Technical specifications for 5X00106G01
-
Manufacturer:Emerson
-
Product Category:DCS Systems
-
Spare Part Number:5X00106G01
-
Estimated shipping dimensions:12.1x5.2x16.6cm
-
Weight:0.32 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Channels:8 galvanically isolated analog inputs
-
Nominal range:4-20 mA
-
Checked range:2.5 to 25 mA with under-range and over-range checking
-
A/D resolution:14 bits
-
Personality module:5X00109G01
Information
Overview
Manuals
Common Applications
Product Precautions
Westinghouse 5X00106G01 interfaces eight isolated 4-20 mA HART current loops to the Ovation controller while retaining both analog measurement and digital device communication.
- Provides eight isolated input channels for the documented hart analog input electronics module function.
- Handles 4-20 mA current loop with HART communication through the specified Ovation I/O subsystem.
- Works with 5X00109G01 HART high-performance analog-input personality module.
- A dedicated HART transceiver and isolated UART path is provided for each input channel.
The hart analog input electronics module belongs in the controlled Ovation I/O subsystem and works with 5X00109G01 HART high-performance analog-input personality module. Its field connection, companion hardware and project configuration must be reviewed together before the channel is returned to service.
Important Notice: Use 5X00106G01 only with 5X00109G01 HART high-performance analog-input personality module; verify the field interface and controlled configuration before energizing the subsystem.
Westinghouse 5X00106G01 Manuals & Downloads
Westinghouse 5X00106G01 Official Technical Reference Excerpt (PDF)Westinghouse 5X00106G01 Installation & Commissioning Guide (PDF)
The first document covers the product function, system role and technical selection. The installation guide covers identification, connection checks, commissioning and the acceptance record.
Installed-base maintenance
Restores the documented hart analog input electronics module position without changing the approved system architecture.
Loop or channel service
Supports verification of 4-20 mA current loop with HART communication at the assigned control-system channel.
Planned replacement
Provides an exact-identity replacement path when 5X00109G01 HART high-performance analog-input personality module and the field interface have been confirmed.
Commissioning support
Allows the responsible engineer to prove wiring, configuration, status and response for eight isolated input channels.
Before installing Westinghouse 5X00106G01, confirm the documented system, interfaces and controlled configuration.
1
Match the complete 5X00106G01 marking to the work order and installed position before removal.
2
Confirm 5X00109G01 HART high-performance analog-input personality module before making or breaking any field connection.
3
Keep the assigned 4-20 mA current loop with HART communication within the documented subsystem and range.
4
Record terminal designations, polarity, common and shield treatment before disconnecting conductors.
5
Inspect module seating, connector keying, terminal condition and strain relief before power is restored.
6
Restore the controlled channel configuration, range selection and alarm or timeout behavior after installation.
7
Check local indicators and controller diagnostics for internal, communication or channel faults during commissioning.
8
Prove the intended response across eight isolated input channels and record the acceptance result before release.
Technical notes
Use 5X00106G01 only with 5X00109G01 HART high-performance analog-input personality module; verify the field interface and controlled configuration before energizing the subsystem.
FAQ View All FAQ
-
How many HART loops can Westinghouse 5X00106G01 monitor?The module provides eight galvanically isolated analog-input channels with HART communication.
-
What is the nominal process-current range for Westinghouse 5X00106G01?Each channel is intended for a nominal 4–20 mA current loop.
-
Which extended current values are checked by Westinghouse 5X00106G01?The documented checked range is 2.5 to 25 mA, allowing under-range and over-range conditions to be identified.
-
What A/D resolution is provided by Westinghouse 5X00106G01?The high-performance analog-input conversion uses 14-bit resolution.
-
Which field-interface module belongs with Westinghouse 5X00106G01?The specified personality module is 5X00109G01.
-
How can Westinghouse 5X00106G01 carry HART data without losing the process value?Each isolated channel retains the 4–20 mA analog measurement while its dedicated HART communication path exchanges digital device information.
-
What should an under-range test demonstrate on Westinghouse 5X00106G01?A controlled current below 4 mA but within the 2.5–25 mA checked span should be measured and identified as an under-range condition rather than a normal process value.
-
Which verification is needed after pairing Westinghouse 5X00106G01 with 5X00109G01?Confirm all eight loop polarities and analog readings, then establish HART communication independently on every assigned channel.
