Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for 330130-085-00-05
For more information on how your data is processed and stored by Apterpower please read our privacy policy
-
Match the complete marking
Include the complete Bently Nevada 330130-085-00-05 marking and any hardware revision on the item. Compare the complete order code, mating interfaces and installed measurement chain.
-
Check the offered item before ordering
Request available label and connector photos. Have your maintenance team compare the offered 330130-085-00-05 with the installed equipment and applicable Bently Nevada documents.
Technical specifications for 330130-085-00-05
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330130-085-00-05
-
Weight:0.3 kg
-
Tariff Code:8537101190
-
Extension length:8.5 m
-
Construction:standard cable
-
Center-conductor resistance:1.87 ohm ±0.28 ohm
-
Outer-conductor resistance:0.56 ohm ±0.11 ohm
-
Cable capacitance:69.9 pF/m typical
-
Matching probe for 9 m system:0.5 m
-
Nominal system scale:7.87 V/mm
-
Nominal system linear range:2 mm
Information
Overview
Downloads
Applications / Compatibility
Product Precautions
- Bently Nevada 330130-085-00-05 provides the calibrated cable reach between the machine-side probe and a 9 m Proximitor when paired with the corresponding 0.5 m probe.
Cable reach: 8.5 m
Construction: standard cable
Calibrated pairing: 0.5 m probe for a 9 m chain
Construction: standard cable
Calibrated pairing: 0.5 m probe for a 9 m chain
The selected 8.5 m extension and a 0.5 m compatible probe add to a 9.0 m electrical chain. This total must agree with the Proximitor calibration; physical reach alone is not a sufficient cable-selection criterion.
The cable uses standard cable. Keep the connectors clean, supported and electrically isolated as required by the installation, and route the cable without shortening or splicing its calibrated length.
Center-conductor resistance is 1.87 ohm ±0.28 ohm, while outer-conductor resistance is 0.56 ohm ±0.11 ohm. These are separate continuity checks on the disconnected cable, and neither replaces a full target-to-monitor response test.
The cable uses standard cable. Keep the connectors clean, supported and electrically isolated as required by the installation, and route the cable without shortening or splicing its calibrated length.
Center-conductor resistance is 1.87 ohm ±0.28 ohm, while outer-conductor resistance is 0.56 ohm ±0.11 ohm. These are separate continuity checks on the disconnected cable, and neither replaces a full target-to-monitor response test.
Controller platform reference: Bently Nevada 3300 XL 8 mm transducer system. Follow the applicable installation instructions and approved measurement-chain design.
The original technical excerpt applicable to Bently Nevada 330130-085-00-05 covers cable electrical characteristics and ordering options. The separate installation guide covers route preparation, length matching, conductor checks and complete-chain testing.
330130-085-00-05 Official Technical Excerpt
The original technical excerpt applicable to Bently Nevada 330130-085-00-05 covers cable electrical characteristics and ordering options. PDF · 6 pages.330130-085-00-05 Installation & Verification Guide
Apter Power installation and verification guide covering route preparation, length matching, conductor checks and complete-chain testing. PDF · 5 pages.
Original manufacturer pages retain their technical context. Use the Apter Power guide with the applicable manufacturer instructions and approved installation design.
System and supply context: The extension cable links a compatible probe to the Proximitor in the selected electrical-length system.
Application scope: Keep the complete system family, connector arrangement and total cable length together when assessing replacement.
Application scope: Keep the complete system family, connector arrangement and total cable length together when assessing replacement.
Nine-metre chain
Combine this 8.5 m extension with the matching 0.5 m probe.Remote conditioning
Reach a Proximitor position away from the immediate sensing point.Cable fault isolation
Separate core and shield continuity checks from probe resistance measurements.Machine wiring renewal
Restore the selected cable route while preserving the calibrated length.
Prepare Bently Nevada 330130-085-00-05 for its configured installation using these checks.
Electrical length
Match probe plus extension to the Proximitor calibration.
Cable modification
Do not shorten or splice the calibrated cable.
Connector cleanliness
Protect coaxial contacts from contamination.
Mechanical support
Avoid pulling at the connector or crushing the cable.
Continuity test
Disconnect the cable before measuring its conductors.
System validation
Verify target-to-monitor response after replacement.
Alternative Names
330130 085 00 05
Bently Nevada 330130-085-00-05
Technical notes
Signal and interface: Check center and outer conductor continuity separately against 1.87 ohm ±0.28 ohm and 0.56 ohm ±0.11 ohm, respectively.
Installation boundary: The 69.9 pF/m typical capacitance belongs to the cable. Range and scale-factor ratings belong to the complete matched transducer system.
Technical basis: Bently Nevada 3300 XL 8 mm Proximity Transducer System, 141194 Rev. AN. Cable selections and DC resistance apply to this length. System sensitivity applies only to the matched probe, extension and Proximitor.
FAQ View All FAQ
-
Which probe length completes a 9 m chain with 330130-085-00-05?A compatible 0.5 m probe plus this 8.5 m extension gives the 9.0 m total.
-
Is 330130-085-00-05 an armored extension?No. Cable option 00 selects the standard cable.
-
What center-conductor resistance belongs to 330130-085-00-05?The nominal value is 1.87 ohm ±0.28 ohm, measured along the disconnected extension core.
-
What outer-conductor resistance should be checked on 330130-085-00-05?The nominal outer-conductor resistance is 0.56 ohm ±0.11 ohm.
-
Can 330130-085-00-05 be shortened to fit a 5 m sensor?No. Cutting the cable changes its calibrated electrical length; select the correct matched cable instead.
-
How is cable capacitance relevant to 330130-085-00-05?The typical cable capacitance is 69.9 pF/m and forms part of the electrical transducer chain.
-
Does 330130-085-00-05 have the same scale-factor tolerance as a 5 m system?The complete standard 9 m system has its own tolerance; the nominal scale remains 7.87 V/mm, but the 5 m tolerance must not be transferred to it.
-
What separates a cable-only test from acceptance of 330130-085-00-05?Cable continuity tests check the conductors. Acceptance also requires a complete-chain gap and target-response test with the matched probe and Proximitor.
