Technical specifications for 6ES7417-4XT05-0AB0
-
Manufacturer:Siemens
-
Product Category:PLC Systems
-
Spare Part Number:6ES7417-4XT05-0AB0
-
Estimated shipping dimensions:5×21.7×29cm
-
Weight:1.06 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
CPU designation:CPU 417-4
-
Work memory:30 MB total
-
Code memory:15 MB
-
Data memory:15 MB
-
First interface:MPI up to 12 Mbit/s
-
Second interface:Integrated PROFIBUS DP
-
Additional interfaces:Two slots for IF 964-DP modules
-
Bus current at 5 V DC:1.5 A typical; 1.8 A maximum
-
Backup current:225 µA typical up to 40 °C; 750 µA maximum
-
External backup voltage:5 to 15 V DC
-
Power loss:7.5 W typical
-
Firmware referenced in manual:V5.3
-
Programming package:STEP 7 V5.3 SP2 plus hardware update or later
-
Lifecycle status:Product cancelled; spare-part context
-
Product family:SIMATIC S7-400
Information
Overview
Manuals
Common Applications
Product Precautions
At the center of an S7-400 control rack, Siemens 6ES7417-4XT05-0AB0 executes the automation program while coordinating local backplane resources and multiple configured communication paths.
- 30 MB work memory with 15 MB each for code and data
- First interface supports MPI up to 12 Mbit/s
- Second integrated interface supports PROFIBUS DP
- Two additional slots accept IF 964-DP interface modules
The CPU supports a broad S7 communication environment and uses the S7-400 bus for its operating supply. Before replacement, retain the STEP 7 project, firmware level, memory card, interface parameters and I/O configuration. Once the validated project is restored, examine the diagnostic buffer, communication resources, process image and every affected control sequence before the rack returns to operation.
Important Notice: Confirm the complete 6ES7417-4XT05-0AB0 order number, firmware, memory card and installed interface-module arrangement before exchange.
Siemens 6ES7417-4XT05-0AB0 Manuals & Downloads
Siemens 6ES7417-4XT05-0AB0 Official Technical Reference Excerpt (PDF)Siemens 6ES7417-4XT05-0AB0 Installation & Commissioning Guide (PDF)
The first document contains the applicable manufacturer reference pages for this exact product; the second organizes preparation, wiring, diagnostics and handover checks.
Large S7-400 controller racks
Executes complex logic and data handling in a validated CPU 417-4 hardware configuration.
MPI engineering and HMI access
Provides the recorded first-interface path for programming and operator communication.
PROFIBUS DP automation
Coordinates documented distributed I/O and field-device exchanges through the integrated bus interface.
Installed-base CPU replacement
Restores the approved project, memory and interface arrangement for a cancelled S7-400 article.
Read the applicable Siemens instructions before work. Verify 6ES7417-4XT05-0AB0 and the installed system configuration before isolation or replacement.
1
Record the full Siemens 6ES7417-4XT05-0AB0 order number and firmware level.
2
Back up the STEP 7 project, hardware configuration and diagnostic records.
3
Place the controlled process and S7-400 rack in the approved maintenance state.
4
Isolate rack power and identify the memory card, MPI and PROFIBUS connections.
5
Document both optional IF-module slots and every installed interface assignment.
6
Inspect backplane contacts, backup supply and connector condition before seating the CPU.
7
Restore the validated project and review the diagnostic buffer after startup.
8
Test communications, program execution and all affected process functions before release.
Technical notes
Preserve the validated STEP 7 hardware configuration and all MPI, PROFIBUS and optional IF-module settings. Final testing should cover diagnostics, communications, program execution and process I/O behavior.
FAQ View All FAQ
-
Which controller function is provided by Siemens 6ES7417-4XT05-0AB0?Siemens 6ES7417-4XT05-0AB0 is the CPU 417-4 central processing unit for a configured SIMATIC S7-400 automation rack.
-
How is the work memory arranged in Siemens 6ES7417-4XT05-0AB0?Siemens 6ES7417-4XT05-0AB0 provides 30 MB of work memory, divided into 15 MB for code and 15 MB for data.
-
What communication speed does the MPI interface of Siemens 6ES7417-4XT05-0AB0 support?The first interface on Siemens 6ES7417-4XT05-0AB0 supports MPI communication at up to 12 Mbit/s.
-
Which fieldbus is integrated as the second interface on Siemens 6ES7417-4XT05-0AB0?The second integrated interface on Siemens 6ES7417-4XT05-0AB0 is PROFIBUS DP.
-
Can Siemens 6ES7417-4XT05-0AB0 accept additional interface modules?Siemens 6ES7417-4XT05-0AB0 provides two slots for optional IF 964-DP interface modules.
-
How much 5 V backplane current does Siemens 6ES7417-4XT05-0AB0 require?Siemens 6ES7417-4XT05-0AB0 typically draws 1.5 A from the 5 V S7-400 bus and has a stated maximum of 1.8 A.
-
Which external backup voltage is permitted for Siemens 6ES7417-4XT05-0AB0?Siemens 6ES7417-4XT05-0AB0 accepts an external backup supply in the range from 5 to 15 V DC.
-
What must be validated after Siemens 6ES7417-4XT05-0AB0 is replaced?The acceptance test for Siemens 6ES7417-4XT05-0AB0 should verify firmware, memory, the STEP 7 hardware configuration, all communication paths, diagnostics and affected process functions.
