Technical specifications for IS200TTURH1B
-
Manufacturer:General Electric
-
Product Category:Gas Turbine Control
-
Spare Part Number:IS200TTURH1B
-
Estimated shipping dimensions:33x17.7x5.5cm
-
Weight:1.1 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Platform:Mark VI
-
Function:Primary turbine-protection input terminal board
-
Associated processor:VTUR
-
Speed inputs:Passive magnetic pickup circuits
-
Voltage inputs:Generator and bus PT circuits
-
Shaft monitoring:Voltage and current circuits
-
Architecture:Simplex or TMR protection arrangements
Information
Overview
Manuals
Common Applications
Product Precautions
The IS200TTURH1B forms the field-wiring boundary for the Mark VI primary turbine-protection chain, keeping speed, synchronization and shaft-monitoring signals organized before they reach VTUR.
- Receives passive pulse-rate speed-sensor wiring for turbine-speed measurement and primary overspeed protection.
- Terminates generator and bus potential-transformer inputs used by the automatic synchronization functions.
- Carries shaft-voltage and shaft-current monitoring signals into the primary protection subsystem.
- Connects to the VTUR processor through the documented Mark VI protection-board cabling arrangement.
TTUR keeps magnetic speed inputs, generator and bus PT circuits, shaft monitoring and VTUR cabling inside one controlled primary-protection boundary.
Important Notice: Confirm IS200TTURH1B, the installed VTUR and trip-board architecture, all terminal assignments and the simplex or TMR cabling arrangement before installation.
GE IS200TTURH1B Manuals & Downloads
GE IS200TTURH1B Technical Reference (PDF)GE IS200TTURH1B Installation & Commissioning Guide (PDF)
The technical reference consolidates product identity and interface data; the installation guide provides separate readiness, configuration, verification and handover checks.
Primary overspeed inputs
Terminates passive magnetic pickup circuits used by VTUR for turbine-speed protection.
Automatic synchronization
Carries generator and bus potential-transformer inputs used by synchronization functions.
Shaft monitoring
Routes shaft-voltage and shaft-current measurement circuits into the primary protection subsystem.
Simplex or TMR integration
Supports the documented VTUR cabling arrangement selected for the installed redundancy architecture.
Read the applicable product and site instructions before work. Verify IS200TTURH1B, the installed host and every connected interface before isolation or replacement.
1
Confirm the IS200TTURH1B revision, VTUR processor and installed primary-trip-board arrangement.
2
Record every magnetic pickup, PT, shaft-monitoring and breaker-related terminal before isolation.
3
Capture the simplex or TMR cable map, including each JR, JS and JT connector used by the position.
4
Place the turbine and generator-breaker circuits in the approved maintenance state.
5
Protect keyed connectors, terminal-block labels and chassis-ground shield terminations during handling.
6
Restore pickup polarity, PT phase, shaft circuits, jumpers and relay wiring exactly as documented.
7
Review VTUR diagnostics, measured speed, PT values and synchronization permissives after energization.
8
Perform the controlled primary-trip and synchronization checks before service handover.
Technical notes
Verify the complete IS200TTURH1B revision, associated VTUR processor, terminal assignments, speed-sensor polarity, PT wiring, shaft-monitoring circuits and protection-system redundancy before removal or return to service.
FAQ View All FAQ
-
What is the purpose of GE IS200TTURH1B?It is the Mark VI terminal board that brings primary turbine-protection field inputs to the VTUR processor.
-
Which processor is associated with GE IS200TTURH1B?It is used with the VTUR primary turbine-protection processor in the documented Mark VI architecture.
-
Which speed signals terminate on GE IS200TTURH1B?Passive magnetic speed-pickup circuits terminate on the board for turbine-speed measurement and overspeed protection.
-
Which voltage signals are handled by GE IS200TTURH1B?The board terminates generator and bus potential-transformer circuits used by the synchronization functions.
-
Does GE IS200TTURH1B participate in shaft monitoring?Yes. The documented protection arrangement carries shaft-voltage and shaft-current monitoring through the TTUR path.
-
Can GE IS200TTURH1B be used in redundant Mark VI systems?The terminal board is documented within both simplex and triple-modular-redundant primary protection arrangements, subject to the installed VTUR and trip-board configuration.
-
Is GE IS200TTURH1B interchangeable with a different TTUR revision?Do not assume interchangeability. Match the complete H1B revision, connectors, terminal assignments, cabling and the installed VTUR configuration.
-
What should be verified after installing GE IS200TTURH1B?Verify speed-sensor polarity and readings, PT phase and voltage, shaft-monitoring circuits, VTUR diagnostics, synchronization permissives and the controlled primary-trip test before service release.
