Get a quick price for 6SE7090-0XX84-0AB0
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 6SE7090-0XX84-0AB0
-
Manufacturer:Siemens
-
Product Category:PLC Systems
-
Spare Part Number:6SE7090-0XX84-0AB0
-
Estimated shipping dimensions:2.4x12.6x26.5cm
-
Weight:0.2 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Auxiliary Voltage Supply:24V DC
-
Auxiliary Voltage for Potentiometer:10V DC (max 5 mA)
-
Pulse Encoder Connection:HTL unipolar pulse encoder
-
Motor Temperature Sensor Compatibility:PTC/KTY84 sensors
-
Operating Temperature Range:-25°C to +60°C
Information
Overview
Manuals
Common Applications
Product Precautions
The 6SE7090-0XX84-0AB0 Control Board is the central processing unit within the SIMOVERT MASTERDRIVES frequency inverter system, commonly designated as the CUVC (Control Unit Vector Control) module.
- Basic Terminal Strips
- Encoder Feedback Connection
- Stackable Expansion Slots
Simultaneously, the module monitors the hardware status of the inverter power section through the backplane bus, including the V and W phase current feedback signals collected by current transformers and the voltage data from the intermediate DC link. This hardware feedback mechanism allows the control board to respond to electrical abnormalities such as overcurrent, short circuits, or overvoltage within milliseconds, blocking pulse outputs to protect the inverter power devices.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Siemens 6SE7090-0XX84-0AB0 CUVC Control Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Steel Smelting
Regulates the torque and speed of electric motors for continuous casting straighteners.
Steel Rolling Industry
Controls the dynamic speed of primary drive motors for hot or cold rolling mills.
Paper Manufacturing
Coordinates the synchronous speed of multi-motor drive systems in high-speed paper machines.
Cement Manufacturing
Regulates the low-speed, high-torque output of primary drive motors for large rotary kilns.
Mining Industry
Controls the electrical drive systems of heavy-duty belt conveyors and mine hoists.
Oil Extraction
Regulates the operational speed of mud pumps and drawworks on offshore or onshore drilling rigs.
During field replacement of a failed 6SE7090-0XX84-0AB0 module, technicians must disconnect both the AC main power and the 24V control power, waiting until the DC link capacitors are discharged. Operational parameters, motor model data, and application macros reside within a removable EEPROM chip on the board; swapping this parameter chip onto the replacement board eliminates the need to manually re-enter hundreds of parameter codes.
Alternative Names
6SE7090-0XX84-0A80
6SE7090-0XX84-0ABO
6SE7090-0XX84-OAB0
6SE7090-0XX8A-0AB0
6SE7090-0XXB4-0AB0
6SE7090-OXX84-0AB0
6SE70900XX840A80
6SE70900XX840AB0
6SE70900XX840ABO
6SE70900XX84OAB0
6SE70900XX8A0AB0
6SE70900XXB40AB0
6SE7090OXX840AB0
6SE709O-0XX84-0AB0
6SE709O0XX840AB0
6SE7O90-0XX84-0AB0
6SE7O900XX840AB0
6SE7O9O-OXX84-OABO
6SE7O9O-OXXBA-OA8O
6SE7O9OOXX84OABO
6SE7O9OOXXBAOA8O
Technical notes
This board integrates dedicated microprocessors to execute closed-loop or open-loop vector control algorithms. Serving as the primary processor of the drive system, it samples speed and current feedbacks, calculates speed and torque regulation loops, and directly outputs pulse-width modulation (PWM) signals to the inverter firing circuits for precise motor control.
FAQ View All FAQ
-
Do you offer global delivery services?Yes. We ship globally, and we are able to quickly deliver parts globally to any corner of the world. Unless otherwise specified, we will ship your order via (DHL). We can also ship through FedEx, UPS, and TNT. We can also use your account.
-
How many parts do you have in stock?We have an extensive stock base consisting of ten thousands of new and discontinued automation parts including those from leading manufacturers such as: Control Systems(DCS ,PLC ,CNC),Panel Controllers, HMI and Display Panels, Drives, Encoders and Resolvers, Power Supplies. If you are unable to find what you are looking for then don’t panic.
-
What product is 6SE7090-0XX84-0AB0?It is a SIMOVERT MASTERDRIVES Vector Control module (CUVC board) manufactured by Siemens.
-
What is the standard firmware version for 6SE7090-0XX84-0AB0?The hardware comes configured with firmware version V3.4.
-
What is the official Siemens lifecycle status of 6SE7090-0XX84-0AB0?It is discontinued by the manufacturer and entered its official phase-out period on September 30, 2020.
