3664 | Triconex 32-Point Dual 24 VDC Digital Output Module

Name: 3664
Brand: Invensys
SKU: 3664

Technical specifications for 3664

Manufacturer:

Invensys

Product Category:

DCS System

Spare Part Number:

3664

Estimated shipping dimensions:

49x45.3x6.8cm

Weight:

3.25 kg

Tariff Code:

8537101190

Counliy of origin:

USA

Module type:

Dual serial digital output

Nominal voltage:

24 VDC

Output signals:

32 commoned

Voltage range:

16 to 30 VDC

Maximum voltage:

36 VDC

Typical voltage drop:

<1.5 VDC

Power-module load:

<10 W

Maximum point current:

2 A

Surge current:

10 A for 10 ms

Load leakage:

2 mA maximum

Output protection:

Self-protecting; no field-termination fuses

Point isolation:

1500 VDC minimum

Status indicators:

1 per point; PASS; FAULT; ACTIVE; LOAD/FUSE

Color code:

Dark blue

Compatible commoned panel:

9662-610

Compatible basic panel:

9653-610

Compatible nonincendive panel:

9671-610

Compatible ERT loop-back:

9671-810

Information

Overview Manuals Common Applications Product Precautions

Triconex 3664 is a thirty-two-point dual 24 VDC digital output module. It produces voted source outputs and supervises field-voltage agreement for safety-related control duties.

Applies two-out-of-three voting to each of thirty-two output switches
Sources 24 VDC current to commoned field loads through dual output circuitry
Uses voltage loopback to compare commanded state with detected field voltage
Supports online hot-spare replacement with continuous channel diagnostics

3664 installs with Tricon I/O chassis and hot-spare position, 9662-610 or compatible termination panel, 16-30 VDC field supply, solenoids, relays, or other protected DC loads in an engineered Tricon dual digital output configuration.

The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this 32-point dual 24 vdc digital output module.

Important Notice: Confirm the complete 3664 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.

Apter Power 3664 Manuals and Guides

Apter Power 3664 Product Technical Reference PDF Apter Power 3664 Installation and Verification PDF

The first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.

De-energize-to-trip solenoid output banksSupports de-energize-to-trip solenoid output banks through the installed 32-point dual 24 vdc digital output module in a configured Tricon system.

Safety shutdown actuator commandsUses 3664 for safety shutdown actuator commands after the assigned host module, field interface and channel mapping are confirmed.

Dual-output valve manifold controlApplies the 3664 hardware arrangement to dual-output valve manifold control with controlled wiring and signal verification.

Online hot-spare DO module maintenanceProvides a defined engineering path for online hot-spare DO module maintenance, including installation checks and final functional proof.

Read the applicable Triconex installation instructions before work. Verify 3664 and the installed Tricon dual digital output configuration.

1Verify 3664 and the de-energize-to-trip application before module replacement.

2Place all commanded equipment in the approved safe state and isolate field power.

3Record thirty-two channel assignments, common supply, and expected de-energized states.

4Confirm each load stays within the two-amp point and ten-amp surge limits.

5Use a listed termination panel and preserve the sourced-output wiring arrangement.

6Use ESD controls and check module keying plus the hot-spare position.

7Command outputs individually and compare field voltage with LOAD/FUSE indication.

8Test hot-spare transfer and the final shutdown function before production release.
