, punching, or special drilling machines for operators to select processing modes, enter stepping distances, and monitor hydraulic oil levels.
When using the 6AV6640-0CA11-0AX1 (OP 73), prioritize program backup and obsolescence migration planning. Prevent operators from piercing the membrane keypad with sharp tools, and avoid harsh cleaning solvents. Crucially, ensure strict common grounding for the non-isolated RS485 port during PLC connection to prevent hardware burnout.
Alternative Names
6AV6640 0CA11 0AX1
6AV664O-OCA11-OAX1
6AV6640-0CAII-0AXI
6AV664O-OCAII-OAXI
Technical notes
SIMATIC HMI TP177 Micro 6AV6640-0CA11-0AX1 is a dedicated 5.7-inch blue-mode STN touch panel optimized for small-scale automation. It features an analog resistive touch screen and an RS485/RS422 port specifically configured for communicating with Simatic S7-200 PLCs. Boasting an IP65 front-panel ingress rating, it safeguards internal components against dust and moisture to ensure consistent operation on standalone machinery.
FAQ View All FAQ
-
What is the Siemens 6AV6640-0CA11-0AX1 TP177 Micro Touch Panel?It is a 5.7-inch blue-mode STN display operator panel designed specifically for human-machine interface (HMI) tasks in small-scale industrial automation.
-
What type of screen and resolution does the 6AV6640-0CA11-0AX1 utilize?It utilizes a 5.7-inch STN LCD touch screen with 4 levels of blue-mode graphics and a resolution of 320 x 240 pixels.
-
What is the touch input technology used in the 6AV6640-0CA11-0AX1?It uses analog resistive touch technology, allowing machine operators to input commands using their fingers, gloved hands, or a specialized stylus.
-
What built-in interfaces does the 6AV6640-0CA11-0AX1 provide for communication?It features one RS485/RS422 sub-D 9-pin port that supports MPI and PPI communication protocols.
-
Can the 6AV6640-0CA11-0AX1 be connected to an S7-300 or S7-1200 PLC?No, this micro series panel does not natively support S7-300 or S7-1200 PLCs; it is designed to communicate exclusively with S7-200 PLCs.
