      P0903CW

      Annunciator Keyboard
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      P0903CW is a serial/GCIO annunciator and numeric keyboard with 32 indicator/switch pairs plus a 16-key numeric keypad for I/A Series operator stations.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for P0903CW
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for P0903CW

      • Manufacturer:
        Invensys
      • Product Category:
        DCS Systems
      • Spare Part Number:
        P0903CW
      • Estimated shipping dimensions:
        23x21x4.5cm
      • Weight:
        0.45 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product form:
        Serial/GCIO annunciator/numeric keyboard
      • Annunciator positions:
        32
      • Numeric keypad:
        16 keys
      • Indicator colors:
        Red, yellow, green or off
      • Indicator states:
        On, off or flashing
      • Operator feedback:
        Tactile and audible
      • Supply:
        27.5 V DC +/-5% at input connector
      • Maximum consumption:
        6.0 W
      • Minimum consumption:
        3.0 W
      • Mounting:
        Free-standing, panel or workstation mounting
      • Communication:
        Serial / GCIO
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Foxboro P0903CW combines configurable colored annunciation, tactile operator keys, audible feedback and numeric entry in a free-standing or mounted control-room assembly.
      • 32 annunciator key positions
      • 16-key numeric keypad
      • Serial / GCIO interface
      • Configurable red, yellow or green LEDs

      The keyboard receives power and GCIO serial communication from the supported workstation or interface arrangement. Application mapping determines lamp color, flashing state, audible behavior and the operator action assigned to every key.

      Important Notice: P0903CW is the serial/GCIO annunciator/numeric keyboard. P0903CV omits the numeric keypad, while P0924TT and P0924WV are USB models.

      Foxboro P0903CW Manuals & Downloads
      Foxboro P0903CW Technical Reference (PDF)Foxboro P0903CW Manufacturer Manual Excerpt (PDF)

      The technical reference organizes exact characteristics and engineering boundaries. The manufacturer excerpt presents selected unchanged official pages used for exact-model review.

      Process alarm annunciation
      Presents configured alarm lamps and operator acknowledgement keys.
      Numeric operator entry
      Adds a dedicated 16-key pad beside annunciator functions.
      Control-room workstation panels
      Mounts within documented I/A Series operator furniture or panels.
      Legacy keyboard replacement
      Restores the exact serial/GCIO annunciator/numeric execution.
      Foxboro P0903CW installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Confirm P0903CW rather than P0903CV or a USB keyboard.
      2
      Back up every key, lamp color, flash and audible mapping.
      3
      Place operator functions in the approved maintenance state.
      4
      Isolate keyboard supply before opening the serial/GCIO connection.
      5
      Label the communication, power and audio connections.
      6
      Protect keycaps and the molded keyboard surface during handling.
      7
      Restore mounting and cable strain relief before applying power.
      8
      Test all 32 annunciator keys, 16 numeric keys, LEDs and audible output.

      Technical notes

      For P0903CW, retain the exact manufacturer identity, installed connection record and witnessed model-specific acceptance result.

      FAQ View All FAQ

      • How many annunciator positions are provided by Foxboro P0903CW?
        It has 32 indicator and switch pairs arranged as four rows of eight.
      • Which additional keypad is included on Foxboro P0903CW?
        The P0903CW includes a 16-key numeric keypad.
      • Which indicator colors can Foxboro P0903CW display?
        Each configured LED can show red, yellow or green, or remain off.
      • Which communication form is used by Foxboro P0903CW?
        It is the serial/GCIO annunciator and numeric keyboard execution.
      • Which supply is specified for Foxboro P0903CW?
        It uses 27.5 V DC at the input connector with a tolerance of plus or minus five percent.
      • How does Foxboro P0903CW differ from P0903CV?
        P0903CW includes the numeric keypad; P0903CV is the annunciator-only serial/GCIO model.
      • Where can Foxboro P0903CW be mounted?
        It can be used free-standing or mounted in a panel or supported workstation arrangement.
      • What proves commissioning of Foxboro P0903CW?
        Exercise all annunciator and numeric keys, verify every configured LED state, and confirm audible and workstation responses.
