Technical specifications for SC-UCMX02
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:51307195-276
-
Estimated shipping dimensions:5.6x12.6x13cm
-
Weight:0.26 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Controller configuration:Nonredundant
-
Onboard I/O:28 mixed channels
-
DRAM:256 MB
-
Rated supply:24 Vdc +/-25%
-
Input range:18 to 30 Vdc
-
Supply ripple:120 mVpp maximum
-
Input current:1.2 A maximum at 30 Vdc with 9 I/O modules
-
Power without expansion:1.7 to 2.9 W
-
Power with expansion:3.4 W
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell SC-UCMX02 is a nonredundant ControlEdge RTU controller with 28 mixed onboard I/O channels and communications for remote process automation.
- Executes ControlEdge RTU logic
- Provides twenty-eight mixed onboard I/O points
- Hosts RTU communications and protocols
- Expands to external I/O modules
SC-UCMX02 operates with ControlEdge RTU backplane, 24 Vdc power supply, Expansion I/O modules, RTU communications network.
Its engineered use includes Remote wellhead automation, Pipeline block-valve stations, Tank battery monitoring, Utility remote telemetry.
Important Notice: Confirm the complete SC-UCMX02 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.
