Technical specifications for 330930-065-00-05
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330930-065-00-05
-
Estimated shipping dimensions:18x18x2cm
-
Weight:0.1 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Cable family:3300 NSv extension cable
-
Cable length:6.5 m
-
Construction:Without stainless-steel armor
-
Connector protector:Not included
-
Approval selection:Multiple approvals
-
System rule:Probe plus extension cable equals Proximitor system length
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 330930-065-00-05 completes a 3300 NSv probe-to-Proximitor path with a 6.5 m unarmored coaxial section.
- Provides a 6.5 m calibrated extension section.
- Uses unarmored standard coaxial construction.
- Carries the multiple-approval execution.
- Operates only inside a matched 3300 NSv electrical-length chain.
The cable is part of the calibrated transducer circuit. Its family, length and connector arrangement must agree with both the probe lead and the 3300 XL NSv Proximitor sensor.
Important Notice: Compare the complete 330930-065-00-05 marking with the installed cable before disconnection. Record the restored gap voltage and proportional response before service release.
Bently Nevada 330930-065-00-05 Manuals & Downloads
Bently Nevada 330930-065-00-05 Official Technical Reference Excerpt (PDF)Bently Nevada 330930-065-00-05 Installation & Commissioning Guide (PDF)
The first document covers the product function, system role and technical selection. The installation guide covers identification, connection checks, commissioning and the acceptance record.
Electrical-length completion
Provides the 6.5 m extension section required by the matched 3300 NSv transducer chain.
Probe-to-conditioner connection
Carries the calibrated coaxial signal from the probe lead to the Proximitor sensor.
Position measurement loop
Maintains the defined signal path for static shaft-position measurements.
Maintenance replacement
Restores a damaged cable section while preserving the selected system length.
Before installing Bently Nevada 330930-065-00-05, confirm the documented system, interfaces and controlled configuration.
1
Compare the complete 330930-065-00-05 marking with the installed cable before disconnection.
2
Confirm the required unarmored standard cable construction and connector arrangement.
3
Do not shorten, splice or field-repair the calibrated coaxial cable.
4
Clean and inspect both ClickLoc interfaces before mating the connectors.
5
Provide strain relief and protect the cable from abrasion, heat and moving hardware.
6
Use the cable only inside a matched 3300 NSv probe and Proximitor system.
7
Verify continuity and positive connector engagement before energizing the channel.
8
Record the restored gap voltage and proportional response before service release.
Technical notes
Compare the complete 330930-065-00-05 marking with the installed cable before disconnection. Record the restored gap voltage and proportional response before service release.
FAQ View All FAQ
-
Which extension length is selected by 330930-065-00-05?The 065 field specifies 6.5 m.
-
Does the cable construction of include armor 330930-065-00-05?No. Option 00 is the unarmored standard cable.
-
Which approval selection closes 330930-065-00-05?The final 05 selects the multiple-approval execution.
-
How does affect total electrical length 330930-065-00-05?Its 6.5 m section plus the probe lead must equal the selected Proximitor system length.
-
Can be shortened to remove excess routing 330930-065-00-05?No. Cutting or splicing changes the calibrated electrical path.
-
Which contacts require inspection before mating 330930-065-00-05?Inspect both ClickLoc interfaces for cleanliness, damage and positive engagement.
-
Why must armor routing practices not be assumed for 330930-065-00-05?This exact construction is unarmored and requires separate mechanical protection and strain relief.
-
What commissioning evidence should follow replacement of 330930-065-00-05?Record restored bias voltage, response direction and dynamic indication.
