Get a quick price for IS420UCSCH1A-G-V0.1-A
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for IS420UCSCH1A-G-V0.1-A
-
Manufacturer:General Electric
-
Product Category:Gas Turbine Control
-
Spare Part Number:IS420UCSCH1A
-
Estimated shipping dimensions:5.5x15.3x20.3cm
-
Weight:1.52 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Storage:40 GB SSD Flash Storage
-
40 GB SSD Flash Storage:QNX Neutrino Real-Time OS
-
Network Ports:6 x 100Mbps Industrial Ethernet Ports (IONet)
-
Other Interface:2 x USB 2.0 Ports
-
Input Voltage:Nominal 24V DC (Allowable Range: 18 - 30V DC)
-
Power Consumption:Maximum 31 Watts
-
Cooling Method:Natural Convection (Fanless Design)
-
Coating Type:G3-Level Conformal Coating
-
Certifications:ATEX Zone 2 / Class I Div 2 Hazardous Locations
Information
Overview
Manuals
Common Applications
Product Precautions
The IS420UCSCH1A-G-V0.1-A is a core UCSC quad-core controller module within the Mark VIe Distributed Control System framework. Built to handle heavy-duty industrial automation tasks, this specific unit is outfitted with advanced G3-level conformal coating, making it highly resilient against harsh environments containing salt spray, moisture, and corrosive gases such as hydrogen sulfide.
- G3-Level Conformal Coating
- Embedded Field Agent (EFA) Technology
- Equipped with 1.2 GHz Quad-Core Processor
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
General Electric IS420UCSCH1A-G-V0.1-A Controller Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power Generation
Controls fuel supply, speed, and load for heavy-duty gas and steam turbines, ensuring grid synchronization and safety protection.
Wind Power Industry
Used in pitch control, yaw system regulation, and main control logic of large wind turbines to optimize power efficiency and prevent overspeed.
Oil & Gas Extraction
Controls compressor drive units on offshore drilling platforms or onshore oil fields, managing high-pressure natural gas transport pressure.
Petrochemical Industry
Acts as the core of Distributed Control Systems (DCS) to precisely manage the operation of large rotating machinery like cracked gas compressors.
Hydroelectric Power
Controls hydro-turbine governors and wicket gate openings, achieving high-precision, fast-response closed-loop control for hydro power generation.
When utilizing the IS420UCSCH1A-G-V0.1-A, a minimum 4-inch vertical air clearance must be maintained above and below the fanless unit while strictly controlling the cabinet temperature. Before deployment, it is critical to use the ToolboxST software to flash and synchronize the exact site-specific firmware and logic to prevent version mismatch alarms. Additionally, proper hardware grounding must be guaranteed, and the 6 IONet ports should be handled strictly according to redundancy hot-swap protocols to protect the G3-coated components from electrostatic or operational damage.
Alternative Names
IS420UCSCH1A G V0.1 A
1S420UCSCH1A-G-V0.1-A
IS42OUCSCH1A-G-V0.1-A
IS420UCSCH1A-G-VO.1-A
IS420UCSCH1A-G-V0.I-A
IS420UCSCHIA-G-V0.1-A
IS42OUCSCH1A-G-VO.1-A
1S420UCSCHIA-G-V0.I-A
Technical notes
As a core UCSC control unit within the Mark VIe Distributed Control System (DCS) architecture, the IS420UCSCH1A-G-V0.1-A leverages a 1.2 GHz quad-core architecture and the QNX Neutrino real-time operating system, combined with 40 GB of SSD flash storage, to achieve millisecond-level precision in processing complex logic. The module natively integrates six 100Mbps Industrial Ethernet ports (IONet) and two USB 2.0 interfaces, offering seamless compatibility with the ToolboxST configuration software, while establishing a secure data interconnection with the Predix cloud via built-in Embedded Field Agent (EFA) technology.
FAQ View All FAQ
-
What is the IS420UCSCH1A-G-V0.1-A controller?It is the core UCSC quad-core main controller unit in the GE (General Electric) Mark VIe Distributed Control System (DCS). It is primarily used for real-time control of large industrial equipment like gas and steam turbines, and features a G3-level conformal coating.
-
What operating system does the IS420UCSCH1A-G-V0.1-A run on?It runs on the industrial-grade QNX Neutrino real-time embedded multitasking operating system to ensure high reliability and determinism of the control logic.
-
How to properly install the IS420UCSCH1A-G-V0.1-A hardware?It features a fanless design and must be installed vertically on a DIN rail inside a standard control cabinet, relying on the cooling fins on the chassis surface for natural convection.
-
What software is required to use the IS420UCSCH1A-G-V0.1-A?GE's official ToolboxST software must be used for configuration, control logic downloading, firmware flashing, and daily online debugging.
-
How many Ethernet ports does the IS420UCSCH1A-G-V0.1-A have?It has 6 x 100Mbps industrial Ethernet ports (IONet) used to connect to I/O modules, other controllers, or Human-Machine Interfaces (HMIs).
