      330910-00-12-10-02-00

      Proximity Probe
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      Bently Nevada 330910-00-12-10-02-00 is an armored M10 x 1 proximity probe with a 1 m standard lead for the 3300 XL NSv system. A selected NSv extension and matching Proximitor complete the 5 m or 7 m channel for non-contact shaft vibration and position measurements.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330910-00-12-10-02-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330910-00-12-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330910-00-12-10-02-00
      • Estimated shipping dimensions:
        1.8×1.6×108cm
      • Weight:
        0.14 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe Family:
        3300 XL NSv
      • Mounting Thread:
        M10 x 1
      • Armor Execution:
        With armor
      • Unthreaded Length Option:
        AA00 = 0 mm; fully threaded
      • Overall Case Length Option:
        BB12 = 120 mm
      • Total Probe Length:
        CC10 = 1.0 m
      • Connector and Cable:
        DD02 = miniature coaxial ClickLoc, standard cable
      • Included Connector Protector:
        Not included by DD02
      • Approval Selection:
        EE00 = agency approval not required
      • Nominal Probe DC Resistance:
        4.2 +/-0.5 ohm; center to outer conductor
      • Standard Probe Cable:
        75 ohm coaxial; FEP insulated
      • Probe Tip Material:
        Polyphenylene sulfide (PPS)
      • Probe Case Material:
        AISI 304 stainless steel
      • Recommended Case Torque:
        11.3 N m; standard forward mounting
      • Maximum Case Torque:
        33.9 N m; standard forward mounting
      • First-Three-Threads Torque:
        7.5 N m recommended; 22.6 N m maximum
      • Maximum Thread Engagement:
        15 mm; matching internal fit class
      • Minimum Cable Bend Radius:
        25.4 mm
      • Maximum Connector Torque:
        0.56 N m
      • ClickLoc Connector Practice:
        Finger tight
      • Standard Probe Temperature:
        -52 to +177 deg C; operating and storage
      • Matched System Linear Range:
        1.5 mm; approximately 0.25 to 1.75 mm
      • Radial Vibration Gap Setting:
        1.0 mm; recommended gap
      • Nominal System Scale Factor:
        7.87 V/mm (200 mV/mil)
      • System Frequency Response:
        0 to 10 kHz; +0 / -3 dB typical
      • Companion Proximitor Output Resistance:
        50 ohm
      • Companion Proximitor Maximum Current:
        12 mA
      • Companion Proximitor Operating Temperature:
        -52 to +100 deg C
      • Companion Proximitor Storage Temperature:
        -52 to +105 deg C
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330910-00-12-10-02-00 is an armored M10 x 1 proximity probe with a 1 m standard lead for the 3300 XL NSv system. A selected NSv extension and matching Proximitor complete the 5 m or 7 m channel for non-contact shaft vibration and position measurements.
      • Armored M10 x 1 execution for the selected fully threaded mounting arrangement.
      • The 1 m probe uses a 4 m or 6 m NSv extension to complete a matching 5 m or 7 m channel.
      • DD02 selects standard ClickLoc cable without an included connector protector.
      • An isolated 1 m probe resistance check is separate from complete channel calibration.

      The probe senses the gap to a conductive target; its companion NSv Proximitor supplies the conditioned signal to the monitor. Armor provides mechanical lead protection, while the selected extension length and target calibration determine the assembled channel configuration.

      Important Notice: Keep the full AA00 / BB12 execution when selecting the mounting arrangement. Armor does not establish FluidLoc sealing or hazardous-area approval. Match the NSv electrical length and assess the actual target geometry.

      Bently Nevada 330910-00-12-10-02-00 Manuals & Downloads
      Bently Nevada 330910-00-12-10-02-00 Technical Reference (PDF)Bently Nevada 330910-00-12-10-02-00 Installation & Commissioning Guide (PDF)

      The technical reference explains probe construction, electrical-length choices and system performance. The installation guide covers mounting, connection checks, gap setting and channel acceptance.

      Armored metric routes
      Use the M10 armored execution where the mounting interface and lead route call for this construction.
      Small-target measurements
      Apply the NSv system where constrained target or counterbore geometry has been checked against its response data.
      Radial vibration channels
      Measure non-contact shaft motion through a correctly selected and calibrated NSv transducer channel.
      Position monitoring
      Provide a static gap signal through the matched conditioner to the configured position-monitoring function.
      Bently Nevada 330910-00-12-10-02-00 installation checks cover the armored metric mount, 1 m lead and matching NSv electrical length.
      1
      Use a 4 m NSv extension for a 5 m channel or a 6 m extension for a 7 m channel with this 1 m probe.
      2
      Check the M10 x 1 mating fit and keep thread engagement within 15 mm; retain the selected AA00 / BB12 execution.
      3
      Choose torque by support: normal mounting uses 11.3 N m recommended, while first-three-threads support uses 7.5 N m.
      4
      Route the armored lead without crushing or sustained pull; maintain a minimum 25.4 mm bend radius.
      5
      Tighten ClickLoc finger tight within the 0.56 N m maximum; protect the DD02 junction for the installed environment.
      6
      Check target and counterbore size, shaft geometry and nearby probes before relying on the nominal NSv response.
      7
      Measure the disconnected probe against the 4.2 +/-0.5 ohm reference; keep this separate from energized channel testing.
      8
      Apply the distinct probe and conditioner temperature limits; EE00 does not establish a hazardous-area approval.

      Technical notes

      Match the 1 m probe with a 4 m NSv extension for a 5 m channel, or a 6 m extension for a 7 m channel. DD02 provides standard cable and ClickLoc without an included protector; EE00 selects agency approval not required.

      FAQ View All FAQ

      • How does the 1 m lead of 330910-00-12-10-02-00 determine the extension choice?
        Use a 4 m NSv extension with a 5 m Proximitor, or a 6 m NSv extension with a 7 m Proximitor. The sum of probe and extension must match the conditioner length.
      • What does the armor on 330910-00-12-10-02-00 establish?
        It identifies the armored probe execution. It does not select FluidLoc cable, include a DD02 connector protector, or establish an environmental sealing rating for an unprotected joint.
      • What resistance distinguishes the 1 m 330910-00-12-10-02-00 probe check?
        The nominal center-to-outer resistance is 4.2 +/-0.5 ohm. Measure the isolated probe; do not substitute the 0.5 m probe value or an extension conductor resistance.
      • Which mounting checks apply to 330910-00-12-10-02-00?
        Verify the M10 x 1 fit and AA00 / BB12 mechanical execution. Maximum thread engagement is 15 mm; normal forward support uses 11.3 N m recommended and 33.9 N m maximum case torque.
      • What target and counterbore sizes should be reviewed for 330910-00-12-10-02-00?
        The minimum flat-target diameter is 8.9 mm and the minimum counterbore is 9.5 mm; 13 mm is the recommended minimum for each. Smaller geometry changes response and requires review of the published curves.
      • Does the final 00 on 330910-00-12-10-02-00 prove hazardous-area suitability?
        No. EE00 means agency approval not required in the ordering selection. Determine suitability from the actual installed equipment requirements and supplied markings.
      • What is the usable linear range of a channel containing 330910-00-12-10-02-00?
        The matched NSv system has a 1.5 mm linear range, approximately 0.25 to 1.75 mm from the target, with a recommended 1.0 mm gap under the specified reference conditions.
      • How does 330910-00-12-10-02-00 connect to the monitor?
        The probe connects through the selected NSv extension to the matching Proximitor. The separate conditioner-to-monitor circuit uses field wiring; its length is not part of the 5 m or 7 m transducer electrical length.
