330104-01-05-10-02-00

3300 XL 8 mm Metric Proximity Probe with Armor
In Stock
Ships by Tuesday, September 22
Fast Shipping Available

Product Describe:

Bently Nevada 330104-01-05-10-02-00 is a metric M10 × 1 forward-mount 3300 XL 8 mm proximity probe with flexible stainless-steel armor, configured for a 1.0 m total length and standard ClickLoc connection. It senses shaft-to-bearing relative displacement in a matched transducer system.

Ask our team:

Get a quick price for: 330104-01-05-10-02-00
Quantity*
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy.

Technical specifications for 330104-01-05-10-02-00

Technical specifications for 330104-01-05-10-02-00

  • Manufacturer:
    Bently Nevada
  • Product Category:
    Machinery Monitoring System
  • Spare Part Number:
    330104-01-05-10-02-00
  • Estimated shipping dimensions:
    2x1.5x112cm
  • Weight:
    0.14 kg
  • Tariff Code:
    8537101190
  • Counliy of origin:
    USA
  • Probe construction:
    With flexible stainless-steel armor
  • Mounting thread:
    M10 × 1
  • Unthreaded length:
    10 mm
  • Overall case length:
    50 mm
  • Total probe length:
    1.0 m
  • Connector:
    Miniature coaxial ClickLoc
  • Probe cable:
    75 Ω triaxial standard cable
  • Agency approval option:
    Not required
  • Probe-tip material:
    Polyphenylene sulfide (PPS)
  • Probe-case material:
    AISI 303 or 304 stainless steel
  • Standard probe temperature:
    -52 to +177 °C
  • Minimum cable bend radius:
    25.4 mm
  • Recommended mounting torque:
    11.2 N·m

Information

Information

Overview Manuals Common Applications Product Precautions
330104-01-05-10-02-00 provides the metric sensing element for a matched 3300 XL 8 mm eddy-current proximity transducer loop.
  • Detects shaft-to-bearing relative movement without mechanical contact
  • Forms the field sensing element of the matched eddy-current loop
  • Carries the probe signal through a serviceable coaxial connection
  • Supports static-position and vibration measurements in rotating machinery

The probe is fitted to the engineered M10 × 1 machine position and connected to the selected 3300 XL extension cable and Proximitor Sensor. Commissioning includes exact order-code checks, thread and case clearance, cable routing, ClickLoc cleanliness, total-system-length matching, static-gap adjustment and controlled dynamic-response verification.

Important Notice: Confirm 330104-01-05-10-02-00, M10 × 1 host thread, 10 mm unthreaded length, 50 mm case execution, armor, ClickLoc connector, extension cable, Proximitor Sensor, total system length, target material, wiring, shielding, grounding, monitor configuration, static gap and controlled response-test results before commissioning.

Apter Power 330104-01-05-10-02-00 Manuals and Guides

The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.

Radial shaft-vibration measurement
Measures relative shaft motion at a documented bearing location.
Axial position supervision
Observes controlled thrust-position movement with the approved target geometry.
Machine shaft centerline trending
Provides gap-voltage data for startup and operating-position analysis.
Probe-loop replacement
Restores a matched transducer loop requiring the 10 mm by 50 mm metric probe execution.
Read the applicable Bently Nevada installation instructions before work. Verify 330104-01-05-10-02-00, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
1
Confirm the full 330104-01-05-10-02-00 marking and the 10 mm / 50 mm case execution.
2
Place the monitored machine and protection channel in the approved maintenance state.
3
Protect the 8 mm PPS probe tip and keep the M10 × 1 mounting thread clean.
4
Route the armored 1.0 m probe lead without crushing, sharp bends or tensile loading.
5
Keep the miniature coaxial ClickLoc interfaces clean, dry and finger-tight.
6
Match the extension cable and Proximitor Sensor to the approved total system length.
7
Set static gap in the documented linear region while maintaining target clearance.
8
Verify polarity, vibration response and alarm action before returning the channel to service.

Technical notes

Technical notes

Install 330104-01-05-10-02-00 in the documented M10 × 1 probe position and preserve the 10 mm unthreaded length, 50 mm case execution and armored lead routing. Match the probe to the approved total system length and Proximitor Sensor, set the static gap in the linear region, and verify polarity and response before enabling protection logic.

FAQS

  • What exact function does 330104-01-05-10-02-00 perform as a 3300 XL 8 mm Metric Proximity Probe with Armor?
    It is the metric field probe that converts target distance into the eddy-current signal used by the matched 3300 XL loop.
  • Which host system must be confirmed before installing 330104-01-05-10-02-00?
    Confirm the documented Bently Nevada 3300 XL 8 mm Proximity Transducer System host and the complete 330104-01-05-10-02-00 marking before work.
  • Which connection checks are required for 330104-01-05-10-02-00?
    Inspect the M10 × 1 host thread, target clearance, lead route and clean ClickLoc interfaces.
  • How should the installed configuration for 330104-01-05-10-02-00 be preserved?
    Match the installed probe, extension cable and Proximitor Sensor to the approved total system length.
  • Which diagnostic evidence should be reviewed for 330104-01-05-10-02-00?
    Review static gap, polarity, channel baseline, monitor status and controlled vibration response.
  • What must be recorded before replacing 330104-01-05-10-02-00?
    Record the complete order number, 10 mm unthreaded length, 50 mm case execution, cable route and installed loop components.
  • How should 330104-01-05-10-02-00 be commissioned after installation?
    Set the gap in the linear region, verify polarity and prove the configured alert and danger actions under control.
  • Which model-specific limitation applies to 330104-01-05-10-02-00?
    The armored construction and exact metric case geometry must match the installed bracket and cable route.
